XL-MP130
3 – 4
Figure 4
Figure 5
Figure 6
(G1) x1
ø3x8mm
(H1) x4
ø4x6mm
(J1) x1
ø3x8mm
(G2) x2
(G2) x2
Terminal PWB
Main PWB
Power PWB
(K2) x8
ø2.6x8mm
(L1) x4
ø3x10mm
(M1) x1
Special
(K3) x1
(K1) x1
Front Panel
Jack PWB
Cassette
Holder
Display PWB
Tape
Mechanism
(N1) x2
ø3x10mm
(N2) x2
(N3) x1
(P1) x2
ø3x10mm
(P1) x2
ø3x10mm
CD Changer
Unit
CD MP3 PWB
Figure 7
STEP REMOVAL PROCEDURE FIGURE
1Woofer/
Tweeter
1. Net Frame................(A1) x1
2. Front Panel...............(A2) x1
3. Screw.......................(A3) x6
8
Figure 8
(P2) x4
Special
CD Changer
Unit
CD Mechanism
Screwdriver
Net Frame
(A1)x1
(A3)x2
ø3x10mm
(A3)x4
ø4x16mm
Woofer
Front Panel
(A2)x1
Tweeter
