Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-6
VL-PD3S/H/E
VL-PD3S/H/E
COILS
FL1650 RCiLZ0283TAZZ Coil AV
FL2401 RCiLF0391TAZZ Coil AG
FL3401 RCiLF0376TAZZ Coil AH
FL3402 RCiLF0375TAZZ Coil AG
FL3403 RCiLF0375TAZZ Coil AG
L456 VPM6N4R7MR45N Peaking 4.7µHAC
L491 VPM6N4R7MR45N Peaking 4.7µHAC
L1601 VPM6N100MR75N Peaking 10µHAC
L1650 VPM6N100MR75N Peaking 10µHAC
L1701 VPM6N100MR75N Peaking 10µHAC
L1901 VPBSM4R7MR40N Peaking 4.7µHAD
L1902 VPBSM2R2MR23N Peaking 2.2µHAC
L1903 VPM6N4R7MR45N Peaking 4.7µHAC
L1904 VPBSM2R2MR23N Peaking 2.2µHAC
L1905 VPBSM2R2MR23N Peaking 2.2µHAC
L1907 VPBSM2R2MR23N Peaking 2.2µHAC
L1908 VPBSM4R7MR40N Peaking 4.7µHAD
L1909 VPBSM100KR70N Peaking 10µHAC
L1910 VPBUM2R2MR20N Peaking 2.2µHAC
L2401 VPD9M5R6J1R6N Peaking 5.6µHAC
L2402 VPD9M5R6J1R6N Peaking 5.6µHAC
L3401 VPCBM4R7MR25N Peaking 4.7µHAC
L3402 VPCBM4R7MR25N Peaking 4.7µHAC
L3403 VPCBM4R7MR25N Peaking 4.7µHAC
L3406 VPAWM1R0JR70N Peaking 1µHAC
L3407 VPCBM4R7MR25N Peaking 4.7µHAC
L3410 VPM6N4R7MR45N Peaking 4.7µHAC
L7701 VPM6N100MR75N Peaking 10µHAC
L8800 VPM6N100MR75N Peaking 10µHAC
L8801 VPAWM100J2R6N Peaking 10µHAC
L8802 VPAWM120J2R8N Peaking 12µHAD
L9801 VPBSM220K1R7N Peaking 22µHAD
CONTROL
R3404 RVR-M7994TAZZ Variable Resistor AB
CAPACITORS
C431 RC-KZ0083TAZZ Capacitor AD
C433 RC-KZ0083TAZZ Capacitor AD
C435 VCCCCZ1HH5R0C 5p 50V Ceramic AC
C436 VCCCCZ1HH5R0C 5p 50V Ceramic AC
C437 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C438 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C439 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C442 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C443 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C444 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C445 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C447 VCSATK0JJ476M 47 6.3V Tantalum AE
C448 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C449 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C490 VCCCCZ1HH100D 10p 50V Ceramic AB
C491 VCKYCZ1CB103K 0.01 16V Ceramic AB
C492 RC-KZ0083TAZZ Capacitor AD
C493 VCKYCZ1CB103K 0.01 16V Ceramic AB
C494 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C495 VCCCCZ1HH100D 10p 50V Ceramic AB
C496 VCSAPR0JJ106M 10 6.3V Tantalum AD
C497 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C498 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C980 VCKYCZ1AB104K 0.1 10V Ceramic AB
C981 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C982 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1601 VCSAPR0JJ106M 10 6.3V Tantalum AD
C1602 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1603 VCKYCY0JB105K 1 6.3V Ceramic AC
C1604 VCKYCY0JB105K 1 6.3V Ceramic AC
C1605 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1606 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1607 VCSAPR0JJ106M 10 6.3V Tantalum AD
C1608 VCSAPR0JJ106M 10 6.3V Tantalum AD
C1609 VCKYCZ1HB222K 2200p 50V Ceramic AB
C1610 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1611 VCKYTV1CB224K 0.22 16V Ceramic AB
C1612 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1613 VCSAPR1AJ475M 4.7 10V Tantalum AD
C1614 VCKYCZ1HB222K 2200p 50V Ceramic AB
C1615 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1616 VCSAPR1AJ475M 4.7 10V Tantalum AD
C1617 VCKYTV1CB224K 0.22 16V Ceramic AB
C1652 VCKYTV1CF225Z 2.2 16V Ceramic AC
C1654 RC-KZ0101TAZZ Capacitor AD
C1655 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1656 VCSAPR0JJ106M 10 6.3V Tantalum AD
C1657 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1658 VCKYTV1CF225Z 2.2 16V Ceramic AC
C1659 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1660 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1661 VCSAPR1AJ475M 4.7 10V Tantalum AD
C1662 VCKYCY1CB473K 0.047 16V Ceramic AA
C1663 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1664 VCCCCZ1HH270J 27p 50V Ceramic AB
C1665 VCCCCZ1HH270J 27p 50V Ceramic AB
C1666 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1667 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1668 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1669 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1670 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1701 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1702 VCKYCZ1CB103K 0.01 16V Ceramic AB
C1703 VCKYCZ1CB103K 0.01 16V Ceramic AB
C1704 VCKYTV1AB105K 1 10V Ceramic AD
C1705 VCKYTV1AB105K 1 10V Ceramic AD
C1706 VCKYCY1AF105Z 1 10V Ceramic AC
C1707 VCKYCY1CB104K 0.1 16V Ceramic AB
C1708 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1709 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1710 RC-KZ0083TAZZ Capacitor AD
C1711 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1712 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1713 VCKYCY0JB105K 1 6.3V Ceramic AC
C1714 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1715 VCKYCZ1HB392K 3900p 50V Ceramic AA
C1716 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1717 VCKYCZ1HB392K 3900p 50V Ceramic AA
C1718 VCKYCZ1HB392K 3900p 50V Ceramic AA
C1719 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1720 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1721 VCKYCY1AF105Z 1 10V Ceramic AC
C1722 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1723 VCKYCY1AF105Z 1 10V Ceramic AC
C1724 VCKYCY1CB473K 0.047 16V Ceramic AA
C1725 VCKYCZ1EB472K 4700p 25V Ceramic AB
C1726 VCKYCY1AF105Z 1 10V Ceramic AC
C1727 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1728 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1730 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1731 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1732 VCKYCY1AF105Z 1 10V Ceramic AC
C1735 VCCCCZ1HH101J 100p 50V Ceramic AB
C1901 VCKYTV1EB104K 0.1 25V Ceramic AB
C1902 VCKYTV1AB105K 1 10V Ceramic AD
C1903 VCKYTV1AB105K 1 10V Ceramic AD
C1904 VCKYCZ1AB104K 0.1 10V Ceramic AB
C1905 VCKYCZ1HB332K 3300p 50V Ceramic AA
C1906 VCKYCY0JB105K 1 6.3V Ceramic AC
C1907 VCKYTV1AB105K 1 10V Ceramic AD
C1908 VCKYTV1AB105K 1 10V Ceramic AD
C1909 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1910 VCKYTV1CB105K 1 16V Ceramic AC
C1911 VCKYCZ1CB103K 0.01 16V Ceramic AB
C1912 VCKYTV1AB105K 1 10V Ceramic AD
C1913 VCKYTV1AB105K 1 10V Ceramic AD
C1914 VCKYCZ1HB332K 3300p 50V Ceramic AA
C1915 VCKYCZ1CB103K 0.01 16V Ceramic AB
C1916 VCSATE1AJ476M 47 10V Tantalum AD
C1917 VCKYTV1AB105K 1 10V Ceramic AD
C1967 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1971 VCKYCZ1AF104Z 0.1 10V Ceramic AB
