SM-SX1/SX1W
INTEGRATED CIRCUITS
IC101 VHINJM4558M-1 J AC Motor Driver,NJM4558M
IC102 VHI74HC153F-1 J AH Inverter,74HC153F
IC103 VHITC74HCU04F J AF Amp.,TC74HCU04F
IC301 VHINJM431U/-1 J AE Regulator,NJM431U
IC302 RUNTZ0775AFZZ J AZ DC/DC Converter,TZ0775AF
IC303 VHINJM78M05-1 J AE +5V Voltage Regulator,
NJM78M05
IC304 VHINJM78M12-1 J AF +12V Voltage Regulator,
NJM78M12
IC305 VHINJM79M12-1 J AF -12V Voltage Regulator,
NJM79M12
IC306 VHINJM431U/-1 J AE Regulator,NJM431U
IC307 VHINJM4558M-1 J AC Motor Driver,NJM4558M
IC308 RH-IX2838AFZZ J AP Analog Amp.,IX2838AF
IC800 VHIYM3436D/-1 J BA Digital Interface Receiver,
YM3436D
IC801 VHISM5844AF-1 J BF Sampling Rate
Converter,SM5844AF
IC802 VHITC7W04F/-1 J AD Inverter,TC7W04F
IC803 VHITDA1307/-1 J BS 1-Bit Conversion,TDA1307
IC804 VHI74ACT00F-1 J AE Control,74ACT00F
IC805 VHI74HC74AF+1 J Waveform Rectification,
74HC74AF
IC806,807 VHI74ACT00F-1 J AE Control,74ACT00F
IC809 VHI74HC74AF+1 J Waveform Rectification,
74HC74AF
IC810 VHITC7WU04F-1 J AD PC Controll,TC7WU04F
IC811 VHITC7W74F/-1 J AE Change Voltage,TC7W74F
IC812 VHITC7W08F/-1 J AE Inverter,TC7W08F
IC903~905 VHIBU2114F+-1 J AL LED Driver,BU2114F
IC907 RH-IX2845AFZZ J AZ System Microcomputer,
IX2845AF
IC908 VHIPST9119F-1 J AE Reset,PST9119F
ICA1 RH-IX2815AFZZ J AV 7th Order Modulation Conver-
sion LSI,IX2815AF
ICA2 VHI74AC00F/-1 J AE NAND Gate,74AC00F
ICA3 VHITAC08F//-1 J AE AND Gate,TAC08F
ICA4~7 VHIHIP2100/-1 J AQ FET Driver,HIP2100
TRANSISTORS
Q101~103 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q201 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q202 VS2SA1037KR-1 J AB Silicon,PNP,2SA1037 KR
Q203~208 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q301~303 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q304 VS2SD2394F/-1 J AE Silicon,NPN,2SD2394 F
Q305 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q306,307 VS2SC3242-F-1 J AC Silicon,NPN,2SC3242 F
Q309 VS2SD2394F/-1 J AE Silicon,NPN,2SD2394 F
Q310 VS2SA1037KR-1 J AB Silicon,PNP,2SA1037 KR
Q311 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q313~316 VS2SA1036KR-1 J AC Silicon,PNP,2SA1036 KR
Q317~320 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q321,322 VS2SK389BL+-1 J AH FET,2SK389 BL
Q323,324 VS2SJ109BL+-1 J AM FET,2SJ109 BL
Q325,326 VS2SK170-BL-1 J AD FET,2SK170 BL
Q327,328 VS2SJ74BL++-1 J AG FET,2SJ74 BL
Q801~803 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
QA1~8 VS2SA1483//-1 J AM Silicon,PNP,2SA1483
QA9,10 VSMP4712+++-1 J AS Power FET×4,MP4712
DIODES
D101~103 VHDDAN202K/-1 J AB Silicon,DAN202K
D201~204 VHDDAN202K/-1 J AB Silicon,DAN202K
D301~303 VHDDAN202K/-1 J AB Silicon,DAN202K
D304 VHD20E4FD//-1 J AC Silicon,20E4FD
D305~308 VHD1SR154/4-1 J AC Silicon,1SR154
D310~315 VHD1SR154/4-1 J AC Silicon,1SR154
D316~323 VHDDAN202K/-1 J AB Silicon,DAN202K
D324~327 VHD1SR154/4-1 J AC Silicon,1SR154
D328 VHDDAN202K/-1 J AB Silicon,DAN202K
D800~803 VHDDAN202K/-1 J AB Silicon,DAN202K
D900 VHDDAN202K/-1 J AB Silicon,DAN202K
DA1~8 VHD1SS355//-1 J AB Silicon,1SS355
DA9~16 VHDSM1XP2//-1 J AD Silicon,SM1XP2
LED900~904 RH-PX1124AFZZ J AL LED,White,PX1124AF
LED905~907 VHPGL9BC030-1 J BA LED,White,GL9BC030
ZD101 VHEMTZJ5R1B-1 J AC Zener,5.1V,MTZJ5.1B
ZD301 VHEMTZJ160A-1 J AA Zener,16V,MTZJ16A
ZD302,303 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
ZD304 VHEHZ5BLL//-1 J AC Zener,5V,HZ5BLL
ZDA1~8 VHEHZU12B3+-1 J AB Zener,12V,HZU12B3
ZDA81A~84A VHEHZ7A2///-1 J AB Zener,7.2V,HZ7A2
ZDA81B~84B VHEHZ7A2///-1 J AB Zener,7.2V,HZ7A2
THYRISTOR
THY301 VHSSF3J48++-1 J AK Thyristor,SF3J48
COILS
L101,102 RCILC0371AFZZ J AC Line Filter
L105,106 RCILC0371AFZZ J AC Line Filter
L109,110 RCILC0371AFZZ J AC Line Filter
L113,114 RCILC0371AFZZ J AC Line Filter
L117 RFILN2023SCZA J AF Line Filter,Digital Signal
L118,119 VPACK100J0000 J AB 10 µH
L120,121 RCILC0371AFZZ J AC Line Filter
L123 VP-CH101K0000 J AB 100 µH
L124~127 RCILC0371AFZZ J AC Line Filter
L201~207 RCILC0371AFZZ J AC Line Filter
L301~303 VP-CH221K0000 J AB 220 µH,Noise Filter
! L501 RCILZ0337AFZZ J AT Line Filter,5 mH
! L502 RCILZ0318AFZZ J AF Line Filter,220 µH
L800~806 RCILC0371AFZZ J AC Line Filter
L808~813 RCILC0371AFZZ J AC Line Filter
L900 VPACK220J0000 J AB 22 µH
L901~903 RCILC0371AFZZ J AC Line Filter
LA801~804 RCILZ0335AFZZ J AR 10.8 µH
LA805~808 RCILZ0336AFZZ J AS 5.6 µH
VARIABLE RESISTORS
VOL301 RVR-A0267AFZZ J BD 20 kohms (B)×5 [Main Volume]
VRA1~4 RVR-M1615AFZZ J AP 200 ohms (B),Semi-VR
[1Bit AMP. Feadback Level
Adjustment]
VIBRATORS
CXA1 RCRSC0032AFZZ J AH Crystal,11.2896 MHz
X800 RCRSC0032AFZZ J AH Crystal,11.2896 MHz
X900 RCRM-0202AFZZ J AD Ceramic,8.00 MHz
THERMISTOR
! R390 RH-QX0006AWZZ J AE Posistor,4.7 ohms
! R391 RH-QX0003AWZZ J AK Posistor,2.2 ohms
! R392 RH-QX0002AWZZ J AK Posistor,0.7 ohms
! R393 RH-QX0003AWZZ J AK Posistor,2.2 ohms
! R396,397 RH-QX1067AFZZ J AE Posistor,8.2 ohms
CAPACITORS
C101~108 VCKYTV1HB102K J AA 0.001 µF,50V
C112 VCKYTV1EB103K J AA 0.01 µF,25V
C113 VCKYTV1EB104K J AA 0.1 µF,25V
C114 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C115,116 VCKYTV1EB104K J AA 0.1 µF,25V
C117,118 VCKYTV1HB103K J AA 0.01 µF,50V
C119 VCE9GA1VW476M J AF 47 µF,35V,Electrolytic,Non-Polar
C120,121 VCKYTV1EB104K J AA 0.1 µF,25V
C122 VCKYTV1EB223K J AB 0.022 µF,25V
C124~128 VCKYTV1HB152J J AA 0.0015 µF,50V
C129 RC-KZ1250AFZZ J 0.68µF
C130 VCKYTV1HB152J J AA 0.0015 µF,50V
[For SM-SX1 Only]
C131 VCTYBT1CX152M J AA 0.0015 µF,16V
[For SM-SX1 Only]
C132 VCTYBT1CX152M J AA 0.0015 µF,16V
C202,203 VCE9GA1VW336M J AD 33 µF,35V,Electrolytic,Non-Polar
C304 VCEA7A476AF1C J AB 47 µF,16V,Electrolytic
C305 VCKYTV1HB102K J AA 0.001 µF,50V
C306 RC-EZ1699AFZZ J AK 47 µF,20V,Electrolytic
C307 VCKYTV1HB103K J AA 0.01 µF,50V
C308,309 RC-EZ1714AFZZ J AD 220 µF,35V,Electrolytic
C310 VCKYTV1HB103K J AA 0.01 µF,50V
