XL-MP130
19
NO.
P
ARTS CODE
PRICE
RANK
NEW
MARK
PA
R
T
RANK
DESCRIPTION
[14] SPEAKER BOX P
ARTS
901
GBOXSA076
AW01
BF
Speaker Box Ass'y
902
CWAKPA010
AW01
AR
Net Frame Ass'y
903
HPNLSA036
AWSB
AU
Front Panel
904
LHLDZ8001
AWSA
AD
Catching Holder
905
PCUSGA020
AWZZ
AB
Cushion,Foot
906
TSPC-A365
AWZZ
AC
Label,Specification
907
XEBSN30P1
0000
AA
Screw,M3x10mm
908
XEPSN40P1
6000
AC
Screw,M4x16mm
SP1,2
RSP-ZA
084AWZZ
AZ
Woofer
SP3,4
RSP-ZA
085AWZZ
Tweeter
76
78
