XL-DV60
Preparation for Use
System connections
Front speaker (left)Front speaker (right)Subwoofer
AC outlet
(AC 120 V, 60 Hz)
Speaker connection (see page 15)
FM antenna
Make sure to unplug the AC power cord before making any connections.
FM/AM loop antenna connection (see page 15)
TV connection
(see pages 16 - 17)
Connecting the AC power cord (see page 18)
AM loop antenna
TV
