Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-10
VL-PD3S/H/E
VL-PD3S/H/E
FILTER AND COILS
PFiLW0076TAZZ Filter AP
L12 VPAWM100K1R5N Peaking 10µHAC
L101 VPAWM100K1R5N Peaking 10µHAC
L551 VPBWM150K1R0N Peaking 15µHAC
CAPACITORS
C1 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C2 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C3 VCSATE1VJ335M 3.3 35V Tantalum AD
C4 VCKYCZ1HB102K 1000p 50V Ceramic AB
C5 VCKYCZ1CB103K 0.01 16V Ceramic AB
C7 VCKYTV1EB104K 0.1 25V Ceramic AB
C12 VCSATA1AJ106M 10 10V Tantalum AC
C13 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C14 VCSATA1AJ106M 10 10V Tantalum AC
C15 VCSATE1VJ335M 3.3 35V Tantalum AD
C16 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C17 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C18 VCSATA1DJ475M 4.7 20V Tantalum AC
C19 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C20 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C21 VCSATA0JJ156M 15 6.3V Tantalum AC
C22 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C23 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C24 VCSATE1VJ335M 3.3 35V Tantalum AD
C26 VCKYCZ1HB102K 1000p 50V Ceramic AB
C27 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C28 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C29 VCSAPR0JJ106M 10 6.3V Tantalum AD
C31 VCSATE1DJ106M 10 20V Tantalum AD
C34 VCSATE1VJ335M 3.3 35V Tantalum AD
C35 VCKYCY1EF104Z 0.1 25V Ceramic AA
C36 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C102 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C103 VCKYCZ1EF223Z 0.022 25V Ceramic AB
C104 VCKYTV1CB105K 1 16V Ceramic AC
C105 VCKYTV1CB105K 1 16V Ceramic AC
C106 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C107 VCSATA0JJ156M 15 6.3V Tantalum AC
C108 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C109 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C110 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C111 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C112 VCSAPR0JJ106M 10 6.3V Tantalum AD
C113 VCSAPR0JJ106M 10 6.3V Tantalum AD
C501 VCSATA1AJ106M 10 10V Tantalum AC
C551 VCSATA1CJ106M 10 16V Tantalum AD
C552 VCKYCZ1EB472K 4700p 25V Ceramic AB
C553 VCKYCY1EB183K 0.018 25V Ceramic AA
C554 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C555 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C556 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C557 VCKYCZ1CB103K 0.01 16V Ceramic AB
C558 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C559 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C560 VCKYCY0JF105Z 1 6.3V Ceramic AB
C561 VCKYCZ1EB472K 4700p 25V Ceramic AB
C562 VCKYCZ1EB472K 4700p 25V Ceramic AB
C563 VCKYCZ1EB472K 4700p 25V Ceramic AB
C565 VCSATA1AJ106M 10 10V Tantalum AC
C566 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C567 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C568 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C569 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C570 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C571 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C572 VCCCCZ1HH151J 150p 50V Ceramic AB
C573 VCKYCY1CF224Z 0.22 16V Ceramic AA
C574 VCKYCZ1HF103Z 0.01 50V Ceramic AB
RESISTORS
R2 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R3 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
R4 VRS-CZ1JF222J 2.2k 1/16W Metal Oxide AA
R5 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R6 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R11 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R12 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R13 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R14 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R15 VRS-CZ1JF220J 22 1/16WMetal Oxide AA
R16 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R17 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R18 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R19 VRS-CZ1JF183J 18k 1/16W Metal Oxide AA
R20 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R21 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R23 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R24 VRS-CZ1JF822J 8.2k 1/16W Metal Oxide AA
R25 VRS-CZ1JF181J 180 1/16W Metal Oxide AA
R26 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R27 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R28 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R32 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R101 VRS-CZ1JF153D 15k 1/16W Metal Oxide AB
R103 VRS-CZ1JF244D 240k 1/16W Metal Oxide AA
R106 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
R107 VRS-CZ1JF182J 1.8k 1/16WMetal Oxide AA
R108 VRS-CZ1JF182J 1.8k 1/16WMetal Oxide AA
R109 VRS-CZ1JF473J 47k 1/16W Metal Oxide AA
R110 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
R111 VRS-CZ1JF562J 5.6k 1/16WMetal Oxide AA
R112 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R501 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R551 VRS-CZ1JF153J 15k 1/16W Metal Oxide AA
R552 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
R553 VRS-CZ1JF473D 47k 1/16W Metal Oxide AB
R554 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R555 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R556 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R557 VRS-CZ1JF682J 6.8k 1/16WMetal Oxide AA
R558 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R559 VRS-CZ1JF682J 6.8k 1/16WMetal Oxide AA
R560 VRS-CZ1JF392J 3.9k 1/16WMetal Oxide AA
R561 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R562 VRS-CZ1JF912J 9.1k 1/16WMetal Oxide AB
R563 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R564 VRS-CZ1JF153J 15k 1/16W Metal Oxide AA
R565 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R566 VRS-CZ1JF562J 5.6k 1/16WMetal Oxide AA
R567 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R568 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
R569 VRS-CZ1JF474J 470k 1/16W Metal Oxide AA
R570 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R571 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R572 VRS-CZ1JF122J 1.2k 1/16WMetal Oxide AA
R573 VRS-CZ1JF472J 4.7k 1/16WMetal Oxide AA
R574 VRS-CZ1JF222J 2.2k 1/16WMetal Oxide AA
R575 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
R576 VRS-CZ1JF474J 470k 1/16W Metal Oxide AA
R577 VRS-CZ1JF682J 6.8k 1/16WMetal Oxide AA
R578 VRS-CZ1JF682J 6.8k 1/16WMetal Oxide AA
R579 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R580 VRS-CZ1JF272D 2.7k 1/16WMetal Oxide AB
R581 VRS-CZ1JF153D 15k 1/16W Metal Oxide AB
R582 VRS-CZ1JF244D 240k 1/16W Metal Oxide AA
R583 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R584 VRS-CZ1JF471J 470 1/16W Metal Oxide AA
R585 VRS-CZ1JF271J 270 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB11 RBLN-0051TAZZ Balun, BLN-0051TA AC
SC501 QCNCW5068TAZZ CONNECTOR AG
SC551 QSOCN0203FJZZ Socket, 24pin AE
SW501 QSW-P0095TAZZ Switch AH
