XL-DV60
11
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
CNW102 QCNWNA033SJZZ AD Connector Ass'y,7/7Pin/CNS102
CNW103 QCNWNA339SJZZ N Connector Ass'y,8/7Pin
!
CNW201 QCNWNA024SJZZ AF Connector Ass'y,3/3Pin/CNS201
CNW205 QCNWNA289SJZZ AG N Connector Ass'y,15/14Pin/CNS205
CNW206 QCNWNA288SJZZ AG N Connector Ass'y,14/13Pin/CNS206
CNW207 QCNWNA107SJZZ AB Connector Ass'y,3Pin
CNW208 QCNWNA315SJZZ N Connector Ass'y,3Pin
CNW302 QCNWNA032SJZZ AE Connector Ass'y,10/9Pin/CNS302
CNW602 QCNWNA030SJZZ AE Connector Ass'y,8/7Pin/CNS602
!
F201 QFS-D632BSJNI AC Fuse,6.3A/125V
!
F202 QFS-D632BSJNI AC Fuse,6.3A/125V
!
F203 QFS-D202BSJNI AB Fuse,2A/125V
!
F204 QFS-D322BSJNI AC Fuse,3.15A/125V
FC501 QCNWNA286SJZZ N Flat Cable,15Pin
FFC1B QCNWNA399SJZZ N Flat Cable,24Pin
JK101 QJAKMA001SJZZ AG Jack,Headphones
M201 RMOTV0409AFZZ AL Motor,Air Cooling Fan (218-4)
MR101 RCORFA004SJZZ AE Core
!
MR201 RCORFA004SJZZ AE Core
RLY101 RRLYD0014AWZZ AK Relay
RLY102 RRLYDA001SJZZ AH Relay
!
RLY201 RRLYD0004SJZZ AG Relay
RX701 VHLGP1UD261-1 AK Remote Sensor,GP1UD261
S901 QSOCJA001SJZZ AD Socket,Component Video Output
S902 QSOCJA002SJZZ AE Socket,S-Video/Video Output
S903 VHPBFTX1001-1 AK Terminal,Audio Digital Output
SO101 QTANAA002SJZZ AF Terminal,Speaker
!
SO202 QSOCA0214AWZZ AD Socket AC Input
SO601 QSOCJ0003SJZZ AG Socket,Video/AUX Input
SW700 QSW-Z0003SJZZ AG Switch,Rotary Type,Jog [VOLUME]
SW701 QSW-K0002SJZZ AC Switch,Key Type [EQUALISER]
SW702 QSW-K0002SJZZ AC Switch,Key Type [TUNING DOWN/STOP]
SW703 QSW-K0002SJZZ AC Switch,Key Type [TUNING UP/PLAY]
SW704 QSW-K0002SJZZ AC Switch,Key Type [PRESET UP]
SW705 QSW-K0002SJZZ AC Switch,Key Type [PRESET DOWN]
SW706 QSW-K0002SJZZ AC Switch,Key Type [DISC 1]
SW707 QSW-K0002SJZZ AC Switch,Key Type [DISC 2]
SW708 QSW-K0002SJZZ AC Switch,Key Type [MEMORY/SET]
SW709 QSW-K0002SJZZ AC Switch,Key Type [POWER ON/STAND-BY]
SW710 QSW-K0002SJZZ AC Switch,Key Type [X-BASS/DEMO]
SW711 QSW-K0002SJZZ AC Switch,Key Type [DVD/CD]
SW712 QSW-K0002SJZZ AC Switch,Key Type [TUNER (BAND)]
SW713 QSW-K0002SJZZ AC Switch,Key Type [VIDEO/AUX]
SW714 QSW-K0002SJZZ AC Switch,Key Type [DISC 3]
SW715 QSW-K0002SJZZ AC Switch,Key Type [DISC 4]
SW716 QSW-K0002SJZZ AC Switch,Key Type [DISC 5]
SW717 QSW-K0002SJZZ AC Switch,Key Type [OPEN/CLOSE]
VFD701 VVK251116//-1 AV FL Display
[11] OTHER CIRCUITRY PARTS
