Sharp XL-MP130 Service Manual

XL-MP130
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
C704 VCCCCY1HH180J AA 18 pF (CH),50V
C705 VCCCCY1HH180J AA 18 pF (CH),50V
C706 VCKYCY1EF223Z AB 0.022 µ F,25V
C707 RC-EZD105AF1H AB 1 µ F,50V,Electrolytic
C716 VCKYCY1HB102K AA 0.001 µ F,50V
C717 VCKYCY1HB102K AA 0.001 µ F,50V
C718 VCKYCY1HB103K AA 0.01 µ F,50V
C719 RC-EZD335AF1H AB 3.3 µ F,50V,Electrolytic
C720 VCKYCY1EF223Z AB 0.022 µ F,25V
C721 RC-EZD476AF1C AC 47 µ F,16V,Electrolytic
C722 VCCCCY1HH151J AA 150 pF (CH),50V
C723 VCKYCY1EF473Z AB 0.047 µ F,25V
C724 VCKYCY1EF473Z AB 0.047 µ F,25V
C801 VCEAZA1VW107M AC 100 µ F,35V,Electrolytic
C802 VCEAZA1HW476M AB 47 µ F,50V,Electrolytic
C803 VCEAZA1HW476M AB 47 µ F,50V,Electrolytic
C804 VCEAZA1JW227M AD 220 µ F,63V,Electrolytic
C805 VCEAZA2AW226M AC 22 µ F,100V,Electrolytic
C806 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C807 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C808 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C809 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C810 VCFYDA2AA224J AD 0.22 µ F,100V,Thin Film
C811 VCFYDA2AA224J AD 0.22 µ F,100V,Thin Film
C841 VCEAZA0JW108M AC 1000 µ F,6.3V,Electrolytic
C842 VCEAZA1EW477M AD 470 µ F,25V,Electrolytic
C843 VCQYKA1HM473K AB 0.047 µ
F,50V,Mylar
!
C844 RC-KZ002LAWZZ AC 0.0047 µ F,250V,Ceramic
C851 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C854 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C855 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C856 VCEAZW1EW338M AG 3300 µ F,25V,Electrolytic
C858 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C859 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C861 VCKYPA1HF223Z AB 0.022 µ F,50V
C863 VCEAZA1EW226M AB 22 µ F,25V,Electrolytic
C864 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C865 VCEAZA1HW106M AB 10 µ F,50V,Electrolytic
C901 VCEAZA1HW104M AB 0.1 µ F,50V,Electrolytic
C902 VCEAZA1HW104M AB 0.1 µ F,50V,Electrolytic
C903 VCKYCY1HB102K AA 0.001 µ F,50V
C904 VCKYCY1HB102K AA 0.001 µ F,50V
C905 VCEAZA1HW226M AB 22 µ F,50V,Electrolytic
C906 VCEAZA1HW226M AB 22 µ F,50V,Electrolytic
C907 VCCCCY1HH101J AA 100 pF (CH),50V
C908 VCCCCY1HH3R0C AA 3 pF (CH),50V
C909 VCQYKA1HM104K AB 0.1 µ F,50V,Mylar
C910 VCCCCY1HH3R0C AA 3 pF (CH),50V
C911 VCEAZA2AW107M AD 100 µ F,100V,Electrolytic
C912 VCEAZA2AW107M AD 100 µ F,100V,Electrolytic
C913 VCCCCY1HH101J AA 100 pF (CH),50V
C914 VCEAZA2AW107M AD 100 µ F,100V,Electrolytic
C915 VCEAZA2AW107M AD 100 µ F,100V,Electrolytic
C916 VCEAZA1HW107M AC 100 µ F,50V,Electrolytic
C917 VCKYCY1HB103K AA
0.01 µ F,50V
C918 VCEAZA1HW107M AC 100 µ F,50V,Electrolytic
C919 VCKYCY1HB103K AA 0.01 µ F,50V
C920 RC-EZ3011AWZZ 3300 µ F,63V,Electrolytic
C921 RC-EZ0115AWZZ AH 4700 µ F,35V,Electrolytic
C922 RC-EZ0115AWZZ AH 4700 µ F,35V,Electrolytic
C923 RC-EZ3011AWZZ 3300 µ F,63V,Electrolytic
C925 VCEAZA1HW476M AB 47 µ F,50V,Electrolytic
C928 VCFYFA1HA104J AC 0.1 µ F,50V,Thin Film
C929 VCFYFA1HA104J AC 0.1 µ F,50V,Thin Film
C931 VCEAZA1HW106M AB 10 µ F,50V,Electrolytic
C946 VCEAZA1HW104M AB 0.1 µ F,50V,Electrolytic
C960 VCEAZA1EW335M AB 3.3 µ F,25V,Electrolytic
[9] RESISTORS
VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R05 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R06 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R7 VRD-ST2CD470J AA 47 ohms,1/6W
R8 VRS-CY1JB100J AA 10 ohm,1/16W
R9 VRD-ST2CD102J AA 1 kohm,1/6W
R10 VRD-ST2CD562J AA 5.6 kohms,1/6W
R11 VRD-ST2CD682J AA 6.8 kohms,1/6W
R12 VRD-ST2CD103J AA 10 kohm,1/6W
R13 VRD-ST2CD103J AA 10 kohm,1/6W
R14 VRS-CY1JB103J AA 10 kohm,1/16W
R15 VRS-CY1JB103J AA 10 kohm,1/16W
R16 VRS-CY1JB331J AA 330 ohms,1/16W
R17 VRD-ST2CD330J AA 33 ohms,1/6W
R18 VRS-CY1JB1R0J AA 1 ohm,1/16W
R19 VRD-ST2CD682J AA 6.8 kohms,1/6W
[8] CAPACITORS
