Sharp XL-DV5

NO.
PARTS CODE
PRICE
RANK
DESCRIPTION
XL-DV5/DV50
NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
– 4 –
R696 VRS-CY1JB102J J AA 1 kohm,1/16W
R701 VRD-ST2CD102J J AA 1 kohm,1/6W
R702 VRS-CY1JB102J J AA 1 kohm,1/16W
R703 VRD-ST2CD102J J AA 1 kohm,1/6W
R704 VRD-ST2CD103J J AA 10 kohm,1/6W
R705~710 VRD-ST2CD102J J AA 1 kohm,1/6W
R712 VRS-CY1JB221J J AA 220 ohms,1/16W
R713 VRS-CY1JB102J J AA 1 kohm,1/16W
R714,715 VRD-ST2CD102J J AA 1 kohm,1/6W
R716 VRS-CY1JB103J J AA 10 kohm,1/16W
R718 VRS-CY1JB102J J AA 1 kohm,1/16W
R719 VRD-ST2CD102J J AA 1 kohm,1/6W
R720,721 VRS-CY1JB102J J AA 1 kohm,1/16W
R722,723 VRD-ST2CD102J J AA 1 kohm,1/6W
R724,725 VRS-CY1JB221J J AA 220 ohms,1/16W
R727 VRD-ST2CD103J J AA 10 kohm,1/6W
R728~732 VRD-ST2CD102J J AA 1 kohm,1/6W
R733 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R735 VRD-ST2CD103J J AA 10 kohm,1/6W
R737 VRS-CY1JB103J J AA 10 kohm,1/16W
R738,739 VRD-ST2CD103J J AA 10 kohm,1/6W
R740 VRS-CY1JB102J J AA 1 kohm,1/16W
R741 VRS-CY1JB106J J AA 10 Mohm,1/16W
R742~744 VRD-ST2CD103J J AA 10 kohm,1/6W
R745B VRS-CY1JB000J J AA 0 ohm,Jumper,0.8×1.55mm,Green
R746~750 VRD-ST2CD102J J AA 1 kohm,1/6W
R751 VRS-CY1JB102J J AA 1 kohm,1/16W
R752A VRS-CY1JB823J J AA 82 kohms,1/16W
R752B VRS-CY1JB823J J AA 82 kohms,1/16W
R752C VRS-CY1JB823J J AA 82 kohms,1/16W
R752D VRS-CY1JB823J J AA 82 kohms,1/16W
R752E VRS-CY1JB823J J AA 82 kohms,1/16W
R752F VRS-CY1JB823J J AA 82 kohms,1/16W
R752G VRS-CY1JB823J J AA 82 kohms,1/16W
R752H VRS-CY1JB823J J AA 82 kohms,1/16W
R752I VRS-CY1JB823J J AA 82 kohms,1/16W
R752J VRS-CY1JB823J J AA 82 kohms,1/16W
R752K VRS-CY1JB823J J AA 82 kohms,1/16W
R753A VRS-CY1JB823J J AA 82 kohms,1/16W
R753B VRS-CY1JB823J J AA 82 kohms,1/16W
R753C VRS-CY1JB823J J AA 82 kohms,1/16W
R753D VRS-CY1JB823J J AA 82 kohms,1/16W
R753E VRS-CY1JB823J J AA 82 kohms,1/16W
R753F VRS-CY1JB823J J AA 82 kohms,1/16W
R753G VRS-CY1JB823J J AA 82 kohms,1/16W
R753H VRS-CY1JB823J J AA 82 kohms,1/16W
R753I VRS-CY1JB823J J AA 82 kohms,1/16W
R753J VRS-CY1JB823J J AA 82 kohms,1/16W
R753K VRS-CY1JB823J J AA 82 kohms,1/16W
R753L VRS-CY1JB823J J AA 82 kohms,1/16W
R753M VRS-CY1JB823J J AA 82 kohms,1/16W
R753N VRS-CY1JB823J J AA 82 kohms,1/16W
R753O VRS-CY1JB823J J AA 82 kohms,1/16W
R753P VRS-CY1JB823J J AA 82 kohms,1/16W
R753Q VRS-CY1JB823J J AA 82 kohms,1/16W
R753R VRS-CY1JB823J J AA 82 kohms,1/16W
R753S VRS-CY1JB823J J AA 82 kohms,1/16W
R753T VRS-CY1JB823J J AA 82 kohms,1/16W
R755 VRD-ST2CD102J J AA 1 kohm,1/6W
R756 VRD-ST2CD103J J AA 10 kohm,1/6W
R758 VRS-CY1JB102J J AA 1 kohm,1/16W
R760 VRD-ST2EE470J J AA 47 ohms,1/4W
R761,762 VRS-CY1JB102J J AA 1 kohm,1/16W
R763 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R764 VRS-CY1JB104J J AA 100 kohm,1/16W
R765,766 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R767 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R768 VRD-ST2CD202J J AA 2 kohms,1/6W
R769 VRS-CY1JB272J J AA 2.7 kohms,1/16W
R770 VRS-CY1JB392J J AA 3.9 kohms,1/16W
R772 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R773 VRD-ST2EE271J J AA 270 ohms,1/4W
R775 VRS-CY1JB820J J AA 82 ohms,1/16W
R776 VRS-CY1JB102J J AA 1 kohm,1/16W
R777,778 VRS-CY1JB103J J AA 10 kohm,1/16W
R779 VRS-CY1JB121J J AA 120 ohms,1/16W
R780,781 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R782 VRS-CY1JB152J J AA 1.5 kohms,1/16W
R783 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R784 VRS-CY1JB272J J AA 2.7 kohms,1/16W
R785 VRS-CY1JB392J J AA 3.9 kohms,1/16W
R786 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R787~789 VRS-CY1JB103J J AA 10 kohm,1/16W
R797 VRD-ST2CD103J J AA 10 kohm,1/6W
R799 VRS-CY1JB102J J AA 1 kohm,1/16W
R901~903 VRS-CY1JB000J J AA 0 ohm,Jumper,0.8×1.55mm,Green
R904,905 VRS-CY1JB750J J AA 75 ohms,1/16W
R906 VRS-CY1JB000J J AA 0 ohm,Jumper,0.8×1.55mm,Green
OTHER CIRCUITRY PARTS
CFW101 QCNWNA102SJZZ J Lead Wire Ass’y
CFW750 QCNWNA103SJZZ J Lead Wire
CFW751 QCNWNA105SJZZ J Lead Wire Ass’y
CNP101 QCNCM999JAFZZ J AC Plug,9Pin
CNP102 QCNCM999GAFZZ J AD Plug,7Pin
CNP103A QCNCMA014SJ07 J AB Plug,7Pin
CNP103B QCNCMA014SJ07 J AB Plug,7Pin
1 CNP201 QCNCM017BSJZZ J AD Plug,3Pin
1 CNP202 QCNCM017CSJZZ J Plug,3Pin
1 CNP203 QCNCM018BSJZZ J Plug,3Pin
1 CNP204 QCNCM998EAFZZ J AG Plug,6Pin
CNP205 QCNCM046CSJZZ J AD Plug,3Pin
CNP301 QCNCM042CSJZZ J AB Plug,3Pin
CNP302 QCNCM999JAFZZ J AC Plug,9Pin
CNP501 QCNCW015QSJZZ J AE Socket,15Pin
CNP602 QCNCM999GAFZZ J AD Plug,7Pin
CNP802 QCNCM004GAFZZ J AC Plug,7Pin
CNP807 QCNCMA019SJ07 J Plug,7Pin
CNP904 QCNCM999DAFZZ J AG Plug,4Pin
CNP904A QCNCLA020SJ12 J Plug,12Pin
CNW101/CNS101 QCNWNA031SJZZ J Connector Ass’y,9/9Pin
CNW102/CNS102 QCNWNA033SJZZ J Connector Ass’y,7/7Pin
CNW103 QCNWNA108SJZZ J Connector Ass’y,7/7Pin
1 CNW201/CNS201 QCNWNA024SJZZ J Connector Ass’y,3/3Pin
CNW205 QCNWNA035SJZZ J AC Connector Ass’y,3Pin
CNW206 QCNWNA107SJZZ J Connector Ass’y,3/2Pin
CNW302/CNS302 QCNWNA032SJZZ J Connector Ass’y,10/9Pin
CNW602/CNS602 QCNWNA030SJZZ J Connector Ass’y,8/7Pin
1 F201 QFS-D502BSJNI J AE Fuse,5A/125V
1 F202 QFS-D502BSJNI J AE Fuse,5A/125V
1 F203 QFS-D202BSJNI J AB Fuse,2A/125V
1 F204 QFS-D322BSJNI J AC Fuse,3.15A/125V
FC501 QCNWNA013SJZZ J AE Flat Cable,15Pin
JK101 QJAKMA001SJZZ J AG Jack,Headphones
M201(218-4) RMOTV0409AFZZ J AL Motor,Air Cooling Fan
MR101 RCORFA004SJZZ J Core
MR201 RCORFA004SJZZ J Core
RLY101 RRLYD0014AWZZ J AK Relay
RLY102 RRLYDA001SJZZ J AH Relay
1 RLY201 RRLYD0004SJZZ J AG Relay
RX701 VHLGP1UD261-1 J AK Remote Sensor,GP1UD261
S901 QSOCJA001SJZZ J Socket,Component Video Output
S902 QSOCJA002SJZZ J Socket,S-Video/Video Output
S903 VHPBFTX1001-1 J Terminal,Audio Digital Output
SO101 QTANAA002SJZZ J AF Terminal,Speaker
1 SO202 QSOCA0214AWZZ J AD Socket AC Input
SO601 QSOCJ0003SJZZ J AG Socket,Video/AUX Input
SW700 QSW-Z0003SJZZ J AG Switch,Rotary Type,Jog
[VOLUME]
SW701 QSW-K0002SJZZ J AC Switch,Key Type [EQUALISER]
SW702 QSW-K0002SJZZ J AC Switch,Key Type
[TUNING DOWN/STOP]
SW703 QSW-K0002SJZZ J AC Switch,Key Type
[TUNING UP/PLAY]
SW704 QSW-K0002SJZZ J AC Switch,Key Type [PRESET UP]
SW705 QSW-K0002SJZZ J AC Switch,Key Type
[PRESET DOWN]
SW706 QSW-K0002SJZZ J AC Switch,Key Type [DISC 1]
SW707 QSW-K0002SJZZ J AC Switch,Key Type [DISC 2]
SW708 QSW-K0002SJZZ J AC Switch,Key Type
[MEMORY/SET]
SW709 QSW-K0002SJZZ J AC Switch,Key Type
[POWER ON/STAND-BY]
SW710 QSW-K0002SJZZ J AC Switch,Key Type
[X-BASS/DEMO]
SW711 QSW-K0002SJZZ J AC Switch,Key Type [DVD/CD]
SW712 QSW-K0002SJZZ J AC Switch,Key Type
[TUNER (BAND)]
SW713 QSW-K0002SJZZ J AC Switch,Key Type [VIDEO/AUX]
SW714 QSW-K0002SJZZ J AC Switch,Key Type [DISC 3]
SW715 QSW-K0002SJZZ J AC Switch,Key Type [DISC 4]
SW716 QSW-K0002SJZZ J AC Switch,Key Type [DISC 5]
SW717 QSW-K0002SJZZ J AC Switch,Key Type
