Sharp SJ-PT55R-HS Service Manual

SJPT55RHS
1 – 1
SJPT55RHS
Service Manual
CHAPTER 1. SPECIFICATION
Items SJ-PT51R SJ-T51R SJ-PT55R SJ-T55R
Type 2-Door
Outer dimensions Height 1670mm(65.7") 1770mm(69.7")
Width 800mm(31.5") 800mm(31.5")
Depth 720mm(28.3") 720mm(28.3")
Rated storage volume
(Rated volume)
Total 514liter(18.1cu.ft) 555liter(19.6cu.ft)
Freezer 139liter(4.8cu.ft) 139liter(4.9cu.ft)
Refrigerator 375liter(13.3cu.ft) 416liter(14.7cu.ft)
Defrosting System Heater system
Start Automatic
Finish Automatic
Temperature control Automatic (Adjustable)
No-frost freezer Yes
Interior lamp Freezer 1 (LED) — 1 (LED) —
Refrigerator 1 (LED) 1 1 (LED) 1
Evaporating pan 1 (unremovable)
Freezer Compartment F-shelf 1
F-shelf S 1 — 1 —
Ice cube maker Twin ice cube maker
Ice storage box 1
F door pocket ass'y 1
RF door pocket 1
Refrigerator Compartment Fresh case 1
Fresh door 1
R glass shelf ass'y 1 2 1 2
R glass shelf SF ass'y 1 — 1 —
R glass shelf SB ass'y 1 — 1 —
V glass shelf ass'y 1
Vegetable case 2
Egg tray 2 1 2 1
R door pocket 1
R door cover 1 — 1 —
RF door pocket 1
Utility pocket 2
Utility pocket L — 1
Bottle pocket 1
Tube stand 2 1 2 1
Deodorizing unit (Honeycomb type) 2 1 2 1
Door opening side Changeable*1 — Changeable*1 —
*1 To modify the door, REFRIGERATOR HINGE KITS (SJ-L55CRD) will be required.
All modification work should be carried out by a competent person.
RATING
Items SJ-PT51R SJ-T51R SJ-PT55R SJ-T55R
Rated voltage (V~) 110
Rated frequency (Hz) 60
Climate class ST
Rated input (W) 146
Rated input of heating systems (W) 146
Defrosting input (W) 146
Refrigerant (Charging quantity) [Non-flammable] HFC-134a(110g) HFC-134a(110g) HFC-134a(110g) HFC-134a(110g)
Insulation blowing gas [Flammable] Cyclo pentane (HC)
Net Weight (kg) 80 77 82 79
PLUG TYPE
Plug cord 2 pin
Plug type A-1
Destination mark F
COLOR
Items -HS/SL
Outside color Silver
Inside color White
