Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-5
VL-PD3S/H/E
VL-PD3S/H/E
R4422 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
R4426 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R4430 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R4431 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
R4432 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R4435 VRS-CZ1JF330J 33 1/16WMetal Oxide AA
R4436 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R4437 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R4441 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R4442 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R4443 VRS-CZ1JF181J 180 1/16W Metal Oxide AA
R4444 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R4445 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R4447 VRS-CZ1JF332J 3.3k 1/16W Metal Oxide AA
R4448 VRS-CZ1JF562D 5.6k 1/16W Metal Oxide AB
R4449 VRS-CZ1JF122D 1.2k 1/16W Metal Oxide AB
R4451 VRS-CZ1JF273D 27k 1/16W Metal Oxide AA
R4452 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
R4453 VRS-CZ1JF332J 3.3k 1/16W Metal Oxide AA
R4454 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R4455 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R4461 VRS-CZ1JF272J 2.7k 1/16W Metal Oxide AA
R4462 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
R4463 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R4464 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R4465 VRS-CZ1JF391J 390 1/16W Metal Oxide AA
R4466 VRS-CZ1JF272J 2.7k 1/16W Metal Oxide AA
R4467 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R4468 VRS-CZ1JF183J 18k 1/16W Metal Oxide AA
R4469 VRS-CZ1JF332J 3.3k 1/16W Metal Oxide AA
R4470 VRS-CZ1JF331J 330 1/16W Metal Oxide AA
R4471 VRS-CZ1JF474J 470k 1/16W Metal Oxide AA
R4472 VRS-CZ1JF332J 3.3k 1/16W Metal Oxide AA
R4473 VRS-CZ1JF821J 820 1/16W Metal Oxide AA
R4477 VRS-CZ1JF363D 36k 1/16W Metal Oxide AA
R4479 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R4484 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R4701 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R4702 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
R4703 VRS-CZ1JF224J 220k 1/16W Metal Oxide AA
R4704 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
R4705 VRS-CZ1JF334J 330k 1/16W Metal Oxide AA
R4706 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
R4707 VRS-CZ1JF823J 82k 1/16W Metal Oxide AA
R4708 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
R4709 VRS-CZ1JF823J 82k 1/16W Metal Oxide AA
R4710 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
R4711 VRS-CZ1JF224J 220k 1/16W Metal Oxide AA
R4712 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
R4713 VRS-CZ1JF184J 180k 1/16W Metal Oxide AA
R4714 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
R4715 VRS-CZ1JF393J 39k 1/16W Metal Oxide AA
R4716 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
MISCELLANEOUS PARTS
FB1001 RBLN-0028TAZZ Balun, BLN-0028TA AB
FB1002 RBLN-0106TAZZ Balun, BLN-0106TA AB
FB1003 RBLN-0028TAZZ Balun, BLN-0028TA AB
FB1004 RBLN-0028TAZZ Balun, BLN-0028TA AB
FB1005 RBLN-0028TAZZ Balun, BLN-0028TA AB
P601 QPLGN0374TAZZ Plug, 3pin AC
P1001 QCNCM5069TAZZ Plug, 50pin AG
P1002 QCNCM9167TAZZ Plug, 100pin AK
P3701 QPLGN0376TAZZ Plug, 3pin AD
SC1001 QSOCN2886TAZZ Socket, 28pin AE
SC1003 QSOCN5111TAN1 Socket, 51pin AH
SC3702 QSOCN0560TAZZ Socket, 5pin AC
DUNTK2872PM02 MAIN2 PWB UNIT(VL-PD3S)
DUNTK2872PM03 MAIN2 PWB UNIT(VL-PD3H)
DUNTK2872PM04 MAIN2 PWB UNIT(VL-PD3E/EW/EX)
INTEGRATED CIRCUITS
IC431 RH-iX0630TAZZ IX0630TA(TRANSPORT) BG
IC432 RH-iX0616TAZZ IX0616TA(ECC AW
EXTERNAL MEMORY)
IC491 VHiM40C558V-1 A/D CONVERTER AX
IC980 VHiTA75S01F-1 AMP AD
IC1601 VHiAK4518VF-1 ADC/DAC AQ
IC1650 RH-iX0632TAZZ IX0632TA(PCM) BB
IC1651 VHiTC75S54F-1 AMP AF
IC1702 VHiLB1990WA-1 MOTOR DRIVE AS
IC1902 VHiTK11900M-1 TK11900M AF
IC1971 VHiBU2090FS-1 SERIAL IN/PARALLEL AG
OUT DRIVER
IC3401 VHiBH7268KV-1 PLL BB
IC3402 VHiBH7273KV-1 EQ/ATF BA
IC3403 VHiAD8561RU-1 COMPARATOR AQ
IC7401 VHiMB86611/-1 IEEE1394 CONTROLLER BB
IC7701 RH-iX0694TAZZ IX0658TA(MECHA AX
CONTROL MICON)
IC7702 VHiTA75W01/-1 SERVO ERROR AMP AF
IC8800 VHiCXA2503A-1 VF RGB DECODER AZ
CONTROLLER
IC9800 VHiT7SET08U-1 BUFFER AE
TRANSISTORS
Q943 VSXP4316///-1 XP4316 AC
Q1701 VSXP6501///-1 XP6501 AB
Q1702 VSXP4113///-1 XP4113 AA
Q1703 VS2PA1774R/-1 2PA1774R AB
Q1704 VSCPH3206//-1 CPH3206 AD
Q1901 VSUN9214///-1 UN9214 AB
Q1902 VSSi2301DS/-1 Si2301DS AE
Q1903 VSSi2301DS/-1 Si2301DS AE
Q1904 VSXP4113///-1 XP4113 AA
Q1905 VSXN4404///-1 XN4404 AD
Q1906 VSSi2301DS/-1 Si2301DS AE
Q1908 VSXP4113///-1 XP4113 AA
Q1909 VSXP4113///-1 XP4113 AA
Q1910 VS2SD1979S/-1 2SD1979S AE
Q1911 VSXP1213///-1 XP1213 AB
Q1914 VSUPUMX1///-1 UPUMX1 AC
Q1915 VSSi2301DS/-1 Si2301DS AE
Q1916 VSSi2301DS/-1 Si2301DS AE
Q2401 VSXP6501///-1 XP6501 AB
Q2402 VSXP6401///-1 XP6401 AB
Q2403 VSXP6401///-1 XP6401 AB
Q2404 VSXP6401///-1 XP6401 AB
Q2405 VSXP6501///-1 XP6501 AB
Q2406 VSXP6501///-1 XP6501 AB
Q3401 VS2SC4627CD-1 2SC4627CD AB
Q7401 VSCPH3206//-1 CPH3206 AD
Q7402 VSUPUMD3///-1 UPUMD3 AC
Q7403 VSUPDA114EE-1 UPDA114EE AB
Q8800 VSUPUMZ1///-1 UPUMZ1 AC
DIODES
D1902 VHDMA132WK/-1 Diode, DMA132WK AA
D3401 VHDMA137///-1 Diode, DMA137 AC
D7401 VHDBAV70S//-1 Diode, DBAV70S AC
D7402 VHDBAW56S//-1 Diode, DBAW56S AC
D8800 VHD1T406///-1 Diode, D1T406 AD
PACKAGED CIRCUITS
X431 RCRSC0110TAZZ Crystal AL
X1650 RCRSC0107TAZZ Crystal AL
X7401 RCRSC0127TAZZ Crystal AM
X7701 RCRSC0132TAZZ Crystal AK
X8800 RCRSC0151TAZZ Crystal AH
