SJPT55RHS
5 – 1
SJPT55RHS
Service Manual
CHAPTER 5. WIRING DIAGRAM
[1] WIRING DIAGRAM
Be sure to replace the electrical parts with specified ones for maintaining the safety and performance of the set.
1. SJ-PT51R/PT55R
2. SJ-T51R/T55R
STARTING RELAY
COMPRESSOR
(G/Y)
FUSE
DEF-HEATER
LAMP
R-DOOR
SWITCH
F-DOOR
SWITCH
FAN MOTOR
(BL)
(SOURCE CORD)
(BR)
AC/DC
MAIN PWB
(GY)
PROTECTOR
(BR)
(W)
(BK)
(V)
(SB)
L
(SB)
(P)
(BL)
(GR)
(R)
FM
(BK)
(W)
(BR)
(BK)
(GR)
(P)
CONTROL
PWB
(BR)
(O)
(R)
(Y)
ELECTRICAL DAMPER
(SB)
(BL)
(P)
(O)
(W)
(GY)
(F-THERMISTOR)
(DEF-THERMISTOR)
(R-THERMISTOR)
BK : BLACK
BR : BROWN
R : RED
O : ORANGE
Y : YELLOW
GR : GREEN
BL : BLUE
V : VIOLET
GY : GRAY
W : WHITE
P : PINK
SB : SKY-BLUE
G/Y : GREEN/YELLOW STRIPE
