PRICE
RANK
DESCRIPTION
NO.
PART CODE
XL-1700/1700C
– 5 –
248 LANGK0048SJFW J Bracket,AC
249 PSHEP0010SJZZ J Sheet,Shield Front End
601 LX-HZ0087AFFD J AA Screw,ø3×8mm
602 LX-HZ0224AFFD J AA Screw,ø3×6mm
603 LX-JZ0001SJFD J AA Screw,ø3×10mm
604 LX-JZ0010AFFD J AA Screw,ø3×10mm
606 XEBSD25P10000 J AA Screw,ø2.5×10mm
607 XEBSD25P12000 J AA Screw,ø2.5×12mm
608 XEBSF25P08000 J AA Screw,ø2.5×8mm
610 XHBSD30P06000 J AA Screw,ø3×6mm
611 XHBSF30P06000 J AA Screw,ø3×6mm
612 XJBSD30P06000 J AA Screw,ø3×6mm
613 XJBSD30P08000 J AA Screw,ø3×8mm
614 XJBSD30P10000 J AA Screw,ø3×10mm
615 XJBSF30P10000 J AA Screw,ø3×10mm
616 XHBSD20P03000 J AA Screw,ø2×3mm
617 LX-WZ9004SJSA J Washer,5×5mm
SPEAKER BOX PARTS
901 GBOXS6003SJSA J AS Box Ass’y
902 GLEGP0003SJSB J AD Leg
903 GWAKP1020SJ01 J AL Net Flame Ass’y
903- 1 ———— — Net Flame
(Not Replacement Item)
903- 2 PGUMM0003SJSA J AD Net Catcher
903- 3 HBDGA1002SJSA J AF Badge,SHARP
904 HPNLS1011SJ01 J AQ Front Panel Ass’y
904- 1 ———— — Front Panel
(Not Replacement Item)
904- 2 HDECQ0073SJSA J AG Panel,Tweeter
904- 3 PCOVZ1003SJSA J AG Duct Cap
904- 4 PDUC-0005SJZZ J AE Duct Pipe
905 PSPAG0005SJZZ J AE Gsket
906 QTANA9011SJZZ J AE Terminal
907 TSPC-0315SJZZ J Specification Label
908 XTBSF40P12000 J AA Screw,ø4×12mm
SP601,602 RSPA00023SJ8W J Woofer
SP603,604 RALMB0001SJZZ J AH Tweeter
PACKING PARTS (Except for U.S.A.)
SPAKA0112SJZZ J Packing Add.,Speaker[Top/
Bottom]
SPAKA0116SJZZ J Packing Add.,Left
SPAKA0117SJZZ J Packing Add.,Right
SPAKC0226SJZZ J Packing Case
SPAKS0007SJZZ J Sleeve Carton,Speaker
SPAKZ0039SJZZ J Polyethylene Bag,Speaker
SPAKZ0063SJZZ J Pad,Accessories
SPAKZ0064SJZZ J AC Polyethylene Bag,Unit
SSAKA0009SJZZ J Polyethylene Bag,Accessories
TLABN0179SJZZ J Label,Serial No.
TLABRF245SJZZ J Label,Product
TLABS0044SJZZ J Label,UL Caution
TLABZ0038SJZZ J Label,Energy Star
ACCESSORIES
TINSE0081SJZZ J Operation Manual [XL-1700]
TINSK0031SJZZ J Operation Manual [XL-1700C]
TINSZ0140SJZZ J Quick Guide
1 QACCU0003SJ00 J AC Power Supply Cord
QANTL0001SJZZ J AK AM Loop Antenna
QANTW0002SJZZ J AH FM Antenna
QCNWH0005SJ01 J AF Speaker Cord
RRMCG0037SJSA J AT Remote Control
GCABB1064SJSB J Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
1 PWB-A1~8 DCEKLV188SJ03 J Main/Display/CD/Terminal/
Switch/Led/Led/Led
PWB-B1,2 DCEKJV188SJ03 J Tuner/Washer
PWB-C QPWBF3895AFZZ J AC CD Motor (PWB Only)
OTHER SERVICE PART
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner Disc
