Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-14
VL-PD3S/H/E
VL-PD3S/H/E
R1840 VRS-CZ1JF393J 39k 1/16W Metal Oxide AA
R1841 VRS-CZ1JF474J 470k 1/16W Metal Oxide AA
R1842 VRS-CZ1JF104J 100k 1/16W Metal Oxide AA
R1843 VRS-CZ1JF512J 5.1k 1/16W Metal Oxide AB
R1844 VRS-CZ1JF224J 220k 1/16W Metal Oxide AA
R1845 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R1846 VRS-CZ1JF363D 36k 1/16W Metal Oxide AA
R1847 VRS-CZ1JF564J 560k 1/16W Metal Oxide AA
R1848 VRS-CZ1JF124J 120k 1/16W Metal Oxide AA
R1849 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R1850 VRS-CZ1JF333J 33k 1/16W Metal Oxide AA
R1854 VRS-CZ1JF273D 27k 1/16W Metal Oxide AA
R1855 VRS-CZ1JF183D 18k 1/16W Metal Oxide AB
R1856 VRS-CZ1JF100J 10 1/16WMetal Oxide AA
R1857 VRS-CZ1JF471J 470 1/16W Metal Oxide AA
R1858 VRS-CZ1JF561J 560 1/16W Metal Oxide AA
R1859 VRS-CZ1JF331J 330 1/16W Metal Oxide AA
R5803 VRS-CZ1JF103D 10k 1/16W Metal Oxide AB
R5807 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R5808 VRS-CZ1JF182D 1.8k 1/16W Metal Oxide AB
R5810 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R5811 VRS-CZ1JF152J 1.5k 1/16W Metal Oxide AA
R5812 VRS-CZ1JF271D 270 1/16W Metal Oxide AB
R5813 VRS-CZ1JF271D 270 1/16W Metal Oxide AB
MISCELLANEOUS PARTS
SC800 QSOCN1092TAZZ Socket AD
SC801 QSOCN1092TAZZ Socket AD
SC802 QSOCN1092TAZZ Socket AD
SC1800 QSOCN2492TAZZ Socket, 24pin AE
SC5800 QSOCN0412TAN1 Socket, 4pin AF
RAMP-0028TAN1 HEAD AMP UNIT
INTEGRATED CIRCUITS
IC301 VHiBH7275KV-1 H/A IC AU
IC302 VHiS24C04A/-1 E
2
PROM AL
or
VHiXL24C04F-1 AK
or
VHiST25C4M6-1 AL
TRANSISTORS
Q302 VS2SC4738Y/-1 Transistor AA
or
VS2SC4617B/-1 Transistor AA
Q303 VS2SC4738Y/-1 Transistor AA
or
VS2SC4617B/-1 Transistor AA
COILS
L301 VPAWM4R7MR70N 4.7µHAC
L303 VPAWM4R7MR70N 4.7µHAC
CAPACITORS
C301 VCKYCZ1HB102K 1000p 50V Ceramic AB
C302 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C303 VCSATE1AJ336M 33 10V Tantalum AG
C304 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C305 VCCCCY1HH331J 330p 50V Ceramic AA
C306 VCKYCZ1HB102K 1000p 50V Ceramic AB
C307 VCCCCY1HH331J 330p 50V Ceramic AA
C308 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C309 VCKYCZ1HB102K 1000p 50V Ceramic AB
C310 VCKYCY1AF105Z 1 10V Ceramic AC
C311 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C312 VCKYCZ1HB102K 1000p 50V Ceramic AB
C313 VCKYCZ1HB102K 1000p 50V Ceramic AB
C314 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C315 VCKYCZ1HB102K 1000p 50V Ceramic AB
C318 VCKYCZ1HB102K 1000p 50V Ceramic AB
C319 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C320 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C321 VCKYCZ1HB102K 1000p 50V Ceramic AB
C322 VCKYCY0JB105K 1 22V Ceramic AC
C323 VCKYCZ1HB102K 1000p 50V Ceramic AB
C324 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C325 VCSATE1AJ336M 33 10V Tantalum AG
C326 VCCCCZ1HH101J 100p 50V Ceramic AB
C327 VCKYCZ1EB472K 4700P 25V Ceramic AB
C329 VCSATA1AJ106M 10 10V Tantalum AC
C330 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C331 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C332 VCKYCZ1EB472K 4700p 25V Ceramic AB
C333 VCKYCZ1CB822K 8200p 16V Ceramic AB
C340 VCCCCZ1HH5R0C 5p 50V Ceramic AC
C342 VCCCCZ1HH5R0C 5p 50V Ceramic AC
C343 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C344 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C345 VCKYCZ1AF104Z 0.1 10V Ceramic AB
RESISTORS
R304 VRS-CZ1JF222J 2.2k 1/16WMetal Oxide AA
R308 VRS-CZ1JF122J 1.2k 1/16WMetal Oxide AA
R309 VRS-CZ1JF392J 3.9k 1/16WMetal Oxide AA
R310 VRS-CZ1JF433J 43k 1/16W Metal Oxide AA
R311 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R312 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R313 VRS-CZ1JF153J 15k 1/16W Metal Oxide AA
R314 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R315 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R316 VRS-CZ1JF823J 82k 1/16W Metal Oxide AA
R317 VRS-CZ1JF563J 56k 1/16W Metal Oxide AA
R318 VRS-CZ1JF563J 56k 1/16W Metal Oxide AA
R319 VRS-CZ1JF182J 1.8k 1/16WMetal Oxide AA
R320 VRS-CZ1JF182J 1.8k 1/16WMetal Oxide AA
R321 VRS-CZ1JF682J 6.8k 1/16WMetal Oxide AA
R323 VRS-CZ1JF123J 12k 1/16W Metal Oxide AA
R324 VRS-CZ1JF222J 2.2k 1/16WMetal Oxide AA
R325 VRS-CZ1JF472J 4.7k 1/16WMetal Oxide AA
R327 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R328 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R330 VRS-CZ1JF563J 56k 1/16W Metal Oxide AA
R332 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R333 VRS-CZ1JF222J 2.2k 1/16WMetal Oxide AA
R376 VRS-CZ1JF000J 0 1/16WMetal Oxide AA
R377 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R380 VRS-TV1JD100J 10k 1/16W Metal Oxide AA
CONNECTORS
P306 QCNCM8082TAZZ (B TO B) 80pin AK
SC301 QSOCN0806TAN1 (L.M FPC) 8pin AL
SC302 QSOCN0606TAN1 (MODE SW FPC) 6pin AK
SC303 QSOCN1005TAN1 (DRUM FPC) 10pin AF
SC304 QSOCN0705TAN1 (H/A FPC) 7pin AK
SC305 QSOCN1887TAZZ (MECHA SFNS FPC)18pin AD
SC306 QSOCN1886TAZZ (CAP M FPC) 18pin AD
RUNTK0341TAZZ JOINT PWB UNIT
P2006 QPLGN0276TAZZ CONNECTOR, 2pin AD
P2009 QPLGN0276TAZZ CONNECTOR, 2pin AD
P2008 QPLGN0376TAZZ CONNECTOR, 3pin AD
P2010 QPLGN0476TAZZ CONNECTOR, 4pin AD
SC2001 QSOCN2887TAZZ CONNECTOR, 28pin AE
SC2002 QSOCN2887TAZZ CONNECTOR, 28pin AE
SC2003 QSOCN1087TAZZ CONNECTOR, 10pin AC
SC2004 QSOCN1087TAZZ CONNECTOR, 10pin AC
SC2005 QSOCN1087TAZZ CONNECTOR, 10pin AC
SC2007 QSOCN0560TAZZ CONNECTOR, 5pin AC
SC2011 QCNCW1481TAZZ CONNECTOR, 14pin AE
SW2001 QSW-M0047GEZZ Switch AE
QTANS9000TAFW Lithium Battery (+)
QTANS9004TAFW Lithium Battery (-)
