Sharp SJ-PT55R-HS Service Manual

SJPT55RHS
2 – 3
[2] CONSTRUCTIONS
Evaporator
Damper ass'y
Freezer
compartment
Refrigerator
compartment
Defrost heater
R-thermistor
Aluminum panel
F-thermistor
DEF-thermistor
Deodorizer
Deodorizer
F fan motor
Fuse ass'y
Ionizer-K
LED PWB ass'y
(Only for SJ-T51R/T55R)
(for SJ-T51R/T55R)
(Only for SJ-PT51R/PT55R)
(Only for SJ-PT51R/PT55R)
(Only for SJ-PT51R/PT55R)
(for SJ-PT51R/PT55R)
Mark : Cold air flow
Main PWB ass'y
Caster
Foot cover
Evaporating pan
Refrigerator temp. control knob
Lamp
LED lamp PWB L ass'y
R LED lamp PWB L ass'y
Freezer temp. control knob
Adjustable leg ass'y
Compressor
Starting relay
Overload relay(Protector)
