05/5/23 XL-MP9H(H)E3.fm
E-30
ENGLISH
TINSZA058SJZZ
XL-MP9H
8
References
Specifications
As part of our policy of continuous improvement, SHARP reserves
the right to make design and specification changes for product
improvement without prior notice. The performance specification fig-
ures indicated are nominal values of production units. There may be
some deviations from these values in individual units.
! General
! Amplifier
! Tuner
! CD player
! Speaker
Power source AC 230 V, 50 Hz
Power
consumption
Power on: 25 W
Power stand-by: 0.9 W
Dimensions Width: 100 mm (3-15/16")
Height: 205 mm (8-1/16")
Depth: 240 mm (9-7/16")
Weight 2.1 kg (4.6 lbs.)
Output power PMPO: 30 W (total)
MPO: 15 W (7.5 W + 7.5 W) (DIN 45 324)
RMS: 10 W (5 W + 5 W) (DIN 45 324)
Output terminals Speakers: 4 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Line output: 2 k ohms
Input terminals Line input: 47 k ohms
Frequency range FM: 87.5 - 108.0 MHz
AM: 522 - 1,620 kHz
Type Compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Type 8 cm (3-1/8") full-range speaker
Maximum input
power
10 W
Rated input power 5 W
Impedance 4 ohms
Dimensions Width: 100 mm (3-15/16")
Height: 205 mm (8-1/16")
Depth: 193 mm (7-5/8")
Weight 1.2 kg (2.6 lbs.)/each
To Next Page
