SM-SX1/SX1W
– 3 –
Rated output power:
RMS; 50 W + 50 W (DIN 45 500)
Total harmonic distortion:
0.05 % (1 kHz, 1 W)
Frequency response:
10 Hz - 20 kHz (+1 dB, -1 dB)
10 Hz - 100 kHz (+1 dB, -3 dB)
Dynamic range:
100 dB (10 Hz - 20 kHz)
A/D noise shaping:
7th-order
(delta-sigma) modulation
Input terminals:
DIGITAL1; RCA coaxial
DIGITAL2; Square type optical
SACD; RCA analog, 1 BIT digital
LINE 1,2; RCA analog (350 mV rms/50 k ohms)
Output terminals:
DIGITAL OUT; Square type optical
LINE OUT; RCA analog
Speakers; 8 ohms
Dimensions:
Width; 300 mm (11-13/16")
Weight:
Approx. 6.8 Kg (15.0 lbs.)
Height; 66 mm (2-5/8")
Depth; 411 mm (16-3/16")
120 V, 60 Hz
220-240 V, 50/60 Hz
230 V, 50 Hz
220 V, 50 Hz
110 - 120 V, 50/60 Hz
220- 240 V, 50/60 Hz
Power source:
North America
Australia,
New Zealand
Singapore
Hong Kong
Other countries
51 W
55 W
55 W
55 W
55 W
55 W
POWER
CONSUMPTION
POWER SOURCE
Specifications for this model are subject to change without
prior notice.
SPECIFICATIONS
NAMES OF PARTS
SACD
DIGITAL1
DIGITAL2
LINE1
LINE2
3
2
4
1
4 Volume Control Knob
Controls the sound level.
To cut the output to the speaker with the
power turned on:
Set the sound level at “0” then press and
hold the corresponding input selector but-
ton for 2 seconds or more.
The signal output to the speaker returns
when you reset the sound level at “1” or
higher.
1 Power Button
Turns the unit on or off.
2 Input Selector Buttons
Used to select the equipment source you
want to play back.
When the power is turned on, the unit is
switched to “SACD”.
3 Volume Display
Displays the sound level within the range of
“0” - “128”.
