XL-MP333H/XL-MP444H
8 – 5
IC701 RH-iX0058SJZZ: System Microcomputer (IX0058SJ) (1/2)
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
Pin No. Port Name Terminal Name Input/Output Function
1 P16/T1PWML TIMER LED Output LED DRIVER (H LED ON).
2* P17/T1PWMH/BUZ P MUTE Output MUTE (03.11.4).
3* PWM2/IN4/T1IN PROG1 — PROGRAM USE.
4* PWM3/IN4/T1IN PROG2 — PROGRAM USE.
5* P32/IN4/T1IN PROG3 — PROGRAM USE.
6 P33/IN4/T1IN P_CON Output POWER CONTROL.
7
7*
(XL-MP333H)
P34/IN5/T1IN FAN_START Output FAN START.
8 P35/IN5/T1IN NO USE —
9 P36/IN5/T1IN/AN12 NO USE —
10* P37/IN5/T1IN/AN13 NO USE —
11 RES RESET IN PUT —
12 XT1/AN10 CRYSTAL IN —
13 XT2/AN11 CRYSTAL OUT —
14 VSS1 GND —
15 CF1 CRYSTAL IN —
16 CF2 CRYSTAL IN —
17 VDD1 VDD1 —
18 P80/AN0 KEY1 Input [AD] KEY SCAN1.
19 P81/AN1 KEY2 Input [AD] KEY SCAN2.
20 P82/AN2 POWER KEY Input POWER KEY (FOR TEST MODE).
21 P83/AN3 NO USE —
22 P84/AN4 NO USE —
23 P85/AN5 FAN_PRO Input [AD] FAN PROTECT.
24 P86/AN6 PATCH_DATA Input 12C SDA (EEPROM DATA).
25 P87/AN7/MICIN MODEL_CHECK Input [AD] DIFFERENT COUNTRY SELECT.
26 P70/INT0/TOLCP/
AN8
SYS_STOP Input [INT] SYSTEM STOP CHECK OUT.
27 P71/INT1/TOHCP/
AN9
CD WRQ Input CD WRQ.
28 P72/INT2/TOIN/
NKIN
NO USE —
29 P73/INT3/TOIN IRQ Input [INT] REMOTE SIGNAL INPUT.
30 S0/T0 1G — VFD SEGMENT.
31 S1/T1 2G — VFD SEGMENT.
32 S2/T2 3G — VFD SEGMENT.
33 S3/T3 4G — VFD SEGMENT.
34 S4/T4 5G — VFD SEGMENT.
35 S5/T5 6G — VFD SEGMENT.
36 S6/T6 7G — VFD SEGMENT.
37 S7/T7 8G — VFD SEGMENT.
38 S8/T8 9G — VFD SEGMENT.
39 S9/T9 10G — VFD SEGMENT.
40 S10/T10 11G — VFD SEGMENT.
41* S11/T11 NO USE — VFD SEGMENT.
42 S12/T12 P1 — VFD SEGMENT.
43 S13/T13 P2 — VFD SEGMENT.
44 S14/T14 P3 — VFD SEGMENT.
45 S15/T15 P4 — VFD SEGMENT.
46 VDD3 VDD3 —
47 S16/PC0 P5 — VFD SEGMENT.
48 S17/PC1 P6 — VFD SEGMENT.
49 S18/PC2 P7 — VFD SEGMENT.
50 S19/PC3 P8 — VFD SEGMENT.
51 FIX0 GND —
52 S20/PC4 P9 — VFD SEGMENT.
53 S21/PC5 P10 — VFD SEGMENT.
To Next Page
