Sharp XL-MP9H Service Manual

XL-MP9H
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
ZD351 VHEDZH05C2+-1 AB Zener,5.1V,DZH05C2+
ZD701 VHEMM3Z6V2+-1 N Zener,6.2V,MM3Z6V2+
ZD702 VHEMM3Z6V2+-1 N Zener,6.2V,MM3Z6V2+
ZD703 VHEMM3Z6V2+-1 N Zener,6.2V,MM3Z6V2+
ZD704 VHEMM3Z6V2+-1 N Zener,6.2V,MM3Z6V2+
ZD801 VHEDZH05C2+-1 AB Zener,5.1V,DZH05C2+
ZD802 VHEDZH04B2+-1 AB Zener,3.9V,DZH04B2+
ZD803 VHEDZH09A2+-1 AB N Zener,8.2V,DZH09A2+
[4] FILTERS
CF301 RFILFA001SJZZ AE FM IF
CF302 RFILFA001SJZZ AE FM IF
CF351 RFILF0003AWZZ AK FM IF
CF352 RFILA0003SJZZ AF AM IF
[5] TRANSFORMERS
!
PT1 RTRNPA045SJZZ AX N Power
T302 RCILAA002SJZZ AC AM Antenna
T306 RCILBA006SJZZ AC AM OSC.
T351 RCILIA002SJZZ AC AM IF
[6] COILS
!
L101 RCILZ0005SJZZ AF Line Filter
L102 RCILZA001SJZZ AC Line Filter
L103 RCILZA001SJZZ AC Line Filter
L104 VP-DH1R0K0000 AC 1 µ H
L105 RCILCA004SJZZ AB 3.3 µ H
L201 RCILCA004SJZZ AB 3.3 µ H
L202 RCILCA004SJZZ AB 3.3 µ H
L203 RCILCA004SJZZ AB 3.3 µ H
L341 RBLN-0001SJZZ AE Balun
L342 VP-DH2R2K0000 AB 2.2 µ H,Peaking
L351 VP-DH101K0000 AB 100 µ H,Choke
L352 VP-DH101K0000 AB 100 µ H,Choke
L353 VP-DH102K0000 AB 1 mH,Choke
L354 RFILL0001SJZZ AF Low Pass Filter
L502 VP-DHR82K0000 AE 0.82 µ H,Choke
L521 VP-DH2R2K0000 AB 2.2 µ H,Peaking
L601 RCILCA004SJZZ AB 3.3 µ H
L602 RCILCA004SJZZ AB 3.3 µ H
L603 RCILCA004SJZZ AB 3.3 µ H
L701 VP-DH220K0000 AB 22 µ H,Choke
L702 VP-DH2R2K0000 AB 2.2 µ H,Peaking
L801 VP-DH2R2K0000 AB 2.2 µ H,Peaking
L804 VP-DHR82K0000 AE 0.82
µ H,Choke
L805 RBLN-A003SJZZ AB Ferrite Bead,1 kohms
L806 RBLN-A003SJZZ AB Ferrite Bead,1 kohms
[7] VIBRATORS
X351 RCRM-0007SJZZ AG VCO,456 kHz
X352 RCRSP0003SJZZ AL Crystal,4.5 MHz
X521 RCRSP0005SJZZ AF Crystal,456 kHz
X702 RCRSP0007SJZZ AE Crystal,32.768 kHz
X801 RCRSP0002SJZZ AL Crystal,16.93 MHz
[8] CAPACITORS
C7A1 VCKYCY1EF104Z AA 0.1 µ F,25V
C101 VCKYCY1EF473Z AB 0.047 µ F,25V
C102 VCKYCY1HB472K AA 0.0047 µ F,50V
C103 VCKYCY1HB472K AA 0.0047 µ F,50V
C104 VCKYCY1EF104Z AA 0.1 µ F,25V
C105 VCKYCY1EF104Z AA 0.1 µ F,25V
C106 VCKYCY1HB472K AA 0.0047 µ F,50V
C107 VCKYCY1HB472K AA 0.0047 µ F,50V
C108 VCKYCY1EF104Z AA 0.1 µ F,25V
C109 VCKYCY1EF104Z AA 0.1 µ F,25V
C110 VCKYCY1HB472K AA 0.0047 µ F,50V
C111 VCKYPA1HB331K AA 330 pF,50V
C112 VCKYCY1HB331K AA 330 pF,50V
C115 RC-GZV108AF1E AD 1000 µ F,25V,Electrolytic
C116 RC-GZV108AF1E AD 1000 µ F,25V,Electrolytic
C117 RC-GZA226AF1H AB 22 µ F,50V,Electrolytic
C118 RC-GZA226AF1C AB 22 µ F,16V,Electrolytic
C119 RC-GZA107AF1C AB 100 µ F,16V,Electrolytic
C120 VCKYCY1EF104Z AA 0.1 µ F,25V
C121 RC-GZA475AF1H AB 4.7 µ F,50V,Electrolytic
C122 RC-GZA475AF1H AB 4.7 µ F,50V,Electrolytic
C123 RC-GZA105AF1H AB 1 µ F,50V,Electrolytic
C124 VCKYCY1HB103K AA 0.01 µ F,50V
C125 RC-GZA105AF1H AB 1 µ F,50V,Electrolytic
C126 RC-GZA476AF1E AB 47 µ F,25V,Electrolytic
C127 VCTYPA1CX223K AA 0.022 µ F,16V
C128 VCKYCY1EF104Z AA 0.1 µ F,25V
C129 RC-GZV228AF1C AG 2200 µ F,16V,Electrolytic
[3] DIODES
