XL-MP130
13
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[11] CD MECHANISM PARTS
301 NGERH0011AWZZ AC Gear,Middle
302 NGERH0012AWZZ AC Gear,Drive
304 NSFTM0020AWFW AD Shaft,Guide
305 92LMCUSN1524A AD Cushion
!
306 92LHPC1LFASY BB Pickup Unit Ass'y
306- 1 -------- - Pickup Unit (Not Replacement Item)
306- 2 NGERR0043AFZZ AC Gear,Rack
306- 3 MSPRC0961AFZZ AA Spring,Rack
307 PCUSG0001AWSA AD Cushion
308 PCUSG0004AWSA AD Cushion
701 XBSSD26P06000 AA Screw,M2.6x6mm
703 XBBSD20P03000 AA Screw,M2x3mm
704 LX-WZ1070AFZZ AA Washer,M1.5xM3.8x0.25mm
M1A 92LMTR5515CASY AS Motor with Chassis [Spindle]
M2A 92LMTR1854BASY AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 AD Switch,Leaf Type [Pickup In]
