Sharp SJ-XF50X-T - Page 68

SJXF50XT
11
[5] SJ-XF50X-T CYCLE
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[5] SJ-XF50X-T CYCLE
1-5 FPWB-B136CBKZ BP Eecon-inv pwb
1-6 FPWB-B231CBKZ BQ Main pwb
1-21 RMOTRA125CBZZ AW Fan motor g
1-27 RCILZA032CBZZ AQ Reactance
1-38 QCNW-B635C B ZZ Earth cable
4-5 L X -BZA073JBE0 AA Special screw
4-6 LX-BZA095CBMZ AB Special screw
4-8 L X-JZA006CBZZ AC Special screw
6-1 PCMPLA406CBZZ BW Compressor
6-2 RHOG-A227CBZZ AS Protector
6-4 FFRM-A183CBKZ Base frame ass'y
6-5 LX-BZA088CBMZ AH Bolt
6-6 L X-NZA019CBMZ AB Nut
6-7 L X-WZA035CBZZ AB Washer
6-8 PCOV-A429CBFA AG Relay cover
This shows the part
that exchange is
necessary for a set.
4-8
6-1
6-10
6-4
1-6
1-21
6-14
6-17
6-17
6-18
4-5
6-6
6-7
6-8
6-2
1-5
6-19
6-5
6-26
6-24
6-23
6-20
1-27
6-28
6-13
6-30
4-6
6-16
4-6
6-41
6-9
6-12
6-34
6-23
6-20
1-38
6-11
