Sharp XL-MP9H Service Manual

XL-MP9H
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] INTEGRATED CIRCUITS
IC7A1 VHIAT24C04/-1 AH EEPROM,AT24C04
IC101 VHILA4631++-1 AM Power Amp.,LA4631++
IC102 VHIAN78L05/-1 AE Constant Voltage Regulator,AN78L05
IC302 VHILC72131/-1 AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 AN FM IF Det./FM Mpx./AM IF,LA1832S
IC521 VHILC72723M-1 AS RDS,LC72723M
IC601 VHILC75341M-1 AM Signal Control Audio Processor,LC75341M
IC602 VHINJM14558-1 AF Pre. Amp.,NJM14558
IC701 RH-IXA054SJZZ AY System Microcomputer,IXA054SJ
IC801 VHILC78690/-1 BE MP3 Decoder Digital Signal Processor,LC78690
IC802 VHILA6548ND-1 AL Focus/Tracking/Spin/Sled Driver,LA6548ND
[2] TRANSISTORS
Q101 VS2SB1370E+-1 AG Silicon,PNP,2SB1370 E+
Q102 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q103 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q104 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q105 VS2HA1015GR-1 AB Silicon,PNP,2HA1015 GR
Q106 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q107 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q108 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q109 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q301 VS2SC380-O/-1 AC Silicon,NPN,2SC380 O
Q351 VSKRC104M//-1 AC Digital,NPN,KRC104 M
Q360 VS2HA1015GR-1 AB Silicon,PNP,2HA1015 GR
Q521 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q601 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q602 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q603 VSKRA107M//-1 AE Digital,NPN,KRA 107 M
Q701 VSKTA1271Y/-1 AC Silicon,PNP,KTA1271 Y
Q702 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q703 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q704 VSKTA1271Y/-1 AC Silicon,PNP,KTA1271 Y
Q705 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q706 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q707 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q708 VS2SC5395F+-1 AD Silicon,NPN,2SC5395 F+
Q709 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q710 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q801 VS2SA1235F+-1 AD Silicon,PNP,2SA1235 F+
Q802 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q803 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q805 VS2SC3052F+-1 AD Silicon,NPN,2SC3052 F+
Q806 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q808 VS2HC1815GR-1 AB Silicon,NPN,2HC1815 GR
Q809 VSKTC3205Y/-1 AD Silicon,NPN,KTC3205 Y
Q810 VS2HA1015GR-1 AB
Silicon,PNP,2HA1015 GR
[3] DIODES
D101 VHD1N5395//-1 AB Silicon,1N5395
D102 VHD1N5395//-1 AB Silicon,1N5395
D103 VHD1N5395//-1 AB Silicon,1N5395
D104 VHD1N5395//-1 AB Silicon,1N5395
D105 VHD1N4004//-1 AB Silicon,1N4004
D109 VHD1N4004//-1 AB Silicon,1N4004
D110 VHD1SS133//-1 AA Silicon,1SS133
D112 VHD1N4148//-1 AA Silicon,1N4148
D113 VHD1N4148//-1 AA Silicon,1N4148
D114 VHD1N4148//-1 AA Silicon,1N4148
D201 VHD1N4148//-1 AA Silicon,1N4148
D202 VHD1N4148//-1 AA Silicon,1N4148
D301 VHD1N4148//-1 AA Silicon,1N4148
D302 VHD1N4148//-1 AA Silicon,1N4148
D303 VHD1N4148//-1 AA Silicon,1N4148
D304 VHD1N4148//-1 AA Silicon,1N4148
D308 VHD1N4148//-1 AA Silicon,1N4148
D521 VHD1N4148//-1 AA Silicon,1N4148
D601 VHD1N4148//-1 AA Silicon,1N4148
D602 VHD1N4148//-1 AA Silicon,1N4148
D701 VHD1N4148//-1 AA Silicon,1N4148
D702 VHD1N4148//-1 AA Silicon,1N4148
D703 VHD1N4148//-1 AA Silicon,1N4148
D704 VHD1N4148//-1 AA Silicon,1N4148
D705 VHD1N4148//-1 AA Silicon,1N4148
D708 VHD1N4148//-1 AA Silicon,1N4148
D801 VHD1N4148//-1 AA Silicon,1N4148
D802 VHD1N4148//-1 AA Silicon,1N4148
D803 VHD1N4004//-1 AB Silicon,1N4004
D804 VHD1N4004//-1 AB Silicon,1N4004
D805 VHD1N5395//-1 AB Silicon,1N5395
LED701 VHPLPBB73VQ-1 AF LED,White,LPBB73VQ
LED702 VHPLPBB73VQ-1 AF LED,White,LPBB73VQ
VD301 VHCSVC348S/-1 AK
Variable Capacitance,SVC348S
ZD111 VHEDZH11B1+-1 AB N Zener,10V,DZH11B1+
ZD115 VHEDZH05C2+-1 AB Zener,5.1V,DZH05C2+
