XL-MP80H/MP80E
8 – 7
IC801 VHIMN6627933C: CD Digital Signal Processor (MN6627933C) (2/2)
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
NOTE: Signals with * are switched to other signals by microcomputer command.
DRAM pins differ in specifications depending on the type and capacity.
NOTE: When sharing the PCB with MN6627932, connect pins as follows:
No. 62 pin (N.C. pin) = L (fixed), No. 54 pin (N.C. pin): LOVDD2, No. 65 pin (N.C. pin): LOVSS2
Refer to the MN6627932 specifications for the product details.
Pin No. Terminal Name I/O Function
58 LOOUTL O Left channel audio signal output for line-out output
59 LOVSS1 I Line-out output GND
60 LOOUTR O Right channel audio signal output for line-out output
61 LOVDD1 I Line-out output power supply
62* N.C. —
63* TMON O Test monitor output 1
64 N.C. —
65 N.C. —
66* TMON2 O Test monitor output 2
67 DVDD3 I Digital circuit power supply 3
68 DVSS2 I Digital circuit GND 2
69* *EXT0 I/O Extended input/output port 0
70* *EXT1 I/O Extended input/output port 1
71* *EXT2 I/O Extended input/output port 2
72 MCLK I Microcomputer command clock signal input
73 MDATA I Microcomputer command data signal input
74 MLD I Microcomputer command load signal input
75 *STAT O Status signal output
76 *BLKCK O Sub code block clock signal output
77* *SMCK O 4.2336/8.4672 MHz clock signal output
78* *PMCK O 88.2 kHz clock signal output
79 *TX O Digital audio interface signal output
80 *FLAG O Flag signal output
81 NRST I LSI reset signal input
82 NTEST I Test mode setting input
83 DVSS3 I Digital circuit GND 3
84 X1 I Crystal oscillation circuit input
85 X2 O Crystal oscillation circuit output
86 IOVDD2 I Digital I/O power supply 2
87 DVDD2 I Internal digital circuit power supply 2
88 D2 I/O DRAM data signal input/output 2
89 D1 I/O DRAM data signal input/output 1
90 D0 I/O DRAM data signal input/output 0
91 D3 I/O DRAM data signal input/output 3
92 D4 I/O DRAM data signal input/output 4
93 D5 I/O DRAM data signal input/output 5
94 D6 I/O DRAM data signal input/output 6
95 D7 I/O DRAM data signal input/output 7
96 D15 I/O DRAM data signal input/output 15
97 D14 I/O DRAM data signal input/output 14
98 DRVDD2 I DRAM interface I/O power supply 2
99 D13 I/O DRAM data signal input/output 13
100 D12 I/O DRAM data signal input/output 12
