Sharp XL-DV60 Service Manual

XL-DV60
20
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
C174 VCCCCY1CH270J AA N 27 pF (CH),16V
C175 VCCCCY1CH270J AA N 27 pF (CH),16V
C176 VCKYCY1CB561K AA N 560 pF,16V
C177 VCKYCY1CB561K AA N 560 pF,16V
C178 VCKYCY1CB561K AA N 560 pF,16V
C179 RC-GZA475AF1C AB 4.7 µ F,16V,Electrolytic
C180 VCCCCY1CH470J AA N 47 pF (CH),16V
C181 VCCCCY1CH220J AA N 22 pF (CH),16V
C182 VCCCCY1CH220J AA N 22 pF (CH),16V
C183 VCCCCY1CH220J AA N 22 pF (CH),16V
C184 VCCCCY1CH220J AA N 22 pF (CH),16V
C185 VCCCCY1CH220J AA N 22 pF (CH),16V
C186 VCCCCY1CH220J AA N 22 pF (CH),16V
C187 VCKYCY1CB102K AA N 0.001 µ F,16V
C188 VCKYCY1CB102K AA N 0.001 µ F,16V
[24] RESISTORS (DVD)
R1 VRS-CY1JB6810 AA N 681 ohms,1/16W
R2 VRS-CY1JB6810 AA N 681 ohms,1/16W
R3 VRS-CY1JB4120 AA N 412 ohms,1/16W
R4 VRS-CY1JB4120 AA N 412 ohms,1/16W
R5 VRS-CY1JB331F N 330 ohms,1/16W
R6 VRS-CY1JB330J AA 33 ohms,1/16W
R7 VRS-CY1JB330J AA 33 ohms,1/16W
R8 VRS-CY1JB330J AA 33 ohms,1/16W
R9 VRS-CY1JB330J AA 33 ohms,1/16W
R10 VRS-CY1JB330J AA 33 ohms,1/16W
R11 VRS-CY1JB330J AA 33 ohms,1/16W
R12 VRS-CY1JB330J AA 33 ohms,1/16W
R13 VRS-CY1JB330J AA 33 ohms,1/16W
R14 VRS-CY1JB330J AA 33 ohms,1/16W
R15 VRS-CY1JB330J AA 33 ohms,1/16W
R16 VRS-CY1JB330J AA 33 ohms,1/16W
R17 VRS-CY1JB330J AA 33 ohms,1/16W
R18 VRS-CY1JB330J AA 33 ohms,1/16W
R19 VRS-CY1JB330J AA 33 ohms,1/16W
R20 VRS-CY1JB330J AA 33 ohms,1/16W
R21 VRS-CY1JB330J AA 33 ohms,1/16W
R22 VRS-CY1JB330J AA 33 ohms,1/16W
R23 VRS-CY1JB330J AA 33 ohms,1/16W
R24 VRS-CY1JB330J AA 33 ohms,1/16W
R25 VRS-CY1JB330J AA 33 ohms,1/16W
R26 VRS-CY1JB330J AA 33 ohms,1/16W
R27 VRS-CY1JB330J AA 33 ohms,1/16W
R28 VRS-CY1JB330J AA 33 ohms,1/16W
R29 VRS-CY1JB330J AA 33 ohms,1/16W
R30 VRS-CY1JB330J AA 33 ohms,1/16W
R31 VRS-CY1JB330J AA 33 ohms,1/16W
R32 VRS-CY1JB330J AA 33 ohms,1/16W
R33 VRS-CY1JB330J AA 33 ohms,1/16W
R34 VRS-CY1JB330J AA
33 ohms,1/16W
R35 VRS-TV2AB3R3J AA 3.3 ohms,1/10W
R36 VRS-CY1JB2490 AA N 249 ohms,1/16W
R38 VRS-CY2AB000J N 0 ohm,Jumper
R39 VRS-CY2AB000J N 0 ohm,Jumper
R40 VRS-CY1JB680J AA 68 ohms,1/16W
R41 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R42 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R44 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R45 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R49 VRS-TV2AB3R3J AA 3.3 ohms,1/10W
R53 VRS-TV2AB750J AA 75 ohms,1/10W
R54 VRS-TV2AB750J AA 75 ohms,1/10W
R69 VRS-CY1JB102J AA 1 kohm,1/16W
R70 VRS-CY1JB102J AA 1 kohm,1/16W
R71 VRS-CY1JB102J AA 1 kohm,1/16W
R73 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R75 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R76 VRS-CY1JB101J AA 100 ohm,1/16W
R77 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R79 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R80 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R82 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R83 VRS-CY1JB332J AA 3.3 kohms,1/16W
R84 VRS-CY1JB332J AA 3.3 kohms,1/16W
R85 VRS-CY1JB332J AA 3.3 kohms,1/16W
R86 VRS-CY1JB332J AA 3.3 kohms,1/16W
R87 VRS-CY1JB332J AA 3.3 kohms,1/16W
R88 VRS-CY1JB332J AA 3.3 kohms,1/16W
R89 VRS-CY1JB332J AA 3.3 kohms,1/16W
R90 VRS-CY1JB332J AA 3.3 kohms,1/16W
R91 VRS-CY1JB104J AA 100 kohm,1/16W
R92 VRS-CY1JB104J AA 100 kohm,1/16W
R93 VRS-CY1JB104J AA 100 kohm,1/16W
R94
VRS-CY1JB104J AA 100 kohm,1/16W
[23] CAPACITORS (DVD)

Sharp XL-DV60 Specifications

General

Brand	Sharp
Model	XL-DV60
Category	Stereo System
Language	English
