Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-12
VL-PD3S/H/E
VL-PD3S/H/E
C9920 VCKYCZ1HB102K 1000p 50V Ceramic AB
C9921 VCKYCZ1HB102K 1000p 50V Ceramic AB
C9922 VCKYCZ1HB102K 1000p 50V Ceramic AB
C9923 VCKYCZ1HB102K 1000p 50V Ceramic AB
C9924 VCKYCZ1HB102K 1000p 50V Ceramic AB
C9925 VCKYCZ1HB102K 1000p 50V Ceramic AB
C9926 VCKYCZ1HB102K 1000p 50V Ceramic AB
C9927 VCKYCY1AF105Z 1 10V Ceramic AC
C9950 VCKYCZ1CB103K 0.01 16V Ceramic AB
RESISTORS
R901 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R902 VRS-CZ1JF332D 3.3k 1/16WMetal Oxide AA
R903 VRS-CZ1JF153D 15k 1/16W Metal Oxide AB
R904 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R905 VRS-CZ1JF222D 2.2k 1/16WMetal Oxide AA
R906 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R908 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R909 VRS-CZ1JF182D 1.8k 1/16WMetal Oxide AB
R910 VRS-CZ1JF822D 8.2k 1/16WMetal Oxide AA
R911 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R912 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R913 VRS-CZ1JF113D 11k 1/16W Metal Oxide AA
R914 VRS-CZ1JF823D 82k 1/16W Metal Oxide AB
R916 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R917 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R919 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R920 VRS-CZ1JF154D 150k 1/16W Metal Oxide AB
R921 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R922 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R923 VRS-CZ1JF183J 18k 1/16W Metal Oxide AA
R924 VRS-CZ1JF273J 27k 1/16W Metal Oxide AA
R925 VRS-CZ1JF393J 39k 1/16W Metal Oxide AA
R926 VRS-CZ1JF683J 68k 1/16W Metal Oxide AA
R927 VRS-CZ1JF332J 3.3k 1/16WMetal Oxide AA
R928 VRS-CZ1JF472J 4.7k 1/16WMetal Oxide AA
R929 VRS-CZ1JF562J 5.6k 1/16WMetal Oxide AA
R930 VRS-CZ1JF822J 8.2k 1/16WMetal Oxide AA
R931 VRS-CZ1JF153J 15k 1/16W Metal Oxide AA
R932 VRS-CZ1JF273J 27k 1/16W Metal Oxide AA
R933 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R934 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R935 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R936 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R965 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R966 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R971 VRS-CZ1JF333J 33k 1/16W Metal Oxide AA
R979 VRS-TV1JD821J 820 1/16W Metal Oxide AA
R985 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R986 VRS-CZ1JF473D 47k 1/16W Metal Oxide AB
R987 VRS-CZ1JF473D 47k 1/16W Metal Oxide AB
R988 VRS-CZ1JF824J 820k 1/16W Metal Oxide AA
R990 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R991 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R992 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R993 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R994 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R995 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R999 VRS-TV1JD821J 820 1/16W Metal Oxide AA
R2705 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R2707 VRS-CZ1JF392J 3.9k 1/16W Metal Oxide AA
R2710 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R2711 VRS-CZ1JF122J 1.2k 1/16W Metal Oxide AA
R2712 VRS-CZ1JF334J 330k 1/16W Metal Oxide AA
R2713 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R2721 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
R2722 VRS-CZ1JF433D 43k 1/16W Metal Oxide AA
R2730 VRS-CZ1JF563J 56k 1/16W Metal Oxide AA
R9904 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R9906 VRS-CZ1JF912D 9.1k 1/16W Metal Oxide AA
R9907 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R9908 VRS-CZ1JF273D 27k 1/16W Metal Oxide AA
R9909 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R9911 VRS-CZ1JF332D 3.3k 1/16W Metal Oxide AA
R9912 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R9914 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R9915 VRS-CZ1JF133D 13k 1/16W Metal Oxide AA
R9916 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R9917 VRS-CZ1JF393D 39k 1/16W Metal Oxide AB
R9918 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R9919 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R9920 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R9921 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R9922 VRS-CZ1JF272D 2.7k 1/16W Metal Oxide AB
R9923 VRS-CZ1JF273D 27k 1/16W Metal Oxide AA
R9924 VRS-CZ1JF203D 20k 1/16W Metal Oxide AA
R9925 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R9926 VRS-CZ1JF222D 2.2k 1/16W Metal Oxide AA
R9927 VRS-CZ1JF153D 15k 1/16W Metal Oxide AB
R9928 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R9929 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R9930 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R9931 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R9932 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R9933 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R9934 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R9935 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R9941 VRS-TV1JD561J 560 1/16W Metal Oxide AA
R9942 VRS-TV1JD561J 560 1/16W Metal Oxide AA
R9943 VRS-TV1JD561J 560 1/16W Metal Oxide AA
R9944 VRS-TV1JD561J 560 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
PSLDM9140TAZZ Shield AC
SC901 QCNCW9085TAZZ Socket, 90pin AN
SC2701 QCNCW2080TAZZ Socket, 20pin AF
SC2702 QSOCN1092TAZZ Socket, 10pin AD
DUNTK2875QA02 LCD PWB UNIT
INTEGRATED CIRCUITS
IC800 VHiMB8346BV-1 DAC AN
IC801 VHiM24C02W6-1 E
2
PROM AF
IC802 VHiiR3Y29AM-1 LCD DECODER AV
IC1800 VHiNJM2107F-1 AFC LPF AE
IC1801 VHiNJM4565V-1 COMNON AMP AF
IC1802 VHiLZ9GH23/-1 LCD CONTROLLER AP
TRANSISTORS
Q800 VS2PA1774R/-1 2PA1774R AB
Q801 VS2PA1774R/-1 2PA1774R AB
Q1800 VSUPUMZ1///-1 UPUMZ1 AC
Q5801 VSUPUMZ1///-1 UPUMZ1 AC
Q5802 VSCPH3209//-1 CPH3209 AD
Q5803 VSCPH3209//-1 CPH3209 AD
DIODES
D800 VHDHVU17TRF-1 Diode, DHVU17TRF AE
D801 VHDMA132K//-1 Diode, DMA132K AA
D1800 VHDHVC359TR-1 Diode, DHVC359TR AD
D1801 RH-EX0189TAZZ Zener Diode, EX0189TA AC
D1802 RH-EX0269TAZZ Zener Diode, EX0269TA AB
PACKAGED CIRCUITS
TH1800 VHHT1103K44-1 Thermistor AD
X800 RCRSC0152TAZZ Crystal AH
COILS AND TRANSFORMER
L800 VPBWM470K2R6N Peaking 47µHAC
L801 VPBWM470K2R6N Peaking 47µHAC
L803 VPD9M680J8R6N Peaking 68µHAC
L1800 VPBSM100KR70N Peaking 10µHAC
L1801 VPD9M1R2JR66N Peaking 1.2µHAC
L1802 VPD9M100J1R7N Peaking 10µHAC
L1803 VPBSM100KR70N Peaking 10µHAC
L5800 RCiLP0226TAZZ Coil AE
L5801 RCiLP0287TAZZ Coil AD
å T5800 RTRNZ0142TAZZ Transformer AN
