Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-9
VL-PD3S/H/E
VL-PD3S/H/E
R3455 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R3458 VRS-CZ1JF121J 120 1/16W Metal Oxide AA
R3463 VRS-CZ1JF112J 1.1k 1/16W Metal Oxide AA
R3464 VRS-CZ1JF391J 390 1/16W Metal Oxide AA
R3465 VRS-CZ1JF332J 3.3k 1/16W Metal Oxide AA
R3466 VRS-CZ1JF181J 180 1/16W Metal Oxide AA
R3467 VRS-CZ1JF271J 270 1/16W Metal Oxide AA
R3468 VRS-CZ1JF151J 150 1/16W Metal Oxide AA
R3469 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R3470 VRS-CZ1JF221J 220 1/16W Metal Oxide AA
R3480 VRS-CZ1JF221J 220 1/16W Metal Oxide AA
R3481 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R3482 VRS-CZ1JF181J 180 1/16W Metal Oxide AA
R3484 VRS-CZ1JF151J 150 1/16W Metal Oxide AA
R3486 VRS-CZ1JF151J 150 1/16W Metal Oxide AA
R3488 VRS-CZ1JF221J 220 1/16W Metal Oxide AA
R3489 VRS-CZ1JF391J 390 1/16W Metal Oxide AA
R3491 VRS-CZ1JF100J 10 1/16WMetal Oxide AA
R3492 VRS-CZ1JF332J 3.3k 1/16W Metal Oxide AA
R3493 VRS-CZ1JF220J 22 1/16WMetal Oxide AA
R3494 VRS-CZ1JF332J 3.3k 1/16W Metal Oxide AA
R3495 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R3496 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R7401 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R7402 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R7403 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R7405 VRS-CZ1JF821J 820 1/16W Metal Oxide AA
R7406 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R7407 VRS-CZ1JF334J 330k 1/16W Metal Oxide AA
R7409 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R7410 VRS-CZ1JF821J 820 1/16W Metal Oxide AA
R7411 VRS-CZ1JF472D 4.7k 1/16W Metal Oxide AB
R7412 VRS-CZ1JF472D 4.7k 1/16W Metal Oxide AB
R7413 VRS-CZ1JF101D 100 1/16W Metal Oxide AA
R7414 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
R7415 VRS-CZ1JF101D 100 1/16W Metal Oxide AA
R7416 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R7417 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R7418 VRS-CZ1JF560D 56 1/16WMetal Oxide AB
R7419 VRS-CZ1JF560D 56 1/16WMetal Oxide AB
R7420 VRS-CZ1JF560D 56 1/16WMetal Oxide AB
R7421 VRS-CZ1JF560D 56 1/16WMetal Oxide AB
R7422 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
R7423 VRS-CZ1JF560D 56 1/16WMetal Oxide AB
R7424 VRS-CZ1JF560D 56 1/16WMetal Oxide AB
R7425 VRS-CZ1JF560D 56 1/16WMetal Oxide AB
R7426 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R7427 VRS-CZ1JF301D 300 1/16W Metal Oxide AA
R7428 VRS-CZ1JF472D 4.7k 1/16W Metal Oxide AB
R7429 VRS-CZ1JF560D 56 1/16WMetal Oxide AB
R7430 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R7701 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R7702 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R7703 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R7704 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R7705 VRS-CZ1JF563J 56k 1/16W Metal Oxide AA
R7706 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
R7707 VRS-CZ1JF683J 68k 1/16W Metal Oxide AA
R7708 VRS-CZ1JF823J 82k 1/16W Metal Oxide AA
R7709 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R7710 VRK-SB1FF102J 1k 0.0315W AC
Metal Composition
R7711 VRK-SB1FF104J 100k 0.0315W AD
Metal Composition
R7712 VRK-SA1JF103J 10k 1/16W AB
Metal Composition
R7713 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R8800 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R8801 VRS-CZ1JF123J 12k 1/16W Metal Oxide AA
R8802 VRS-CZ1JF153D 15k 1/16W Metal Oxide AB
R8803 VRS-CZ1JF272J 2.7k 1/16W Metal Oxide AA
R8804 VRS-CZ1JF153J 15k 1/16W Metal Oxide AA
R8805 VRS-CZ1JF823D 82k 1/16W Metal Oxide AB
R8806 VRS-CZ1JF751J 750 1/16W Metal Oxide AA
R8808 VRK-SB1FF222J 2.2k 0.0315W AB
Metal Composition
R8812 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R8813 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R8814 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R8815 VRS-CZ1JF333J 33k 1/16W Metal Oxide AA
R8816 VRS-CZ1JF222J 2.2k 1/16W Metal Oxide AA
R8817 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
R8818 VRS-CZ1JF274D 270k 1/16W Metal Oxide AB
R8819 VRS-CZ1JF153D 15k 1/16W Metal Oxide AB
R8822 VRK-SB1FF100J 10 0.0315W AC
Metal Composition
R8823 VRK-SA1JF100J 10 1/16W AB
Metal Composition
R8824 VRK-SA1JF100J 10 1/16W AB
Metal Composition
R8825 VRS-CZ1JF100J 10 1/16WMetal Oxide AA
R8826 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R8827 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R8833 VRK-SA1JF564J 560k 1/16W AC
Metal Composition
R8835 VRS-CZ1JF222J 2.2k 1/16W Metal Oxide AA
R8836 VRS-CZ1JF100J 10 1/16WMetal Oxide AA
R8837 VRS-CZ1JF100J 10 1/16WMetal Oxide AA
R9804 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB1901 RBLN-0119TAZZ Balun, BLN-0119TA AC
FB2401 RBLN-0120TAZZ Balun, BLN-0120TA AC
FB2402 RBLN-0120TAZZ Balun, BLN-0120TA AC
FB2403 RBLN-0120TAZZ Balun, BLN-0120TA AC
FB2404 RBLN-0120TAZZ Balun, BLN-0120TA AC
FB2405 RBLN-0120TAZZ Balun, BLN-0120TA AC
FB7401 RBLN-0057TAZZ Balun, BLN-0057TA AC
FB7402 RBLN-0057TAZZ Balun, BLN-0057TA AC
FB8801 RBLN-0120TAZZ Balun, BLN-0120TA AC
FB9801 RBLN-0120TAZZ Balun, BLN-0120TA AC
J2401 QJAKE0065TAZZ Jack, 10pin AH
J7401 QJAKZ0068TAZZ Jack, 4pin AG
P1901 QCNCM9087TAZZ Plug, 90pin AR
P2402 QPLGN0276TAZZ Plug, 2pin AD
SC2401 QSOCN2806TAN1 Socket, 28pin AG
SC2402 QSOCN5111TAN1 Socket, 51pin AH
SC2403 QCNCW9188TAZZ Socket, 100pin AL
SC3301 QCNCW8080TAZZ Socket, 80pin AH
SC8800 QSOCN2092TAZZ Socket, 20pin AE
DUNTK2873QA02 CAMERA HEAD PWB UNIT
INTEGRATED CIRCUITS
IC1 VHiLZ2383SM-1 CCD IMAGER BN
IC12 VHiLR38610/-1 TIMING GENERATOR AP
IC13 VHiUPD16510-1 V-DRIVER AR
IC101 VHiCXA2096N-1 CDS/AGC AQ
IC501 VHiMB8346BV-1 D/A CONVERTER AN
IC551 VHiMM1449XQ-1 LENS DRIVER AT
IC552 VHiNJM2902V-1 IRIS DRIVE AD
IC553 VHiNJM3414V-1 IRIS DRIVE AF
TRANSISTORS
Q1 VS2SK508///-1 2SK508 AE
Q2 VS2SC4627CD-1 2SC4627CD AB
Q11 VS2PC4617R/-1 2PC4617R AB
Q12 VSXP6501///-1 XP6501 AB
Q551 VSDTA114TE/-1 DTA114TE AA
DIODE
D551 VHDDA121///-1 Diode, DDA121 AA
PACKAGED CIRCUIT
X11 RCRSZ0055TAZZ Crystal AS
