XL-MP80H/MP80E
2 – 2
3. CD SECTION
• Adjustment
Since this CD system incorporates the following automatic adjust-
ment functions, readjustment is not needed when replacing the
pickup. Therefore, different PWBs and pickups can be combined
freely.
Each time a disc is changed, these adjustments are performed
automatically. Therefore, playback of each disc can be performed
under optimum conditions.
[2] TEST MODE
Test Mode Key Operation
All test modes can be terminated by turning off the power with POWER key.
• Preset clear test
All tuner preset stations are cleared.
• Preset set test
Stations are set according to destination.
• Display test
When test mode is activated, the entire display lights up. As the “PLAY” button is pressed, half of the display lights up alternately.
• CD test
In step 5, hold down the AUX button on the remote control. The tracking servo is switched on/off.
From step 3, the pick up can be moved with the FF/REW button.
KEY1 KEY2 KEY3 TEST CONTENTS INDICATION
Memory Preset Down Power Preset clear Tu CL
Memory Stop Power Preset set FM P-01
Memory Play Power Display
Memory Preset up Power CD TEST-1
Memory REC Power Soft reset CLEAR
Bass/treble Preset down Power Volume TEST-3
Bass/treble Play Power Timer test TEST-4
Bass/treble TAPE-REC Power all key TEST-6
Bass/treble Stop Power Tuner aspm TEST-7
CH BAND FREQUENCY
1 FM STEREO FM 87.50 MHz
2 FM 108.00 MHz
3 FM 98.00 MHz
4 FM 90.00 MHz
5 FM 106.00 MHz
1 AM AM 522 kHz
2 AM 1620 kHz
3 AM 990 kHz
4 AM 603 kHz
5 AM AM 1404 kHz
AM6-30
FM11-30
·
35
36 FM MONO FM 106.00 MHz
37 FM 90.00 MHz
38 FM 98.00 MHz
39 FM 108.00 MHz
40 FM 87.50 MHz
CH BAND FREQUENCY
[cd step 1] Enter test mode.
←———————
↓ Hold down the “memory” button
[cd step 2] After some steps, the laser turns on.
↓ Hold down the “memory” button
[cd step 3] After some steps, focus search is performed.
↓ Hold down the “memory” button
[cd step 4] After some steps, CLV rotation is performed.
↓ Hold down the “memory” button
[cd step 5] CD playback starts.
↓ Hold down the “stop” button to return to [cd step 1] ––––––––––
