Sharp PN-CD701-LCD User Manual

42
E
AUDIO menu
Function
Command Direction
Parameter Reply Control/Response contents *
TREBLE AUTR WR -5-5 -5-5
○
BASS AUBS WR -5-5 -5-5
BALANCE AUBL WR -10-10 -10-10
RESET ARST W 3
-
SETUP menu
Function
Command Direction
Parameter Reply Control/Response contents *
DATE/TIME SETTING DATE WR
AABBCCDDEE AABBCCDDEE AA: Year, BB: Month, CC: Day, DD: Hour, EE: Minute
○
DATE FORMAT DTFT WR 0-2 0-2 0: YYYY/MM/DD, 1: MM/DD/YYYY, 2: DD/MM/YYYY
YYYY: Year, MM: Month, DD: Day
TIME FORMAT TMFT WR
0-1 0-1 0: 24-HOUR TIME, 1: 12-HOUR TIME
SCHEDULE SC01-
SC08
WR
ABCDEFFGGH ABCDEFFGGH Schedule of a specied number
A: Schedule 0= Not effective, 1 = Effective
B: Power 0 = OFF, 1 = ON
C: Day of the week 1 0 = Only once, 1 = Every week, 2 = Every day
D: Day of the week 2 0 = Sunday, 1 = Monday through 6 = Saturday,
9 = Not exist
E: Day of the week 3 0 = Sunday, 1 = Monday through 6 = Saturday,
9 = Not exist
F: Hour 00-23
G: Minute 00-59
H: Input 0 = Not specied, 1=HDMI1, 2=HDMI2, 4=D-SUB,
6=DisplayPort, 7=DVI-D, 8=OPTION(valid when an
option is attached)
SCHEDULE BRIGHTNESS SB01-
SB08
WR 0-31 0-31 Screen brightness to change
99 99 Disable brightness setting
LANGUAGE LANG WR 14 14 ENGLISH
1 1 DEUTSCH
2 2 FRANÇAIS
3 3 ITALIANO
4 4 ESPAÑOL
5 5 РУССКИЙ
6 6
7 7
INPUT SELECT D-SUB SLDS WR 0-1 0-1 0: RGB, 1: COMPONENT
HDMI CEC LINK CELK WR 0-1 0-1 0: OFF, 1: AUTO
AUTO POWER ON ATPO WR 0-1 0-1 0: OFF, 1: ON
HDMI AUTO VIEW
(HDMI1)
HDAW WR 0-1 0-1 0: OFF, 1: ON
HDMI AUTO VIEW
(HDMI2)
H2AW WR 0-1 0-1 0: OFF, 1: ON
HDMI AUTO VIEW
(OPTION)
OPAW WR 0-1 0-1 0: OFF, 1: ON
(valid when you have used the expansion slot to expand the functions)
HOT PLUG CONTROL
(DVI-D)
HPCT WR 0-1 0-1 0: OFF, 1: ON
HOT PLUG CONTROL
(HDMI1)
HPCH WR 0-1 0-1 0: OFF, 1: ON
HOT PLUG CONTROL
(HDMI2)
HPH2 WR 0-1 0-1 0: OFF, 1: ON
HOT PLUG
CONTROL (OPTION)
HPOP WR 0-1 0-1 0: OFF, 1: ON
(valid when you have used the expansion slot to expand the functions)
DisplayPort STREAM DPST WR 0-1 0-1 0: SST, 1: MST
“ERR” when PIP MODES is a value other than OFF.
-
DisplayPort SETTING HIGH-FREQUENCY
GAIN
DPHG WR 0-31 0-31
LOW-FREQUENCY
GAIN
DPLG WR 0-31 0-31
FILTER SETTING DPFL WR 0-15 0-15
OFFSET DPOF WR 0-15 0-15
RESET DPRS W 1
AUDIO SELECT HDMI1
ASHP WR 0-1 0-1
0: HDMI, 1: AUDIO
○
HDMI2
AH2P WR 0-1 0-1
0: HDMI, 1: AUDIO
DisplayPort
ASDI WR 1, 3 1, 3
1: AUDIO, 3: DisplayPort
OPTION
ASOP WR 0-1 0-1
0: OPTION, 1: AUDIO
(valid when you have used the expansion slot to expand the functions)
AUDIO OPTION AUDIO OUTPUT
AOUT WR 0-2 0-2
0: VARIABLE1, 1: FIXED, 2: VARIABLE2
AUDIO INPUT LEVEL
AIVP WR 0-1 0-1
0: 1.0Vrms, 1: 0.5Vrms
MONAURAL AUDIO MONO WR
0-1 0-1
0: OFF, 1: ON
START INPUT MODE SUIM WR
1-4, 6-7, 10 1-4, 6-7, 10
1: LAST INPUT MODE, 2: DisplayPort, 3: HDMI1, 4: HDMI2, 6: DVI-D, 7: D-SUB,
10: OPTION (valid when you have used the expansion slot to expand the
functions)
COMMUNICATION
SETTING
RS-232C/LAN
SELECT
CTLS WR 0-1 0-1 0: RS-232C, 1: LAN
●
BAUD RATE
BAUD WR 0-2 0-2 0: 9600bps, 1: 19200bps, 2: 38400bps
○
Crestron Connected
CRCN WR 0-1 0-1 0: OFF, 1: ON
Controlling the Monitor with a PC (RS-232C)
