Sharp XL-DV5

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-DV5/DV50
CABINET PARTS
201 CPNLCA005SJ01 J Front Panel Ass’y [XL-DV5]
201 CPNLCA005SJ03 J AU Front Panel Ass’y [XL-DV50]
201- 1 ———— –– Front Panel
201- 2 HDECQA024SJSA J AF Decoration Panel,Center
201- 3 HDECQA034SJSA J AF Window [XL-DV50]
201- 3 HDECQA037SJSA J Window [XL-DV5]
201- 4 LHLDZA028SJSA J AD Holder,Jog Knob
201- 5 PCUSG0017SJSA J AB Cushion,Leg
202 GCABCA011SJSA J Top Cabinet [XL-DV5]
202 GCABCA011SJSB J AM Top Cabinet [XL-DV50]
203 GCABDA012SJSA J Chassis,Main [XL-DV5]
203 GCABDA012SJSB J Chassis,Main [XL-DV50]
204 GCOVAA005SJ03 J Changer Cover Ass’y [XL-DV5]
204 GCOVAA005SJ04 J Changer Cover Ass’y [XL-DV50]
204- 1 ———— –– Changer Cover
204- 2 HDECQA033SJSA J AE Panel,Changer Cover
205 GCOVAA006SJSA J AD Indicator
206 GCOVAA007SJSA J AD Cover,Sensor
207 GITARA012SJSA J Rear Panel [XL-DV5]
207 GITARA017SJSA J AH Rear Panel [XL-DV50]
208 GITASA007SJSA J Side Panel,Left [XL-DV5]
208 GITASA007SJSB J AM Side Panel,Left [XL-DV50]
209 GITASA008SJSA J Side Panel,Right [XL-DV5]
209 GITASA008SJSB J AM Side Panel,Right [XL-DV50]
210 JKNBKA002SJSA J AF Knob,Jog
211 JKNBZA008SJSA J Button,OPEN/CLOSE [XL-DV5]
211 JKNBZA008SJSB J AD Button,OPEN/CLOSE [XL-DV50]
212 JKNBZA009SJSA J Button,X-BASS [XL-DV5]
212 JKNBZA009SJSB J AF Button,X-BASS [XL-DV50]
213 JKNBZA010SJSA J AE Button,TUNER
214 JKNBZA011SJSA J AD Button,POWER
215 JKNBZA023SJSA J AG Button,PLAY
216 JKNBZA014SJSA J Button,CD Select,A [XL-DV5]
216 JKNBZA014SJSB J AE Button,CD Select,A [XL-DV50]
217 JKNBZA015SJSA J Button,CD Select,B [XL-DV5]
217 JKNBZA015SJSB J AE Button,CD Select,B [XL-DV50]
218 CFANP0001SJ06 J Fan Motor Ass’y
218- 1 LANGKA015SJFW J Bracket,Fan Motor
218- 2 MSPRK0001SJFJ J AC Spring,Fan Stoper
218- 3 NFANP0001SJSA J AG Fan
218- 4(M201) RMOTV0409AFZZ J AL Motor,Air Cooling Fan
219 KMECZA003SJZZ J BL CD Changer Unit Ass’y
1 220 KRPLE0026SJM2 J DVD Mechanism Unit Ass’y
221 LANGKA005SJFW J AB Bracket,Main PWB
222 LANGKA016SJFW J Bracket,PWB
223 LANGKA019SJFW J Bracket,DVD PWB,Front L
224 LANGKA020SJFW J Bracket,DVD PWB,Rear L
225 LANGKA021SJFW J Bracket,DVD PWB,Front R
226 LANGKA022SJFW J Bracket,DVD PWB,Rear R
227 LANGKA031SJFW J Bracket,Sub Chassis L
228 LANGKA032SJFW J Bracket,Sub Chassis R
229 LCHSSA002SJFW J Chassis,Sub
230 LHLDW1001SJZZ J AD Nylon Band
231 LHLDZA011SJSA J AC Holder,FL Display
232 LHLDZA018SJZZ J AB Holder,LED
233 MSPRKA001SJFW J AC Plate Spring,IC
234 MSPRKA002SJFW J Plate Spring,A
235 MSPRKA003SJFW J Plate Spring,B
236 MSPRKA004SJFW J Plate Spring,C
237 PCOVSA003SJZZ J Cover,Display PWB
238 PCOVZA005SJFW J Cover,Transformer
239 PCUSG0017SJSA J AB Cushion,Leg
240 PRDARA008SJFW J Heat Sink,Main
241 PRDARA009SJFW J Heat Sink,A
242 PRDARA010SJFW J Heat Sink,B
243 PRDARA011SJFW J Heat Sink,C
244 PSHEZA002SJZZ J Silicon Sheet
245 PSPAIA002SJZZ J AB Spacer,PWB
1 246 QFSHD1013CEZZ J AB Holder,Fuse
247 9GD450633201 J Insulator (Purple)
248 9GD450633202 J Insulator (Gray)
250 TLABS0042SJZZ J AB Label,Laser
251 TLABZA023SJZZ J Label,Licence
601 LX-JZ0001SJFD J AA Screw,ø3×10mm
602 LX-JZ0002SJFD J AD Screw,Special
605 XHBSD20P03000 J AA Screw,ø2×3mm
606 XHBSD30P06000 J AA Screw,ø3×6mm
607 XHBSD30P12000 J AA Screw,ø3×12mm
608 XHBSF30P06000 J AA Screw,ø3×6mm
– 5 –
[OPEN/CLOSE]
VFD701 VVK251116//-1 J AV FL Display
CHANGER MECHANISM PARTS
101 9GD662641004 J Drawer L
102 9GD662641033 J Drawer R
103 9GD660934115H J Disc 1 Carriage Ass’y
104 9GD662192019 J Frame
105 9GD662393025 J Arm Switch C
106 9GD662224013 J Gear D1
107 9GD662224014 J Gear D2
108 9GD662393018 J Arm Switch D
109 9GD662393024 J Arm Switch B
110 9GD662393020 J Arm Lock
111 9GD582593021 J Lever GC
112 9GD581194039 J S Bracket
113 9GD662224010 J Gear Pulley
114 9GD661192094 J Cover
115 9GD660934103H J Clamper SA-S Ass’y
116 9GD662392085 J Arm Clamper
117 9GD662393007 J Lift Slider L
118 9GD662393005 J PP Slider
119 9GD662112002 J FL Base
120 9GD662393008 J Lift Slider R
121 9GD662113026 J Up/Down Base
122 9GD662393006 J Up/Down Slider
123 9GD662101001 J Main Chassis
124 9GD660934077H J Solenoid Ass’y
125 9GD660934073H J Motor Ass’y
126 9GD662392022 J Arm Lift
127 9GD662224015 J Gear E
128 9GD662393039 J Arm CC Switch
129 9GD662224016 J Gear F
130 9GD663634068 J Gear E Collar
131 9GD662393017 J Arm P Switch
132 9GD660934076H J CD Changer PWB Ass’y
133 9GD660934072H J Switch PWB Ass’y
134 9GD662393023 J Arm Switch A
135 9GD662233009 J Gear B
136 9GD662192003 J Plate Cam
137 9GD662213021 J Gear Cam
138 9GD662593086 J Lever CL 1
139 9GD662593090 J Lever CL 2
140 9GD662224088 J Gear 1
141 9GD662224089 J Gear 2
142 9GD660004091 J Felt
143 9GD010814711 J Gear E Spring
144 9GD010814710 J Gear 1 Spring
145 9GD010814712 J Gear D Spring
146 9GD660824059 J Stop Spring L
147 9GD660824060 J Stop Spring R
148 9GD010824096 J Spring
149 9GD010804727 J Spring A
150 9GD010824717 J Spring B
151 9GD010824718 J Spring C
152 9GD010824735 J Spring 1
153 9GD010824736 J Spring 2
154 9GD010824737 J Spring SL
155 9GD010824738 J Spring SR
156 9GD010814739 J Spring Gear B
157 9GD660934117H J Disc 2 Carriage Ass’y
158 9GD660934118H J Disc 3 Carriage Ass’y
159 9GD660934119H J Disc 4 Carriage Ass’y
160 9GD660934120H J Disc 5 Carriage Ass’y
161 9GDGSL20A2606 J Screw,ø2.5×6mm
162 9GDGSP14A2504 J Screw,ø2.5×4mm
163 9GDGSL15A2616 J Screw,ø2.5×16mm
164 9GDGSL15A2608 J L Screw,ø2.5×8mm
165 9GD033004585 J Screw,ø2×6mm
166 9GD033004581 J Screw,ø2×3mm
167 9GD033004577 J Screw,ø2×16mm
168 GWP65X110030 J Washer
169 9GD020834262 J Belt
170 9GD033004584 J Screw,ø2.5×5mm
