Sharp XL-MP80H Service Manual

XL-MP80H/MP80E
1 – 2
[2] SPECIFICATIONS
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
XL-MP80H
■ General
■ Amplifier
■ Tuner
■ CD player
■ Cassette deck
■ Speaker
Power source AC 230 V, 50 Hz
Power
consumption
Power on: 83 W
Power s tand-by: 0.6 W
Dimensions Width: 16 0 mm (6-5/16")
Height: 228 mm (9")
Depth: 248 mm (9-13/16")
Weight 3.8 k g (8.4 lbs.)
Output power PMPO: 120 W (total)
MPO: 60 W (30 W + 30 W) (DIN 45 324)
RMS: 40 W (20 W + 20 W) (DIN 45 324)
RMS: 30 W (15 W + 15 W) (DIN 45 500)
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
CD digital output (optical)
Input terminals Video/Auxiliary (audio signal):
500 mV/47 k ohms
Frequency range FM: 87.5 - 108 MHz
AM: 522 - 1,620 kHz
Type Compact disc p layer
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency
response
50 - 14,000 Hz (normal t ape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.3 % (DIN 45 511)
Type 2-way type speaker system
4 cm (1-9/16") semi dome t weeter
9 cm (3-9/16") woofer
Maximum input
power
40 W
Rated input power 20 W
Impedance 6 ohms
Dimensions Width: 130 mm (5-1/8")
Height: 228 mm (9")
Depth: 172 mm (6-3/4")
Weight 1.8 kg (4.0 lbs.) /each
XL-MP80E
■ General
■ Amplifier
■ Tuner
■ CD player
■ Cassette deck
■ Speaker
Power source AC 230 - 240 V, 50 Hz
Power
consumption
Power on: 83 W
Power s tand-by: 0.6 W
Dimensions Width: 16 0 mm (6-5/16")
Height: 228 mm (9")
Depth: 248 mm (9-13/16")
Weight 3.8 k g (8.4 lbs.)
Output power RMS: 40 W (20 W + 20 W) (10 % T.H.D.)
RMS: 30 W (15 W + 15 W) (0.9 % T.H.D.)
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
CD digital output (optical)
Input terminals Video/Auxiliary (audio signal):
500 mV/47 k ohms
Frequency range FM: 87.5 - 108 MHz
AM: 522 - 1,620 kHz
Type Compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency
response
50 - 14,000 Hz (normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.25 % (WRMS)
Type 2-way type speaker system
4 cm (1-9/16") semi dome t weeter
9 cm (3-9/16") woofer
Maximum input
power
40 W
Rated input power 20 W
Impedance 6 ohms
Dimensions Width: 130 mm (5-1/8")
Height: 228 mm (9")
Depth: 172 mm (6-3/4")
Weight 1.8 kg ( 4.0 lbs.)/each
Specifications for this model are subject to change without prior notice.
