Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-11
VL-PD3S/H/E
VL-PD3S/H/E
C903 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C904 VCKYCZ1AB104K 0.1 10V Ceramic AB
C905 VCKYCZ1AB104K 0.1 10V Ceramic AB
C906 VCKYCZ1AB104K 0.1 10V Ceramic AB
C907 VCCCCZ1HH101J 100p 50V Ceramic AB
C908 VCKYCY1AF105Z 1 10V Ceramic AC
C909 VCKYCZ1CB103K 0.01 16V Ceramic AB
C911 VCCCCY1HH221J 220p 50V Ceramic AA
C913 VCKYCY1HB102K 1000p 50V Ceramic AA
C914 VCKYCY1CB473K 0.047 16V Ceramic AA
C915 VCKYCY1CB104K 0.1 16V Ceramic AB
C916 VCKYCY1AF105Z 1 10V Ceramic AC
C917 VCKYCY1AF105Z 1 10V Ceramic AC
C918 VCKYCZ1HB102K 1000p 50V Ceramic AB
C919 VCKYCZ1HB102K 1000p 50V Ceramic AB
C920 VCKYCZ1HB102K 1000p 50V Ceramic AB
C921 VCKYCZ1HB102K 1000p 50V Ceramic AB
C922 VCKYCZ1HB102K 1000p 50V Ceramic AB
C935 VCKYCZ1HB102K 1000p 50V Ceramic AB
C936 VCKYCZ1HB102K 1000p 50V Ceramic AB
C937 VCKYCZ1CB103K 0.01 16V Ceramic AB
C938 VCKYCZ1CB103K 0.01 16V Ceramic AB
C950 RC-KZ0075TAZZ 2.2 16V AC
C951 RC-KZ0100TAZZ 4.7 10V AD
C952 VCKYTV1AB105K 1 10V Ceramic AD
C953 RC-KZ0075TAZZ 2.2 16V AC
C954 RC-KZ0044TAZZ 4.7 10V AD
C955 RC-KZ0070TAZZ 4.7 16V AD
C956 VCKYTQ1CB105K 1 16V Ceramic AC
C957 VCKYTQ1CB105K 1 16V Ceramic AC
C958 RC-KZ0069TAZZ 10 16V AE
C959 RC-KZ0058TAZZ 1 25V AC
C960 VCKYTV1AB105K 1 10V Ceramic AD
C961 VCKYTV1EB104K 0.1 25V Ceramic AB
C962 VCKYTV1CF105Z 1 16V Ceramic AB
C963 VCKYTV1CF105Z 1 16V Ceramic AB
C964 RC-KZ0075TAZZ 2.2 10V AC
C965 RC-KZ0044TAZZ 4.7 10V AD
C966 RC-KZ0055TAZZ 3.3 10V AD
C967 RC-KZ0069TAZZ 10 16V AE
C968 RC-KZ0075TAZZ 2.2 16V AC
C969 RC-KZ0075TAZZ 2.2 16V AC
C970 RC-KZ0100TAZZ 4.7 6.3V AD
C971 RC-KZ0070TAZZ 4.7 16V AD
C972 RC-KZ0044TAZZ 4.7 10V AD
C973 VCKYTV1AB105K 1 10V Ceramic AD
C974 RC-KZ0037TAZZ 2.2 10V AD
C975 RC-KZ0058TAZZ 1 2.5V AC
C976 VCKYTV1EB104K 0.1 25V Ceramic AB
C978 RC-KZ0075TAZZ 2.2 16V AC
C979 RC-KZ0044TAZZ 4.7 10V AD
C980 VCKYTV1AB105K 1 10V Ceramic AD
C2702 VCKYCY1AF105Z 1 10V Ceramic AC
C2703 VCKYCY1AF105Z 1 10V Ceramic AC
C2704 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C2705 VCKYCZ1HB102K 1000p 50V Ceramic AB
C2706 VCSAPR0JJ106M 10 6.3V Tantalum AD
C2707 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C2708 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C9900 VCCCCZ1HH181J 180p 50V Ceramic AB
C9901 VCKYCY1AF105Z 1 10V Ceramic AC
C9902 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C9903 VCKYCY1AB224K 0.22 10V Ceramic AB
C9905 VCKYCZ1CB103K 0.01 16V Ceramic AB
C9906 VCKYCZ1HB222K 2200p 50V Ceramic AB
C9907 VCKYCY1CB104K 0.1 16V Ceramic AB
C9908 VCKYCY1HB103K 0.01 50V Ceramic AA
C9909 VCKYCZ1AB104K 0.1 10V Ceramic AB
C9911 VCCCCZ1HH101J 100p 50V Ceramic AB
C9914 VCKYCZ1HB471K 470p 50V Ceramic AB
C9915 VCKYCZ1HB331K 330p 50V Ceramic AA
C9916 VCKYCZ1HB102K 1000p 50V Ceramic AB
C9917 VCKYCZ1CB103K 0.01 16V Ceramic AB
C9918 VCKYCY1HB103K 0.01 50V Ceramic AA
C9919 VCKYCZ1HB102K 1000p 50V Ceramic AB
DUNTK2874PM01 POWER PWB UNIT
INTEGRATED CIRCUITS
å CP1 VHiCCP2B25/-1 CCP2B25 AD
å CP2 VHiCCP2B25/-1 CCP2B25 AD
å CP3 VHiCCP2B25/-1 CCP2B25 AD
IC900 VHiFA3675F/-1 FA3675F AR
IC2702 VHiS84235F/-1 BATTERY BACKUP/SYS AL
3V REGULATOR
IC9900 VHiMB3785V/-1 MB3785V AQ
TRANSISTORS
Q902 VSCPH3106//-1 CPH3106 AD
Q905 VSCPH3106//-1 CPH3106 AD
Q908 VSCPH3209//-1 CPH3209 AD
Q909 VSCPH3106//-1 CPH3106 AD
Q911 VSCPH3106//-1 CPH3106 AD
Q912 VSCPH3106//-1 CPH3106 AD
Q913 VSCPH3106//-1 CPH3106 AD
Q914 VSCPH3106//-1 CPH3106 AD
Q915 VSCPH3106//-1 CPH3106 AD
Q916 VSCPH3109//-1 CPH3109 AD
Q2701 VS2PC4617R/-1 2PC4617R AB
Q2710 VS2SC4116Y/-1 2SC4116Y AB
DIODES
D902 VHDFS1J2E//-1 Diode, DFS1J2E AD
D903 VHDFS1J2E//-1 Diode, DFS1J2E AD
D906 VHDFS1J2E//-1 Diode, DFS1J2E AD
D908 VHDFS1J3///-1 Diode, DFS1J3 AD
D909 VHDFS1J2E//-1 Diode, DFS1J2E AD
D910 VHDFS1J2E//-1 Diode, DFS1J2E AD
D911 VHDFS1J2E//-1 Diode, DFS1J2E AD
D912 VHDF02J9///-1 Diode, DF02J9 AD
D913 VHDMA729///-1 Diode, DMA729 AD
D914 VHDMA729///-1 Diode, DMA729 AD
D915 VHDMA729///-1 Diode, DMA729 AD
D916 VHDF02J9///-1 Diode, DF02J9 AD
D917 VHDFS1J2E//-1 Diode, DFS1J2E AD
D980 RH-EX0259TAZZ Zener Diode, EX0259TA AB
D2701 VHDMA2S111/-1 Diode, DMA2S111 AC
COILS AND TRANSFORMER
L900 RCiLP0263TAZZ Coil, 4.7µHAE
L901 RCiLP0264TAZZ Coil, 15µHAE
L902 VPMAN100MR50N Peaking 10µHAC
L905 RCiLP0263TAZZ Coil, 4.7µHAE
L906 RCiLP0265TAZZ Coil, 33µHAE
L907 VPBWM2R2MR20N Peaking 2.2µHAC
L910 RCiLP0263TAZZ Coil, 4.7µHAE
L911 RCiLP0264TAZZ Coil, 15µHAE
L912 VPBAM2R2M090N Peaking 2.2µHAC
L913 VPM6N100MR75N Peaking 10µHAC
L914 VPMAN100MR50N Peaking 10µHAC
L915 VPMAN100MR50N Peaking 10µHAC
L916 VPM6N100MR75N Peaking 10µHAC
L918 RCiLP0263TAZZ Coil AE
L919 RCiLP0265TAZZ Coil, 33µHAE
L920 RCiLP0265TAZZ Coil, 33µHAE
L921 RCiLP0280TAZZ Coil, 4.7µHAE
L922 RCiLP0264TAZZ Coil, 15µHAE
L924 RCiLP0264TAZZ Coil, 15µHAE
L925 RCiLP0263TAZZ Coil, 4.7µHAE
L926 RCiLP0264TAZZ Coil, 15µHAE
L927 VPBWM2R2MR20N Peaking 2.2µHAC
L928 RCiLP0283TAZZ Coil, 33µHAE
L929 VPBSM4R7MR40N Peaking 4.7µHAD
å T901 RTRNZ0135TAZZ Transformer AF
CAPACITORS
C900 RC-KZ0070TAZZ 4.716V AD
C901 VCKYCZ1CB103K 0.01 16V Ceramic AB
C902 VCKYCY1AF105Z 1 10V Ceramic AC
