Sharp XG-MB70X Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
118
XG-MB70X
OPTICAL MECHANISM PARTS
4 CCHSKA016WJ01 J Optical mechanism Ass'y EC
4-1 LCHSKA016WJFW J Frame BP
4-2-1 LX-EZA018WJFN J Screw, x4 AC
4-2-2 PCOVPA024WJSA J Focus Ring AY
4-2-3 PLNS-A046WJZZ J Projection Lens CT
4-2-4 RMOTBA005WJZZ J Focus/ Zoom Motor BS
4-3 CFiLWA080WJ01 J Color Wheel CD
4-4 LANGKA291WJFW J C/W Angle AM
4-5 LANGKA404WJFW J Sensor Bracket AH
4-6 LANGKA407WJFW J Hold Plate AX
4-7 LANGKA408WJFW J Frame Plate AX
4-8 LHLDZA389WJFW J LH Holder AQ
4-9 LHLDZA517WJFW J Mirror Holder C AX
4-10 LHLDZA518WJFW J FL Holder BB
4-11 LX-AZA001WJ00 J Screw, x4 AC
4-12 LX-BZA090WJF9 J Screw, x8 AX
4-13 LX-EZA019WJFN J Screw, x3 AD
4-14 LX-WZA026WJFN J Washer, Mirror Holder AX
4-15 MSPRCA057WJZZ J Spring BA
4-16 MSPRPA041WJFW J FL Spring AT
4-17 NFANRA034WJZZ J Exhaust Fan 2 BG
4-18 NFANRA035WJZZ J Exhaust Fan 1 BG
4-19 NFANSA017WJZZ J Lamp Fan BG
4-20 PCOVMA018WJFW J Dust Cover B AK
4-21 PCOVZA038WJFW J Frame Cover L AR
4-22 PCOVZA039WJFW J C/W Cover AR
4-23 PCOVZA040WJKZ J Lamp House BG
4-24 PCOVZA044WJFW J Frame Plate AM
4-25 PCOVZA049WJKZ J Exhaust Fan Sheet AV
4-26 PCOVZA050WJFW J Spring, lamp Duct B AK
4-27 PDUC-A050WJKZ J Exhaust Duct BB
4-28 PDUC-A051WJKZ J Lamp Duct B AQ
4-29 PDUC-A055WJKZ J Lamp EX Duct AR
4-30 CFiLWA078WJ01 J UV Mirror Ass'y BD
4-31 PLNS-A047WJZZ J Field Lens BK
4-32 CLNS-A048WJ01 J Relay Lens Ass'y BQ
4-33 CLNS-A051WJ01 J Rod Ass'y BU
4-34 CMiR-A053WJZZ J Mirror Ass'y BF
4-35 PSLDHA031WJFW J Heat Shield for Lamp House AK
4-36 PSLDPA022WJFW J Flame,AP AK
4-37 PSLDPA027WJFW J FL Blind AV
4-38 PSLDPA028WJFW J DMD Aperture AR
4-39 PSLDPA029WJFW J Blind A AR
4-40 PSPAGA245WJZZ J Dumper Gum BC
4-41 PSPAGA246WJZZ J Spacer, x8 AY
4-42 PSPAZA511WJZZ J Ring Bush, x3 AP
4-43 PSPAZA584WJZZ J FL Packing D AS
4-44 PSPAZA589WJZZ J FL Packing C AK
4-45 PSPAZA590WJZZ J Dust Cover AW
4-46 PSPAZA603WJZZ J Blind Seel, x2 AF
4-47 PSPAZA612WJZZ J Fan Tape AG
4-48 RH-HXA005WJZZ J Thermal Sensor AK
4-49 QCNW-C720WJQZ J Photo Sensor cable AM
4-50 QCNW-D074WJZZ J Thermal Fuse AR
4-51 CMOTBA006WJ01 J Aperture Ass'y BL
4-52 RUNTKA091WJZZ J Photo Sensor Unit AZ
4-53 XASSN20P06000 J Screw AD
4-54 XBPSN20P04J00 J Screw, x6 AD
4-55 XBPSN20P06J00 J Screw, x2 AD
4-56 XBPSN25P04JS0 J Screw AD
4-57 XBPSN25P10JS0 J Screw, x7 AD
4-58 XBPSN30P06000 J Screw, x3 AA
4-59 XBPSN30P35JS0 J Screw, x2 AD
4-60 XEBSN20P04000 J Screw, x2 AB
4-61 XEBSN30P08000 J Screw, x2 AA
4-62 XSBSN14P03000 J Screw, x3 AD
4-63 XSBSN20P04000 J Screw, x2 AD
4-64 XSPSN17P02500 J Screw, x2 AD
4-65 XSPSN20P02000 J Screw, x2 AC
4-66 XSPSN20P04000 J Screw, x18 AC
4-67 XSSSN20P07000 J Screw, x2 AD
4-68 XWHUW40-03000 J C/W Washer AK
5 AN-MB70LP - Lamp Unit, Option —
24 DUNTKC613WEF0 - FORMATTER Unit —
34 LHLDZA384WJFW J Backer Plate AM
38 MSPRPA039WJFW J Stud Spring AL
39 NSFTZA101WJFW J Shaft, x2 AE
42 PRDARA124WJFW J Heat Sink AY
43 PRDARA125WJFW J Stud AL
44 PSHEGA031WJKZ J Thermal Pad AF
48 PSPAZ0445CEZZ J Spacer, x2 AC
49 PSPAZA479WJZZ J Kapton Insulator AL
55 QSOCZA081WJZZ J Socket for C-Spring BA
56 RDMDPA014WJZZQ J DMD 0.7 XGA EK
58 XBPSN30P08JS0 J Screw, x2 AB
59 XBPSN30P12JS0 J Screw, x2 AB
