Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-13
VL-PD3S/H/E
VL-PD3S/H/E
CAPACITORS
C800 VCSATE1CJ226M 22 16V Tantalum AE
C803 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C804 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C806 VCKYCY0JB105K 1 6.3V Ceramic AC
C807 VCKYCY1CF104Z 0.1 16V Ceramic AA
C808 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C809 VCKYCY0JB105K 1 6.3V Ceramic AC
C810 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C811 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C812 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C813 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C814 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C815 VCKYCY0JB105K 1 6.3V Ceramic AC
C816 VCKYTV1AB105K 1 10V Ceramic AD
C817 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C818 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C819 VCKYCY0JB105K 1 6.3V Ceramic AC
C820 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C821 VCKYCY0JB105K 1 6.3V Ceramic AC
C822 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C823 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C824 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C825 VCCCCZ1HH6R0D 6p 50V Ceramic AA
C826 VCKYCZ1EB682K 6800p 25V Ceramic AB
C828 VCSATA1AJ335M 3.3 10V Tantalum AC
C830 VCKYCZ1CB103K 0.01 16V Ceramic AB
C831 VCKYCZ1CB103K 0.01 16V Ceramic AB
C832 VCKYCZ1CB103K 0.01 16V Ceramic AB
C833 VCCCCZ1HH390J 39p 50V Ceramic AB
C834 VCKYTV1CB474K 0.47 16V Ceramic AC
C835 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C836 VCSATN1AJ106M 10 10V Tantalum AD
C837 VCCCCZ1HH560J 56p 50V Ceramic AB
C838 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C839 VCKYCY0JB105K 1 6.3V Ceramic AC
C841 VCKYCY1CF334Z 0.33 16V Ceramic AA
C842 VCKYCZ1HB681K 680p 50V Ceramic AB
C844 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C847 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C848 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C850 VCSATE1AJ336M 33 10V Tantalum AG
C1800 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1801 VCSATE1AJ336M 33 10V Tantalum AG
C1803 VCSATE1CJ226M 22 16V Tantalum AE
C1804 VCKYCZ1HB561K 560p 50V Ceramic AC
C1805 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1806 VCKYCZ1HB102K 1000p 50V Ceramic AB
C1807 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1808 VCKYCY0JB105K 1 6.3V Ceramic AC
C1809 VCCCCZ1HH680J 68p 50V Ceramic AB
C1810 VCCCCZ1HH8R0D 8p 50V Ceramic AB
C1811 VCCCCZ1HH220J 22p 50V Ceramic AB
C1812 VCKYCZ1HB102K 1000p 50V Ceramic AB
C1813 VCKYTV1CB105K 1 16V Ceramic AC
C1814 VCCCCZ1HH560J 56p 50V Ceramic AB
C1816 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1817 VCKYCY0JB105K 1 6.3V Ceramic AC
C1818 VCSATA1DJ475M 4.7 20V Tantalum AC
C1819 VCKYCY1CF224Z 0.22 16V Ceramic AA
C1820 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1821 VCKYCY0JB105K 1 6.3V Ceramic AC
C1822 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1824 VCCCCZ1HH101J 100p 50V Ceramic AB
C1825 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1827 VCKYCY1CF104Z 0.1 16V Ceramic AA
C1829 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C1830 VCKYCZ1AB104K 0.1 10V Ceramic AB
C5800 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C5803 VCKYCZ1CB103K 0.01 16V Ceramic AB
C5804 RC-KZ0055TAZZ 3.3 10V AD
C5806 VCKYCY1HB332K 3300p 50V Ceramic AA
C5809 VCFRED1HM183J 0.018 50V AD
C5811 RC-CZ0024TAZZ 15p 2KV AE
RESISTORS
R800 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R801 VRS-CZ1JF304D 300k 1/16W Metal Oxide AA
R802 VRS-CZ1JF823J 82k 1/16W Metal Oxide AA
R803 VRS-CZ1JF823J 82k 1/16W Metal Oxide AA
R805 VRS-CZ1JF363D 36k 1/16W Metal Oxide AA
R806 VRS-CZ1JF563D 56k 1/16W Metal Oxide AA
R807 VRS-CZ1JF473D 47k 1/16W Metal Oxide AB
R808 VRS-CZ1JF393D 39k 1/16W Metal Oxide AB
R811 VRS-CZ1JF392J 3.9k 1/16WMetal Oxide AA
R813 VRS-CZ1JF563D 56k 1/16W Metal Oxide AA
R814 VRS-CZ1JF153D 15k 1/16W Metal Oxide AB
R815 VRS-CZ1JF333D 33k 1/16W Metal Oxide AB
R816 VRS-CZ1JF273D 27k 1/16W Metal Oxide AA
R821 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R822 VRS-CZ1JF124D 120k 1/16W Metal Oxide AA
R824 VRS-CZ1JF223D 22k 1/16W Metal Oxide AB
R825 VRS-CZ1JF163D 16k 1/16W Metal Oxide AA
R827 VRS-CZ1JF122D 1.2k 1/16WMetal Oxide AB
R829 VRS-CZ1JF183D 18k 1/16W Metal Oxide AB
R832 VRS-CZ1JF184J 180k 1/16W Metal Oxide AA
R835 VRS-CZ1JF334J 330k 1/16W Metal Oxide AA
R838 VRS-CZ1JF562D 5.6k 1/16WMetal Oxide AB
R841 VRS-CZ1JF273D 27k 1/16W Metal Oxide AA
R842 VRS-CZ1JF562J 5.6k 1/16WMetal Oxide AA
R843 VRS-CZ1JF393D 39k 1/16W Metal Oxide AB
R844 VRS-CZ1JF822J 8.2k 1/16WMetal Oxide AA
R845 VRS-CZ1JF223D 22k 1/16W Metal Oxide AB
R846 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R847 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R849 VRS-CY1JF106J 10M 1/16W Metal Oxide AA
R850 VRS-CZ1JF274J 270k 1/16W Metal Oxide AA
R852 VRS-CZ1JF363D 36k 1/16W Metal Oxide AA
R853 VRS-CZ1JF563J 56k 1/16W Metal Oxide AA
R854 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R855 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R857 VRS-CZ1JF273J 27k 1/16W Metal Oxide AA
R858 VRS-CZ1JF393D 39k 1/16W Metal Oxide AB
R859 VRS-CZ1JF683D 68k 1/16W Metal Oxide AB
R860 VRS-CZ1JF563J 56k 1/16W Metal Oxide AA
R861 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R862 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R870 VRS-CZ1JF182J 1.8k 1/16WMetal Oxide AA
R871 VRS-CZ1JF332J 3.3k 1/16WMetal Oxide AA
R1800 VRS-CZ1JF562D 5.6k 1/16W Metal Oxide AB
R1801 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
R1802 VRS-CZ1JF473J 47k 1/16W Metal Oxide AA
R1803 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
R1804 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
R1805 VRS-CZ1JF683J 68k 1/16W Metal Oxide AA
R1806 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R1807 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R1808 VRS-CZ1JF272D 2.7k 1/16W Metal Oxide AB
R1809 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R1810 VRS-CZ1JF683J 68k 1/16W Metal Oxide AA
R1812 VRS-CZ1JF223J 22k 1/16W Metal Oxide AA
R1813 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R1814 VRS-CZ1JF564J 560k 1/16W Metal Oxide AA
R1815 VRS-CZ1JF564J 560k 1/16W Metal Oxide AA
R1816 VRS-CZ1JF470J 47 1/16WMetal Oxide AA
R1817 VRS-CZ1JF105J 1M 1/16W Metal Oxide AA
R1818 VRS-CZ1JF471J 470 1/16W Metal Oxide AA
R1819 VRS-CZ1JF273D 27k 1/16W Metal Oxide AA
R1822 VRS-CZ1JF821J 820 1/16W Metal Oxide AA
R1823 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R1824 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R1826 VRS-CZ1JF393J 39k 1/16W Metal Oxide AA
R1827 VRS-CZ1JF393J 39k 1/16W Metal Oxide AA
R1828 VRS-CZ1JF104D 100k 1/16W Metal Oxide AB
R1830 VRS-CZ1JF471J 470 1/16W Metal Oxide AA
R1832 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R1835 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R1836 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R1837 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R1838 VRS-CZ1JF153J 15k 1/16W Metal Oxide AA
