37 P05 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to AIN7, P14, P15, P16 and P17 terminal
while one of G3 line keys on key matrix is touched.
38 P04 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to AIN7, P14, P15, P16 and P17 terminal
while one of G4 line keys on key matrix is touched.
39 P03 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to AIN7, P14, P15, P16 and P17 terminal
while one of G5 line keys on key matrix is touched.
40 P02 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to AIN7, P14, P15, P16 and P17 terminal
while one of G6 line keys on key matrix is touched.
41 P01 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to AIN7, P14, P15, P16, P17 and AIN6
terminal while one of G7 line keys on key matrix is touched.
42 P00 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to AIN7, P14, P15, P16 and P17 terminal
while one of G8 line keys on key matrix is touched.
43 P17 IN Signal coming from touch key.
When either G9 line on key matrix is touched, a corresponding signal out of P00-P07 will be input
into P17. When no key is touched, the signal is held at "H" level.
44 P16 IN Signal similar to P17.
When either G10 line on key matrix is touched, a corresponding signal will be input into P16.
45 P15 IN Signal similar to P17.
When either G11 line on key matrix is touched, a corresponding signal will be input into P15.
46 P14 IN Signal similar to P17.
When either G12 line on key matrix is touched, a corresponding signal will be input into P14.
47 AIN7 IN Signal similar to P17.
When either G13 line on key matrix is touched, a corresponding signal will be input into AIN7.
48 AIN6 IN Input terminal to judge the model.
The signal out of P07 will be input into AIN6 through G1 line on key matrix. The LSI will judge the
model by this signal.
49-50 P11-P10 IN Terminal not used.
51 RESET IN Auto clear terminal.
Signal is input to reset the LSI to the initial state when power is applied. Temporarily set "L" level the
moment power is applied, at this time the LSI is reset. Thereafter set at "H" level
52 NC Terminal not used.
53 XCOUT OUT Terminal not used.
54 XCIN IN Connected to VC.
55 NC Terminal not used.
56 VCC IN Power source voltage: GND(0V).
The power source voltage to drive LSI is input to VCC terminal.
57 OSCSEL IN Connected to VC(-5V).
58 XOUT OUT Internal clock oscillation output.
Output to control oscillation input of XIN.
59 VSS IN Power source voltage: -5.0V.
The power source voltage to the LSI is input to VSS terminal. Connected to VC.
60 NC Terminal not used.
61 XIN IN Internal clock oscillation frequency control input setting.
The internal clock frequency is set by inserting the ceramic filter oscillation circuit with respect to
XOUT terminal.
62 NC Terminal not used.
63-66
AIN3-AIN0
IN Terminal to change cooking input according to the Model.
By using the A/D converter contained in the LSI, DC voltage in accordance with the Model in
operation is applied to set up its cooking constant.
67 COM8 OUT Common data signal : COM8. Connected to LCD signal COM8.
68 COM9 OUT Common data signal : COM7. Connected to LCD signal COM7.
69 COM10 OUT Common data signal : COM6. Connected to LCD signal COM6.
70 COM11 OUT Common data signal : COM5. Connected to LCD signal COM5.
71 COM12 OUT
Common data signal : COM4. Connected to LCD signal COM4.
Pin No. Signal I/O Description
