Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-15
VL-PD3S/H/E
VL-PD3S/H/E
392 MSPRT0418GEFJ T Arm SPR. AB
393 MSPRD0178GEFJ Tu Guide Arm SPR. AB
394 MSPRD0179GEFJ Pinch Lever Return SPR. AB
395 MSPRD0180GEFJ S Pressure SPR. AB
396 MSPRD0181GEFJ Tu Pressure SPR. AB
397 MSPRC0220GEFJ Guide Adjustment SPR. AA
398 MSPRC0221GEFJ Drum Fixing SPR. AA
399 MSPRP0185GEZZ PB Guide SPR. AC
401 LX-WZ1071GE02 CW ø 0.7 ø 1.8t0.1 AC
402 LX-WZ1104GE06 CW ø 0.7 ø 2.2t0.25 AB
403 LX-WZ1029GE00 CW ø 1.2 ø 3.0t0.25 AA
411 LZ-WZ1105GE00 W ø 1.2 ø 2.5t0.13 AA
412 LZ-WZ1106GE00 W ø 1.2 ø 2.5t0.2 AA
413 XWHJZ12-03025 W ø 1.2 ø 2.5t0.3 AA
414 XWHJZ12-04025 W ø 1.2 ø 2.5t0.4 AA
415 XWHJZ12-05025 W ø 1.2 ø 2.5t0.5 AA
420 LX-BZ3202GEFF Swing Arm Release AC
Lever Fixing Screw
421 LHLDZ2025GEZZ Intermediate Gear Stopper AB
429 LX-BZ3203GEFF Type 1 Minuteness AB
Screw M1.4 x L1
430 LX-BZ3185GEFN Screw M1.4 x L2 AB
431 LX-BZ3135GEFF Screw M1.4 x L1 AA
432 LX-BZ3201GEFF Special Head AB
Screw M1.4 x L2
433 LX-BZ3132GEFF Special Head AA
Screw M1.4 x L1.5
434 LX-BZ3131GEFN Screw M1.4 x L1.6 AA
435 LX-HZ3089GEFF S Tight Screw M1.4 x L2 AA
436 LX-HZ3076GEFF S Tight Screw M1.4 x L3 AA
437 LX-HZ3088GEFF L Motor Installation AB
Screw
438 LX-BZ3093GEZZ Drum Installation Screw AC
439 LX-BZ3181GEFN GR Lock Screw AD
440 LX-HZ3084GEFF S Tight Screw M1.4 x L4 AC
441 QPWBH5517GEZZ Mode FPC AF
451 LPOLM0065GEZZ Sup Pole Base Ass’y AK
452 LPOLM0066GEZZ Tu Pole Base Ass’y AK
453 CGiDM0158GE01 Drum Base Ass’y AN
454 NROLM0046GEZZ Guide Roller Ass’y AM
455 NROLM0045GEZZ T Roller Ass’y AK
456 NDAiV1076GEZZ S Reel Base Ass’y AM
457 NDAiV1077GEZZ Tu Reel Base Ass’y AK
458 MLEVF0515GEZZ Pinch Lever Ass’y AP
459 NBLTT0016GEZZ Timing Belt AD
461 RMOTM1080GEZZ L Motor Ass’y AQ
462 RMOTV1023GEZZ Capstan Motor AY
463 QSW-R0039GEZZ Mode SW AE
470 DDRMV0061HE01 Drum Ass’y BZ
500 RAMP-0028TAN1 Head Amplifier —
PWB Unit
501 PSLDM3338TAFW H/A FPC Shild Plate AC
CASSETTE CONTROL PARTS
600 CHLDX3082GE02 Cassette Control Ass’y
(PD3H/E)
600 CHLDX3082GE03 Cassette Control Ass’y
(PD3S)
601 LHLDX3082GEZZ Housing Ass’y AS
604 MLEVF0524GEZZ Top Cover Ass’y AP
606 LANGF9617GEZZ Side Board Ass’y AG
607 MSPRB0001GEFJ UP-Spring AD
608 LX-BZ3089GEZZ Screw M1.4 x L2
609 PDMP-0016GEZZ Damper AE
610 TLABH0557GEZZ Cassette Control Lock AD
Label
611 TLABH0556GEZZ Cassette Control Caution AD
Label
614 ZTAPEZ211004M FPC Shield Tape AB
615 PMLT-0112GEZZ Cassette Control Spacer
(PD3S only)
MECHANISM PARTS
DMECV0063GE08 Mechanism Ass'y(PD3H/E) –
DMECV0063GE09 Mechanism Ass'y(PD3S) –
301 LCHSM0167GEZZ Main Chassis Ass’y AQ
302 MLEVF0501GEFW Eject Lever AD
303 MLEVF0502GEFW Pinch Control Lever Ass’y AD
304 NGERH3050GEFW Main Cam AD
305 MLEVF0503GEZZ Shifter Drive Lever Ass’y AE
306 MLEVF0505GEFW Loading Lever Ass’y AD
307 MARMM0130GEZZ S Loading Arm Ass’y AF
308 MARMM0131GEZZ Tu Loading Arm Ass’y AF
309 MLEVF0508GEFW T Arm Control Lever AD
310 MLEVF0509GEFW AHC Control Lever AC
311 LANGG9106GEFW Tu Guide Cam AD
312 LANGF9016GEZZ Intermediate Gear AG
ANG Ass’y
313 MARMM0132GEZZ Swing Arm Ass’y AG
314 CANGJ0037GE01 Mechanism Fixing Angle AG
Ass’y
321 LANGQ1044GEZZ Down SW-ANG Ass’y AE
322 QPWBH5516GEZZ Dew Sensor FPC AH
323 QSW-M0016TAZZ Down SW AD
324 RDTCH0039GEZZ Dew Sensor AD
330 CCHSS0047GE01 Slide Chassis Ass’y with BC
FPC Sensor
331 LCHSS0047GEZZ Slide Chassis Ass’y AQ
332 CPWBH5515GE01 Sensor FPC Ass’y AX
333 QPWBH5515GEZZ Sensor FPC AP
334 LHLDP1174GEZZ S-LED Holder AC
335 LHLDP1175GEZZ Tu-LED Holder AC
336 PGiDM0157GEZZ Lid Opener AB
337 LHLDZ2023GEZZ Sensor FPC Guide AB
338 QSW-M0047GEZZ Recognition SW AE
339 QTANZ0003GEZZ Mic Contact AE
340 RH-PX0180TAZZ Cassette LED AE
341 RH-PX0181TAZZ S/E Sensor AF
342 RDTCM0002TAZZ Reel Sensor AE
343 PSHEP0015GEZZ Sensor FPC Reinforcing AB
Plate
351 MLEVF0510GEZZ Tension Arm Ass’y AG
352 MLEVF0511GEZZ Tu Guide Arm Ass’y AG
353 MLEVF0512GEZZ Brake Shifter Ass’y AE
354 LBNDK3022GEZZ Tension Band Ass’y AF
355 LANGA0073GEZZ Reel Cover Ass’y AG
356 LANGJ0038GEFW T Spring Hanging ANG AC
357 MLEVP0302GEZZ Swing Arm Release Lever AC
361 MLEVP0296GEZZ Pinch Drive Lever AB
362 PGiDM0156GEZZ Guide Rail AC
363 MLEVP0297GEZZ AHC Ass’y AF
364 NGERH1300GEZZ Intermediate Gear A Ass’y AE
365 NGERH1301GEZZ Intermediate Gear B Ass’y AB
366 NPLYV0164GEZZ Intermediate Pulley Ass’y AC
367 NPLYV0165GEZZ Center Pulley Ass’y AC
368 PCOVP1024GEZZ Down SW Cover AB
369 NGERH1302GEZZ AHC Cam AB
370 NGERH1303GEZZ Coupling Gear AB
371 NGERH1304GEZZ Sub Cam AC
372 NGERH1305GEZZ S Loading Gear AC
373 NGERH1306GEZZ Tu Loading Gear AC
374 MLEVP0298GEZZ S Main Brake AB
375 MLEVP0299GEZZ Tu Main Brake AB
376 LHLDX1033GEZZ S Cassette Stay AB
377 LHLDZ2024GEZZ FPC Cover AB
378 PGiDM0166GEZZ SL Chassis Holder-S AC
379 PGiDM0167GEZZ Lock Lever Guide AC
381 PGiDP0031GEFW Tu Pole AD
382 PGiDS0046GEFW T Roller Upper Flange AE
383 PGiDS0047GEFW T Roller Bottom Flange AE
384 NSFTL0761GEFW T Roller Inner AE
385 PGiDP0042GEFW S Guide Sleeve AD
386 PGiDM0170GEZZ Slide Chassis Guide AC
390 MSPRD0184GEFJ Swing Arm Release SPR. AC
391 MSPRT0417GEFJ Main Brake SPR. AB
