Sharp XR-1X Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
132
XR-1X
INTEGRATED CIRCUITS
IC2601 VHiMB8346BV-1Y J MB88346BPFV AN
TRANSISTORS
Q2601 VSHN2A01FU/-1Y J HN2A01FU AC
Q2602 VSHN2A01FU/-1Y J HN2A01FU AC
Q2603 VSHN2A01FU/-1Y J HN2A01FU AC
Q2604 VSHN2A01FU/-1Y J HN2A01FU AC
Q2605 VSHN2A01FU/-1Y J HN2A01FU AC
Q2606 VSHN2A01FU/-1Y J HN2A01FU AC
DUNTKC416FMF5
MAIN UNIT (Continued)
R3507 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3508 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3509 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3510 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3511 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3512 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3513 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3515 VRN-CY1JF752DY J 7.5k 1/16W Metal Film AA
R3516 VRS-CY1JF334FY J 330k 1/16W Metal Oxide AA
R3519 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3520 VRS-CY1JF154JY J 150k 1/16W Metal Oxide AA
R3523 VRS-TW2ED151JY J 150 1/4W Metal Oxide AA
R3525 VRS-TW2ED151JY J 150 1/4W Metal Oxide AA
R3531 VRS-TW2ED151JY J 150 1/4W Metal Oxide AA
R3535 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3539 VRS-TX2HF8R2JY J 8.2 1/2W Metal Oxide AB
R3541 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3543 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R3544 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R3545 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3547 VRS-TX2HF2R7JY J 2.7 1/2W Metal Oxide AB
R3548 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R3549 VRS-CE3AF5R6JY J 5.6 1W Metal Oxide AC
R3550 VRS-CE3AF5R6JY J 5.6 1W Metal Oxide AC
R3552 VRS-CY1JF184FY J 180k 1/16W Metal Oxide AA
R3553 VRN-CY1JF472DY J 4.7k 1/16W Metal Film AA
R3554 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3556 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3557 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3558 VRS-CY1JF154JY J 150k 1/16W Metal Oxide AA
R3562 VRS-CY1JF224JY J 220k 1/16W Metal Oxide AA
R3563 VRS-CY1JF224JY J 220k 1/16W Metal Oxide AA
R3564 VRS-CJ1JF333JY J 33k 1/16W Metal Oxide AA
R3570 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R3571 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3572 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3574 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R3577 VRS-CY1JF203JY J 20k 1/16W Metal Oxide AA
R3578 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3581 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R3583 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3584 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3586 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3587 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R3588 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R3589 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3590 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB1701 RBLN-0209TAZZY J Ferrite Bead AB
FB1702 RBLN-0209TAZZY J Ferrite Bead AB
FB1703 RBLN-0061TAZZY J Ferrite Bead AD
FB1704 RBLN-0061TAZZY J Ferrite Bead AD
FB1705 RBLN-0061TAZZY J Ferrite Bead AD
FB1707 RBLN-0061TAZZY J Ferrite Bead AD
FB1708 RBLN-0061TAZZY J Ferrite Bead AD
FB1709 RBLN-0061TAZZY J Ferrite Bead AD
FB1710 RBLN-0252TAZZY J Ferrite Bead AA
FB1711 RBLN-0252TAZZY J Ferrite Bead AA
FB1712 RBLN-0252TAZZY J Ferrite Bead AA
FB1713 RBLN-0061TAZZY J Ferrite Bead AD
FB1714 RBLN-0252TAZZY J Ferrite Bead AA
FB1715 RBLN-0252TAZZY J Ferrite Bead AA
FB1716 RBLN-0061TAZZY J Ferrite Bead AD
FB1717 RBLN-0252TAZZY J Ferrite Bead AA
FB1718 RBLN-0252TAZZY J Ferrite Bead AA
FB1719 RBLN-0061TAZZY J Ferrite Bead AD
FB1731 RBLN-0250TAZZY J Ferrite Bead AC
FB1733 RBLN-0250TAZZY J Ferrite Bead AC
FB2001 RBLN-0064TAZZY J Ferrite Bead AB
FB2002 RBLN-0210TAZZY J Ferrite Bead AB
FB2202 RBLN-0210TAZZY J Ferrite Bead AB
FB2203 RBLN-0210TAZZY J Ferrite Bead AB
FB2204 RBLN-0210TAZZY J Ferrite Bead AB
FB2205 RBLN-0210TAZZY J Ferrite Bead AB
FB2501 RBLN-0006TAZZY J Ferrite Bead AB
FB2502 RBLN-0006TAZZY J Ferrite Bead AB
FB3001 RBLN-1037CEZZY J Ferrite Bead AB
FB3002 RBLN-1037CEZZY J Ferrite Bead AB
FB3003 RBLN-1037CEZZY J Ferrite Bead AB
FB3004 RBLN-1037CEZZY J Ferrite Bead AB
FB3005 RBLN-0061TAZZY J Ferrite Bead AD
FB3006 RBLN-1037CEZZY J Ferrite Bead AB
FB3007 RBLN-0252TAZZY J Ferrite Bead AA
FB3008 RBLN-0252TAZZY J Ferrite Bead AA
FB3009 RBLN-0252TAZZY J Ferrite Bead AA
FB3011 RBLN-0058CEZZY J Ferrite Bead AB
FB3012 RBLN-0058CEZZY J Ferrite Bead AB
FB3013 RBLN-0058CEZZY J Ferrite Bead AB
FB3301 RBLN-1037CEZZY J Ferrite Bead AB
FB3302 RBLN-0252TAZZY J Ferrite Bead AA
FB3303 RBLN-0252TAZZY J Ferrite Bead AA
FB3304 RBLN-0252TAZZY J Ferrite Bead AA
FB3351 RBLN-1037CEZZY J Ferrite Bead AB
FB3361 RBLN-1037CEZZY J Ferrite Bead AB
FB3501 RBLN-0061TAZZY J Ferrite Bead AD
FB3505 RBLN-0210TAZZY J Ferrite Bead AB
FB3506 RBLN-0061TAZZY J Ferrite Bead AD
FB3507 RBLN-0061TAZZY J Ferrite Bead AD
FB3508 RBLN-0253TAZZY J Ferrite Bead AA
FB3509 RBLN-0253TAZZY J Ferrite Bead AA
FB3510 RBLN-0253TAZZY J Ferrite Bead AA
FB3511 RBLN-0253TAZZY J Ferrite Bead AA
FB3545 RBLN-0070TAZZY J Ferrite Bead AA
FB3561 RBLN-1037CEZZY J Ferrite Bead AB
FB3562 RBLN-1037CEZZY J Ferrite Bead AB
J2501 QSOCZA074WJZZ J Jack, USB AD
J3303 QTANZA020WJZZ J Earphone Jack AF
J3561 QJAKAA001WJZZ J Jack, AUDIO-IN AD
P1701 QPLGN1280GEZZ J Plug, 12Pin(EA) AC
P1702 QPLGN0363TAZZY J Plug, 3Pin(CW) AC
P1703 QPLGN0258REZZY J Plug, 2Pin(LF) AD
P1711 QPLGN0364TAZZY J Plug, 3Pin(FA) AC
P1712 QPLGN0565FJZZY J Plug, 3Pin(FB) AD
P1713 QPLGN0566FJZZY J Plug, 4Pin(FC) AD
P2202 QEARBA011WJFMY J Earth AE
P2501 QPLGN0458REZZY J Plug, 4Pin(RS) AD
P3503 QPLGN0564FJZZY J Plug, 2Pin(SO) AD
RMC3501 RRMCUA027WJZZ J Remote Receiver, Front AK
RMC3502 RRMCUA027WJZZ J Remote Receiver, Rear AK
S2001 QSW-S0203TAZZY J Switch, Normal/Write AD
S2551 QSW-K0099TAZZY J Service Switch AC
SC2502 QCNCW0031CEZZY J Socket, 122Pin AM
SC2551 QSOCNA002WJPZY J Socket, 20Pin(KY) AD
SC3001 QSOCNA234WJZZ J Socket AH
SC3502 QCNCW0040CEZZY J Socket, 4Pin(DD) AB
SLD3501 PSLDC0002SEFN J Shield AC
SLD3502 PSLDC0002SEFN J Shield AC
DUNTKC432WEF5
KEY Unit
