Page #90 background imageLoading...
Page #90 background image
87109654321
A
B
C
D
E
F
G
H
90
XG-MB70X
OVERALL WIRING DIAGRAM / GESAMTSCHALTPLAN
COLOR WHEEL
CFILWA080WJ01
ZOOM/FOCUS MOTOR
RMOTBA005WJZZ
LAMP FAN
SPEAKER IRIS MOTOR NFANSA017WJZZ THERMA
RSP-ZA085WJQZ RMOTBA006WJZZ QCNW-D
CMOS CAMERA UNIT
RUNTKA090WJZZ
QCNW-C720WJQZ
P1708
P1707
LAMP
CLMPFA017WEF0
CN2 CN1
EA701
EA702
AC CORD
P1101
P3503 SC5001 SC2502P1705P1704P3552P3551
BALLAST UNIT
RDENCA088WJZZ
POWER UNIT
RDENCA082WJZZ
BC
MAIN UNIT
DUNTKC612WEF0
QACCDA010WJPZ A3KVMB70XU
QACCVA011WJPZ A3KVMB70XE/XD
QACCBA036WJPZ A3KVMB70XH/XK/XM
QACCLA018WJPZ A3KVMB70XX
QACCJA010WJPZ A3KVMB70XJ
DD
CW
EA
FOCUS
MOTOR
ZOOM
MOTOR
IRIS
MOTOR
TF
AZAI
SO
FD
PHOTO SENSOR UNIT
RUNTKA091WJZZ
CW
