XL-1700/1700C
– 4 –
R861,862 VRS-CY1JB103J J AA 10 kohm,1/16W
1 R863 VRG-ST2EM100J J AC 10 ohm,1/4W,Fusible
R864 VRD-ST2EE101J J AA 100 ohm,1/4W
R865 VRD-ST2CD821J J AA 820 ohms,1/6W
R866 VRS-CY1JB683J J AA 68 kohms,1/16W
R867 VRS-CY1JB154J J AA 150 kohms,1/16W
R870 VRS-CY1JB103J J AA 10 kohm,1/16W
OTHER CIRCUITRY PARTS
CFW301 QCNWN0450SJZZ J Lead Wire,
CFW682/A QCNWN0394SJZZ J Flat Wire,5Pin
CFW701/A QCNWN0378SJZZ J Flat Wire,2Pin
CFW702/A QCNWN0378SJZZ J Flat Wire,2Pin
CFW703/A QCNWN0388SJZZ J Flat Wire,2Pin
CNP101 QCNCM999BAFZZ J AD Plug,2Pin
CNP301 QCNCM010LAWZZ J AC Plug,11Pin
CNP401 QCNCM999CAFZZ J AG Plug,3Pin
CNP651 QCNCM039DSJZZ J AD Plug,4Pin
1 CNP681 QCNCM017BSJZZ J AD Plug,3Pin
CNP701 QCNCM999GAFZZ J Plug,7Pin
CNP702 QCNCM999NAFZZ J AC Plug,13Pin
CNP703 QCNCM999BAFZZ J AD Plug,2Pin
CNP703A QCNCM035FSJZZ J AD Plug,6Pin
CNP704 QCNCM999KAFZZ J Plug,10Pin
CNP705 QCNCM998BAFZZ J AC Plug,2Pin
CNP706 QCNCM999BAFZZ J AD Plug,2Pin
CNP707 QCNCM998BAFZZ J AC Plug,2Pin
CNP801 QCNCW011RSJZZ J Plug,16Pin
CNP803 QCNCM998CAFZZ J AE Plug,3Pin
CNP804 QCNCM999DAFZZ J AG Plug,4Pin
CNP805 QCNCM999EAFZZ J AG Plug,5Pin
CNP808 QCNCM998BAFZZ J AC Plug,2Pin
CNP909 QCNCM998BAFZZ J AC Plug,2Pin
CNS301 QCNCW010LAWZZ J AD Socket,11Pin
CNW401 QCNWN0465SJZZ J Connector Ass'y,3-3Pin
CNW701 QCNWN0381SJZZ J Connector Ass'y,7-7Pin
CNW702 QCNWN0448SJZZ J Connector Ass'y,13-13Pin
CNW703 QCNWN0383SJZZ J Connector Ass'y,2-2Pin
CNW704 QCNWN0384SJZZ J Connector Ass'y,10-10Pin
CNW705 QCNWN0387SJZZ J Connector Ass'y,2Pin
CNW706 QCNWN0385SJZZ J Connector Ass'y,2-2Pin
CNW707 QCNWN0449SJZZ J Connector Ass'y,2-2Pin
CNW801 QCNWN0390SJZZ J Flat Cable,16Pin
CNW802 QCNWN0391SJZZ J Connector Ass'y,6-6Pin
CNW803 QCNWN0463SJZZ J Connector Ass'y,3-3Pin
CNW804 QCNWN0396SJZZ J Connector Ass'y,3-4Pin
CNW805 QCNWN0393SJZZ J Connector Ass'y,5-5Pin
CNW808 QCNWN0445SJZZ J Connector Ass'y,2-2Pin
CNW909 QCNWN0458SJZZ J Connector Ass'y,2Pin with Lug
CORE1 RCORF0026FCZZ J Core
1 F652 QFS-D252BSJNI J AB Fuse,2.5A/125V
1 F653 QFS-D162BSJNI J AE Fuse,1.6A/125V
FE301 RTUNS0016AWZZ J AX FM Front End
J801 VHPIF11381+-1 J AM Jack,CD Digital Output
JK101 QJAKM0001SJZZ J AG Jack,Headphone
LCD701 RV-LX0015SJZZ J AS FL Display
M701 RMOTV0408SJM4 J Motor with Chassis [Spindle]
M702 RMOTV0409AFM1 J AN Motor with Gear [Sled]
M801(246-6) RMOTV0004SJZZ J Motor [CD Lid]
1 RLY601 RRLYD0004SJZZ J AG Relay
RX701 VHLN61V380A-1 J AN Remote Sensor
SO301 QTANC9003SJZZ J AF Terminal,Antenna
SO401 QSOCJ0301SJZZ J AG Socket,Video/AUX Input
SO601 QTANA0007SJZZ J AF Terminal,Speaker
1 SO651 QSOCA0214AWZZ J AD Socket AC Input
SP601,602 RSPA00020SJ8W J AQ Woofer
SP603,604 RALMB0001SJZZ J AH Tweeter
SW702 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
SW709 QSW-K0004SJZZ J AD Switch,Key Type [Power]
SW710 QSW-K0004SJZZ J AD Switch,Key Type
[CD Lid Open/Close]
SW711 QSW-K0004SJZZ J AD Switch,Key Type
[REW/Preset Down]
SW712 QSW-K0004SJZZ J AD Switch,Key Type [FF/Preset Up]
SW713 QSW-K0004SJZZ J AD Switch,Key Type
[CD Stop/Tuning Down]
SW718 QSW-K0004SJZZ J AD Switch,Key Type
[CD Play/Pause/Tuning Up]
SW719 QSW-K0004SJZZ J AD Switch,Key Type [Volume Down]
SW720 QSW-K0004SJZZ J AD Switch,Key Type [Volume Up]
SW725 QSW-K0004SJZZ J AD Switch,Key Type [Bass/Treble]
SW726 QSW-K0004SJZZ J AD Switch,Key Type [Memory/Set]
SW727 QSW-K0004SJZZ J AD Switch,Key Type [Clear]
SW728 QSW-K0004SJZZ J AD Switch,Key Type [Function]
SW802 QSW-B0001SJZZ J AG Switch,Lever Type [CD Lid]
CD MECHANISM PARTS
301 MLEVP1054AFZZ J AC Rail,Guide
302 NGERH0586AFZZ J AC Gear,Middle
303 NGERH0587AFZZ J AC Gear,Drive
304 NSFTM0291AFFW J AD Shaft,Guide
305 PCOVP1333AFSA J AF Cover,Mechanism
306 PCUSG0001AWSA J AD Cushion [Green]
307 PCUSG0004AWSA J AD Cushion [Red-Brown]
1 308 DCTRH8005SJ01 J BA Pickup Unit Ass’y
308- 1 ———— — Pickup Unit
(Not Replacement Item)
308- 2 MSPRC0961AFZZ J AA Spring,Rack
308- 3 NGERR0043AFZZ J AC Gear,Rack
701 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
702 XBBSD20P03000 J AA Screw,ø2×3mm
703 XBSSD26P06000 J AA Screw,ø2.6×6mm
704 XHBSD20P05000 J AA Screw,ø2×5mm
M701 RMOTV0408SJM4 J Moter with Chassis [Spindle]
M702 RMOTV0409AFM1 J AN Motor with Gear [Sled]
SW702 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CABINET PARTS
201 GCABA1077SJSA J AQ Top Cabinet
202 GCABB1085SJSA J Bottom Cabinet [XL-1700]
202 GCABB1089SJSA J Bottom Cabinet [XL-1700C]
203 GCOVA1024SJSA J Cover,Rear Panel
204 GCOVA1017SJSA J AD Cover,Remote Sensor
205 GFTAT1012SJSA J AG CD Lid
206 GFTAT1013SJSA J AG Slide Door
208 HBDGA1002SJSB J AD Badge,SHARP
209 HDECA0001SJSA J AT Cover Plate,CD Lid
210 HDECA0002SJSA J AN Plate,Slide Door
211 HDECB0003SJSA J AK Plate,CD Lid
212 HDECP0006SJSA J AH Sheet,Operation
213 HDECQ0067SJSA J AF CD Ring Panel
214 HDECQ0091SJSA J Clear Panel,CD Lid
215 HDECQ0094SJSA J LCD Window
216 HDECQ0070SJSA J AE Indicator Panel,CD
217 HDECQ0071SJSA J AG Indicator Panel,LCD
218 JKNBZ0059SJSA J AE Knob,CD Open/Volume
219 JKNBZ0060SJSA J AE Knob,Power/Volume
220 JKNBZ0061SJSA J AF Knob,Operation
221 LANGF0054SJFW J Bracket,Display PWB
222 LANGK0032SJFW J Bracket
223 LANGQ0003SJFW J Rear Panel
224 LCHSM0015SJZZ J Chassis
225 LHLDM1005SJSB J Stabilizer
227 LHLDW1001SJZZ J AD Nylon Band
228 LHLDZ1043SJSA J AE Holder,Indicator Panel,CD
229 LHLDZ1044SJSA J AE LCD Holder
230 LHLDZ1045SJSA J AD LED Holder
231 LHLDZ1050SJSA J Holder,Remote Sensor
232 MSPRD0018SJZZ J AD Spring,Slide Door
233 MSPRD0022SJFD J Spring
234 NSFTG0001SJZZ J Gear Shaft,Door
235 PCUSG0010SJZZ J Cushion,Leg
236 PGUMS0002SJZZ J AA Cushion,CD Lid
237 PMAGF0002AWZZ J AE Magnet
239 PRDAR0053SJFW J Radiator,Main
240 PRDAR0054SJFW J Radiator,Transistor
241 PSHEP0006SJSA J LCD Diffusion Sheet
242 PSHEP0009SJZZ J Sheet,Shield
1 243 QFSHD0001AWZZ J AB Holder,Fuse
244 TLABS0043SJZZ J Label,Laser
245 TSPC-0311SJZZ J Label,Specification [XL-1700]
245 TSPC-0312SJZZ J Label,Specification [XL-1700C]
246 CGERW0008SJ01 J Gear Box Ass’y
246- 1 LHLDZ1041SJSA J Lid,Gear Box
246- 2 LHLDZ1042SJSA J Gear Box
246- 3 NGERW0008SJSA J Gear Drive
246- 4 NGERW0009SJSA J Worm Wheel
246- 5 NGERW0010SJSA J Worm Gear
246- 6 RMOTV0004SJZZ J Motor [CD Lid],M801
