» Adjustment mode process menu
Adjustment mode process menu1
* Adjust only the shaded items below.
Adjustment Process Menu
First layer DTV VERSION
DVD SS
VIDEO TEMP
AD OPTION
AD2 LAMP
DLP LINE
VIDEO1
Pedestal EXIT
second layer Initial Value
DTV Contrast 4
Tint 5
Color 12
Sharpness 2
Bright 40
B-DRIVE 41
R-DRIVE 41
EXIT
DVD Contrast 4
Tint 5
Color 12
Sharpness 3
Bright 40
B-DRIVE 41
R-DRIVE 41
EXIT
VIDEO Contrast 4
N-Tint 5
P-Tint 5
S-Tint 5
N-Color 6
P-Color 6
S-Color 6
Sharpness 3
Bright 40
B-DRIVE 41
R-DRIVE 41
EXIT
AD R-Bright 63
G-Bright 63
B-Bright 63
R-Contrast 155
G-Contrast 155
B-Contrast 155
EXIT
second layer Initial Value
AD2 R-Bright2 63
G-Bright2 63
B-Bright2 63
R-Contrast2 155
G-Contrast2 155
B-Contrast2 155
EXIT
DLP Index Delay 10500
R-Bright 32
G-Bright 32
B-Bright 32
R-Contrast 34
G-Contrast 34
B-Contrast 34
SR-Cont 34
SG-Cont 34
SB-Cont 34
EXIT
VIDEO1 N-Contrast 12
P-Contrast 13
S-Contrast 14
Color 17
NT3.58Delay 1
NT4.43Delay 1
PAL Delay 1
SECAM Delay 3
EXIT
Pedestal R-Bright -10
G-Bright -10
B-Bright -10
R-Contrast 15
G-Contrast 15
B-Contrast 15
EXIT
