Sharp XG-MB70X Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
116
XG-MB70X
CABINET AND MECHANICAL PARTS
1 Not Available -Top Body Ass'y Unit —
1-1 DBDYTA072WJF0 J Top Body Ass'y BB
1-2 GCOVAA947WJKA J Lens Upper Cover AF
1-3 GCOVAA948WJSA J R/C Cover Front AE
1-4 PFiLDA015WJZZ J R/C Filter AD
1-5 XEBSN30P12000 J Screew, x2 AA
2 Not Available - Bottom Body Ass'y Unit —
2-1 DBDYUA092WJF0 J Bottom Body Ass'y BA
2-1-1 Not Available - Bottom Body —
2-1-2 LANGFA025WJFW J Kensington Angle AC
2-1-3 LX-NZ3120CEFW J Nut M5_R AB
2-1-4 LX-NZ3122CEFW J Nut M5_L AC
2-1-5 LX-NZ3144CEFW J Nut (for Lamp Door) AC
2-1-6 Not Available -Teflon Tape —
2-2 CDORUA023WJF0 J Lamp Door Ass'y AR
2-2-1 Not Available - Lamp Door Ass'y —
2-2-2 LX-BZ1009CEFN J Screw AE
2-2-3 MSPRC0023SEFW J Spring AB
2-2-4 XRESJ30-06000 J E-Ring AA
2-2-5 Not Available -Teflon Tape —
2-3 GCOVAA299WJSA J R/C Cover AD
2-4 GLEGPA029WJKA J Adjuster (Front) BA
2-5 GLEGPA030WJSA J Adjuster (R_R) AK
2-6 GLEGPA031WJSA J Adjuster (R_L) AK
2-7 LANGFA113WJFW J Bracket A AE
2-8 LANGFA114WJFW J Bracket B AF
2-9 LHLDZA416WJKZ J Adjuster Holder AF
2-10 LX-BZA067WJFN J Screw, x4 AB
2-11 LX-HZ3105CEFN J Screw x2 AB
2-12 LX-NZ3095CEFN J Cap Nut R (M5) AB
2-13 LX-NZ3123CEF9 J Cap Nut L (M5) AD
2-14 LX-NZA003WJFW J Nut, x4 AD
2-15 PSPAH0648CE00 J Ajuster Spacer, x2 AB
2-16 QEARPA134WJFW J Earth Plate AL
2-17 XEBSN30P12000 J Screw, x6 AA
3 Not Available - Speaker Holder Ass'y —
3-1 DBFL-A017WJF0 J Speaker Holder Ass'y AK
3-1-1 Not Available - Speaker Holder —
3-1-2 Not Available -Teflon Tape —
3-2 LANGSA006WJFW J Speaker Bracket, x2 AD
3-3 RSP-ZA085WJQZ J Speaker AP
3-4 XEBSN20P06000 J Screw, x2 (Speaker Bracket) AA
3-5 PSPAHA464WJZZ J Speaker Holder Sheet AE
4Refer to the OPTICAL MECHANISM PARTS
23 DUNTKC612WEF0 - MAIN Unit —
23-1 LX-BZ3266CEFN J Screw, x4 AB
23-2 PCOVUA044WJ00 J Light Shield AE
23-3 PSLDMA441WJFW J Terminal Shield AM
25 DUNTKC615WEF0 - FRONT R/C Unit —
26 DUNTKC681WEF0 - REAR R/C Unit —
27 RDENCA082WJZZ - POWER SUPPLY Unit —
28 RDENCA088WJZZ J BALLAST Unit CE
29 RUNTKA090WJZZ J CMOS CAMERA Unit BS
30 JBTN-A328WJKA J Adjuster Button AH
31 LANGKA329WJFW J Switch Bracket AF
32 LANGKA357WJFW J L-Socket Angle AC
33 LHLDWA032WJZZ J EDG Saddle AD
35 LHLDZA409WJKZ J A/F Holder A AF
36 LHLDZA410WJKZ J A/F Holder B AE
37 LX-BZA085WJF7 J Screw, x4 AB
40 PCAPHA021WJSA J Lens Cap AL
41 PDUC-A056WJKZ J Duct AH
45 PSHEPA232WJZZ J Power SLD Sheet AG
46 PSLDCA019WJFW J CCD Shield AD
47 PSLDMA442WJFW J Ballast Shield AP
50 PZETKA098WJKZ J Ballast Insulator AS
51 PZETKA110WJKZ J R/C Insulator AC
52 QCNW-C667WJPZ J Connecting Wire AH
53 QCNW-C671WJPZ J Power SW Wire (PA) AZ
54 QCNW-C939WJPZ J Connecting Wire AC
57 XBBSN30P08000 J Screw, x6 AA
60 XBPSN40P08JS0 J Screw AC
61 XEBSN30P12000 J Screw, x20 AA
62 XEBSN30P08000 J Screw AA
