Sharp XL-MP80H Service Manual

XL-MP80H/MP80E
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] INTEGRATED CIRCUITS
IC201 VHISTK45303-1 AS Power,STK45303
IC301 VHILV23002M-1 AS PLL (Tuner)/FM IF Det./FM Mpx./AM IF,LV23002M
IC351 VHILC72723D-1 AP RDS,LC72723D [H,Only]
IC401 VHIKIA7805API AF Voltage Regulator,KIA7805AP
IC501 VHIBD3881FV-1 AP Record/Playback Amp.,BD3881FV
IC601 VHINJM14558-1 AF Pre. Amp.,NJM14558
IC701 RH-IXA013SJZZ AX System Microcomputer,IXA013SJ
IC801 VHIMN6627933C BB CD Digital Signal Processor,MN6627933C
IC802 RH-IXA018SJZZ AX MP3 DECODER,IXA018SJ
IC803 VHIAN22004A-1 AN Servo Amp.,AN22004A
IC804 VHIAN8785SB-1 AP Focus/Tracking/Spin/Sled Driver,AN8785SB
IC805 VHIHY57V16D-1 AT DRAM,HY57V16D
[2] TRANSISTORS
Q101 VS2SB1370E+-1 AG Silicon,PNP,2SB1370 E+
Q102 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q103 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q104 VSKTA1266GR-1 AB Silicon,PNP,KTA1266 GR
Q105 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q201 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q251 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q252 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q254 VS2SA1235F+-1 AD Silicon,PNP,2SA1235 F+
Q255 VS2SA1514K/-1 AC Silicon,PNP,2SA1514 K
Q256 VS2SA1514K/-1 AC Silicon,PNP,2SA1514 K
Q257 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q301 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q305 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q351 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q352 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+ [H,Only]
Q353 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+ [H,Only]
Q371 VS2SC5477++-1 AD Silicon,NPN,2SC5477++
Q401 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q402 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q403 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q404 VS2SA1235F+-1 AD Silicon,PNP,2SA1235 F+
Q501 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q502 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q503 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q504 VS2SA1235F+-1 AD Silicon,PNP,2SA1235 F+
Q505 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q506 VS2SA2002EF-1 AE Silicon,PNP,2SA2002 EF
Q507 VS2SA2002EF-1 AE Silicon,PNP,2SA2002 EF
Q508 VS2SA1235F+-1 AD Silicon,PNP,2SA1235 F+
Q509 VSKTC2875B/-1 AC Silicon,NPN,KTC2875 B
Q510 VSKTC2875B/-1 AC Silicon,NPN,KTC2875 B
Q511 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q512 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q513 VSKTC2875B/-1 AC Silicon,NPN,KTC2875 B
Q601 VS2SK2158//-1 AB FET,2SK2158
Q602 VS2SK2158//-1 AB FET,2SK2158
Q603 VS2SA1235F+-1 AD Silicon,PNP,2SA1235 F+
Q701 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q702 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q703 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q704 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q705 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q706 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q708 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q801 VS2SA1235F+-1 AD Silicon,PNP,2SA1235 F+
Q802 VS2SK2158//-1 AB FET,2SK2158
Q803 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q804 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q805 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q806 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q807 VSKRA102S//-1 AB Digital,PNP,KRA102 S
Q808 VSKRC102S//-1 AB Digital,NPN,KRC102 S
[3] DIODES
!
D1 VHD1N4148//-1 AA Silicon,1N4148
!
D2 VHD1N4148//-1 AA Silicon,1N4148
!
D3 VHD1N4148//-1 AA Silicon,1N4148
!
D4 VHD1N4148//-1 AA Silicon,1N4148
D101 VHDRL203///-1 AC Silicon,RL203
D102 VHDRL203///-1 AC Silicon,RL203
D103 VHDRL203///-1 AC Silicon,RL203
D104 VHDRL203///-1 AC Silicon,RL203
D105 VHDMC2836//-1 AB Silicon Epitaxial Double,MC2836
D106 VHEDZH07A3+-1 AB Zener,??V,DZH07A3+
D107 VHD1N4148//-1 AA Silicon,1N4148
D108 VHD1N4004//-1 AB Silicon,1N4004
D109 VHD1N4004//-1 AB Silicon,1N4004
D110 VHEDZH2701+-1 AB Zener,26.6V,DZH271
D201 VHD1N4148//-1 AA Silicon,1N4148
D251 VHDMC2838//-1 AB Silicon Epitaxial Double,MC2838
