Sharp VL-PD3S User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
16-16
VL-PD3S/H/E
VL-PD3S/H/E
4-9 TLABZ0474TAZZ Special Merit Label A AH
5 DCOVA1601TAK1 K.S. Front Cover(PD3S/H) BB
5 DCOVA1601TAK2 K.S. Front Cover(PD3E)
5-1-2 GCOVA1590TAZZ R/C Catch Light Cover
5-1-3 PFLT-0026TAZZ Microphone Spacer AC
5-1-4 HDECA0701TASA Microphone Grille(PD3S/H) AP
5-1-4 HDECA0701TASB Microphone Grille(PD3E)
5-1-5 HiNDP0207TASA Terminal Plate
5-1-6 GCOVA1591TAKA Terminal Cover(PD3S/H) AH
5-1-6 GCOVA1591TAKB Terminal Cover(PD3E)
5-1-7 HBDGB0061TASA SHARP Badge AG
5-1-8 HiNDP0203TASA Lens Plate AD
5-1-9 LHLDZ1493TAZZ Terminal Cover Belt
5-1-10 GCOVA3068TASA Lens Hood
5-1-11 PFLT-0027TAZZ Microphone Grille Felt AA
5-1-12 QEARP0253TAZZ Front Cover Earth Sheet AB
5-2 PMLT-0177TAZZ Microphone Sound AC
Insulation Sheet
5-3 LHLDZ1491TAZZ Microphone Holder Front AD
5-4 LHLDZ1492TAZZ Microphone Holder Rear AD
5-5 RMiCC0083TAZZ Microphone Unit AR
5-6 PMLT-0176TAZZ Microphone Molt AB
5-9 PMLT-0179TAZZ Microphone Grille Molt AB
5-10 QEARP0256TAZZ Front Cover Earth Sheet B
6-1 DCOVA1600TAK1 K.S. Battery Cover Service AZ
6-1-2 HiNDP0204TASA Battery Plate AD
6-1-3 JBTN-0302TASA S/S Button AH
6-1-4 JBTN-0303TASA Still Button AG
6-1-5 JBTN-0304TASA Power Lock Button AD
6-1-6 JKNBP0173TASA Battery Lock Pinch AE
6-1-7 JKNBP0174TASA Power Lock Pinch AG
6-1-8 LHLDZ1494TAZZ Power Lock Button Holder AD
6-1-9 LHLDZ1498TAZZ Battery Lock Pinch Holder AD
6-1-10 MLEVP0041TASA Battery Lock AD
6-1-11 MSPRC0121TAFJ Battery Lock Spring AB
6-1-12 MSPRC0122TAFJ Power Lock Spring AB
6-1-13 PSHEP0113TAZZ Battery Guide Hole AC
Cover U
6-1-14 PSHEP0114TAZZ Battery Guide Hole AC
Cover D
6-2 LANGK0472TAFW Cover Fixing Angle
6-3 QSW-Z0312TAZZ Power Switch Unit AR
6-4 QTANZ0136TAZZ Battery Terminal Unit AR
12 RUNTK0341TAZZ Joint PWB Unit AU
13 RUNTK0343TAZZ Remote Control Receiver AM
Unit
22 GCOVA1603TAKA LCD Front Cover
23-1 CLNSA0135TA01 Lens Unit BS
23-2 JKNBP0172TASA Jog Pinch AG
23-3 LANGK0451TAFW Lens Setting Angle AE
23-4 LHLDZ1490TAZZ Jog Switch Holder AD
24 CCOVH1241TAK3 K.S. Adjust Connection AH
Cover(PD3S/H)
24 CCOVH1241TAK4 K.S. Adjust Connection
Cover(PD3E)
24-2 PSPAZ0262TAZZ LCD Under Rubber AA
25 GCOVH1216TASD Lens Cap(PD3S/H) AL
25 GCOVH1216TASC Lens Cap(PD3E) AL
26 TLABM1908TAZZ Model Label(PD3S) AD
26 TLABM1942TAZZ Model Label(PD3H)
26 TLABM1943TAZZ Model Label(PD3E)
26 TLABM1944TAZZ Model Label(PD3EW)
26 TLABM1945TAZZ Model Label(PD3EX)
27-1 DUNTK2871PM02 Main1 PWB Unit(PD3S) –
27-1 DUNTK2871PM03 Main1 PWB Unit(PD3H) –
27-1 DUNTK2871PM04 Main1 PWB Unit –
(PD3E/EW/EX)
27-2 DUNTK2872PM02 Main2 PWB Unit(PD3S) –
27-2 DUNTK2872PM03 Main2 PWB Unit(PD3H) –
27-2 DUNTK2872PM04 Main2 PWB Unit –
(PD3E/EW/EX)
27-3 DUNTK2874PM01 Power PWB Unit –
28 DUNTK2875QA02 LCD PWB Unit –
29 CCOVA1602TAK1 Top Side Cover(PD3S)
29 CCOVA1599TAK3 Top Side Cover(PD3H)
CABINET PARTS LIST
1-1 DCABA6201TAK2 K.S. Cabinet Ass'y BD
1-1-2 LANGK0444TAFW L.L. Angle AE
1-1-3 LANGK0445TA00 Angle for Handstrap.F AF
1-1-4 LANGK0473TA00 Angle for Handstrap.R
1-1-5 LSTYM0031TAZZ Stay.F.Ass'y AQ
1-1-6 LSTYM0032TAZZ Stay.R.Ass'y AM
1-1-7 PSHEP0109TAZZ Zoom FPC Guide AC
1-1-8 PSPAG0124TA00 Floating Rubber AC
1-1-9 UBNDT0124TASA Handstrap AW
1-1-11 PMLT-0180TAZZ Sound Insulation Sheet AA
1-2 GFTAC3006TASA Cassette Lid BE
1-3 HiNDP0201TASA Cassette Lid Plate AD
1-4 JKNBP0171TASA Open Pinch AD
1-5 LANGK0447TAZZ Cassette Lid Lock Ass'y AM
1-6 LHLDZ1488TA00 Open Button Holder
1-7 PMLT-0172TAZZ Cassette Lid Spacer A AB
1-8 PMLT-0173TAZZ Cassette Lid Spacer B AB
1-9 PSHEP0105TAZZ Zoom FPC Cover AE
1-10 QSW-Z0309TAZZ Eject Switch AG
1-11 QSW-Z0310TAZZ Zoom Unit AT
1-12 TLABH0393TAZZ Eject Caution Label AB
1-13 LHLDZ1505TA00 Lid Lock Holder AD
(since about 5001camcorders)
2-1 DCABB6203TAK1 K.S. Cabinet B Service
(PD3S/H)
2-1 DCABB6203TAK2 K.S. Cabinet B Service AY
(PD3E)
2-1-2 JBTN-0305TASA Menu, Gamma Button
2-1-3 PSHEP0117TAZZ Tilt Section Blind Sheet AC
2-1-4 PSPAZ0262TAZZ Rubber for LCD AA
2-1-5 TLABH0386TAZZ Lithium Battery Label AC
2-2 LANGQ0209TAFW RS232C Fixing Metal AF
2-3 LHLDZ1489TAZZ Speaker Holder AD
2-4 QSW-Z0311TAZZ Operation Button Unit AT
2-5 QSW-Z0321TAZZ Menu, Gamma Switch AK
2-6 RUNTK0342TAZZ RS232C Unit AL
2-7 VSP0020P-A18E Speaker Unit AL
2-8 PCOVP9070TAZZ Wire Cover AC
3-1 CLNSV0008TA01 V/F Lens Unit AM
3-2 CCOVA1596TAK2 V/F Cover UP(PD3S/H) AR
3-2 CCOVA1596TAK4 V/F Cover UP(PD3E)
3-2-2 TLABZ0478TAZZ Special Merit Label C AH
3-3 GCOVA1597TAKA V/F Cover Low(PD3S/H) AN
3-3 GCOVA1597TAKB V/F Cover Low(PD3E)
3-4 GCOVD1006TAZZ V/F LCD Protection Cover AH
3-5 GCOVH1240TAZZ V/F LCD Back Cover AD
3-6 GCOVH1242TAZZ V/F Front Cover Unit AM
3-7 GCOVH7067TA00 Eye Cap AF
3-8 JKNBZ0072TASA Visibility Control Button AD
3-9 KLMPV0042TAZZ V/F Back Light BB
3-10 LANGK0443TAZZ V/F Tilt Unit AW
3-11 LANGK0452TAZZ V/F Slide Angle Unit AV
3-12 LHLDZ1497TAZZ V/F LCD Invertor Holder AD
3-13 MSPRP0192TAFW Visibility Control Plate AB
Spring
3-14 PSPAG0122TAZZ V/F LCD Spacer AD
3-15 PSPAZ0271TAZZ V/F Angle Sheet AC
3-16 PSPAZ0272TAZZ V/F Shade Sheet AA
3-17 PSPAZ0273TAZZ V/F FPC Sheet AB
3-18 RLCDV0046TAZZ V/F LCD BP
3-19 PSPAG0123TAZZ V/F Back Light Spacer AD
3-20 PSPAZ0266TAZZ V/F Invertor Holder Sheet AA
4 CCABE6042TAK1 K.S. LCD Cabinet(PD3S/H) AX
4 CCABE6042TAK2 K.S. LCD Cabinet(PD3E) AX
4-2 HBDGB0053TASA SHARP Badge AF
4-3 JBTN-0301TASA LCD Lock Lever AD
4-4 LANGK0464TAFW Plate Nut AD
4-5 LX-HZ0072TAFF Screw for LCD Lock AB
(Since 2000 Camcorders)
4-6 MSPRD0061TAFJ LCD Lock Spring AC
4-7 PSHEP0107TAZZ Shade Sheet AB
4-8 PZETV0403TAZZ Insulate Tape AA
