Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
136
XR-1X
CABINET AND MECHANICAL PARTS
1 Not Available –Top Body Ass'y —
1-1 DBDYTA069WEF0 J Top Body Ass'y AZ
1-1-1 Not Available –Top Body —
1-1-2 GCOVAA772WJSA J LED Cover (Lamp) AB
1-1-3 GCOVAA773WJSA J LED Cover (Zoom/Focus) AB
1-1-4 PSLDHA025WJKZ J Heat Cover (Lamp) AL
1-1-6 LANGFA025WJFW J KENSINGTON Angle AC
1-1-7 PSLDCA020WJZZ J Top Earth Shield AS
1-1-8 PCOVUA045WJZZ J LED Light Shield AC
1-1-9 PSLDHA022WJFW J Heat Cover AE
1-1-10 PSLDHA023WJZZ J Shield AD
1-2 CBTN-A272WEF0 J Operation Button Ass'y AK
1-2-1 JBTN-A272WJSA J Operation Button (Base) AC
1-2-2 JBTN-A273WJSA J Operation Button (Key Top A) AE
1-2-3 JBTN-A274WJSA J Operation Button (Power) AB
1-2-4 JBTN-A308WJSA J Operation Button (Enter) AB
1-2-5 JBTN-A309WJSA J Operation Button (Menu) AB
1-2-6 PSPAGA512WJKZ J Button Spacer AD
1-3 PSLDCA016WJFW J Button Shield AE
1-4 GCOVAA419WJSA J R/C Cover AD
2 Not Available – Bottom Body Ass'y —
2-1 DBDYUA085WEF0 J Bottom Body Ass'y AZ
2-1-1 Not Available – Bottom Body —
2-1-2 LX-NZA023WJFW J Insert Nut M3, x2 AE
2-1-3 LX-NZA014WJFW J Insert Nut M3, x1 AC
2-1-4 QEARPA114WJFW J Earth Board AD
2-1-5 QEARPA117WJFW J Intake Earth AF
2-2 CDORUA016WEF1 J Lamp Door Ass'y AT
2-2-1 Not Available – Lamp Door —
2-2-2 LX-BZ3449CEF9 J Screw, x1 AD
2-2-3 XREUW20-04000 J E-Ring AA
2-3 GLEGPA026WJSA J Adjuster (Rear), x2 AL
2-4 LX-NZA022WJFN J M3 Cap Nut, x2 AC
2-5 LX-HZ3105CEFN J Screw, x1 AB
2-6 QCNW-C178WJQZ J Connecting Cord AL
(Leaf Switch)
2-7 Not Available –Tefron Tape —
3 Not Available – Front Body Ass'y —
3-1 DBDYFA012WEF0 J Front Body Ass'y AR
3-1-1 Not Available – Front Body —
3-1-2 GCOVAA769WJSA J R/C Cover AB
3-1-3 HiNDPB101WJSB J "SHARP" Logo Plate AH
3-1-4 PSLDPA021WJ00 J Light Shield AD
3-2 GLEGPA025WJKB J Adjuster (Front) AW
3-3 LHLDZA362WJKA J Speaker Holder AB
3-4 XEBSN26P08000 J Screw, x4 AA
3-5 RSP-ZA081WJPZ J Speaker AX
4 Not Available –Ventilation Cover Ass'y —
4-1 DCOVAA765WEF1 J Ventilation Cover Ass'y AP
4-1-1 Not Available –Ventilation Cover —
5 Not Available –Terminal Cover Ass'y —
5-1 DCOVAA766WEF1 J Terminal Cover Ass'y AM
5-1-1 Not Available –Terminal Cover —
5-1-3 PSLDMA370WJFW J Terminal Shield AF
5-1-4 XBBSL26P06000 J Screw, x1 AA
6 DUNTKC618WEF0 – Formatter Unit —
6-1 LANGTA125WJFW J DMD Fixing Angle, x1 AD
6-2 LX-BZA057WJFN J Screw M2.5, x1 AB
8 Refer to Optical Mechanism Parts
9 DUNTKC416FMF5 J Main Unit —
10 RDENCA075WJZZ J Power/Ballast Unit CF
11 RUNTKA079WJZZ J AC Inlet Unit —
12 HPNC-A075WJSA J Ventilation Panching AW
13 LHLDZA353WJKZ J Fan Holder AH
14 PSPAGA183WJKZ J Fan Rubber A, x4 AC
15 PSPAGA186WJKZ J Fan Rubber B, x2 AD
16 PSPAGA184WJKZ J Fan Rubber, x2 AD
17 PZETKA072WJKZ J Power Insulator AH
18 QEARPA116WJFW J Earth Plate AD
20 PZETKA100WJZZ J Key SW Sheet AC
21 LX-EZA013WJFN J Screw, x4 AB
22 LX-EZA016WJFN J Screw, x5 AA
23 LX-EZA009WJFN J Screw, x6 AB
24 XEBSN30P08000 J Screw, x1 AA
25 LX-BZA085WJF7 J Screw, x7 AB
26 XBBSL26P06000 J Screw, x2 AA
28 NSFTZ0134CEFW J Nut, x2 AD
29 XEBS926P06000 J Screw, x6 AB
30 DUNTKC432WEF5 – Key Unit —
31 LHLDZA352WJKZ J Ballst Holder AM
32 PSLDMA371WJFW J Ballst Shield (Top) AL
33 PSLDMA373WJFW J Ballst Shield (Bottom) AG
34 PZETKA074WJKZ J Ballst Insu AL
35 Not Available –Tefron Tape for Ballast lead, —
x2
36 NFANRA030WJ00 J Exhst Fan BC
37 NFANRA031WJ00 J Exhst Fan (PW) BC
38 NFANSA016WJ00 J Blow Fan AZ
39 LHLDW1189CEZZ J Wire Holder AC
41 QCNW-C179WJQZ J EA Wire AL
42 QCNW-C220WJQZ J KEY Wire AF
44 QCNW-C221WJQZ J Photo Wure AF
45 98ENZUSYLB7110 J Inlet Output Wire AX
46 HINDPA883WJZZ J Caution Label-A AF
47 HINDPB109WJZZ J NO Upside Down AC
48 LANGTA142WJFW J Bimetal Holder AC
49 PZETKA099WJKZ J Bimetal Cover AD
50 QCNW-C177WJQZ J Bimetal with a lead AX
51 XBBS925P06000 J Screw for Bimetal Cover AA
53 RH-HXA015WJPZ J Thermal Sensor AL
54 PZETKA108WJKZ J Thermistor Tape AC
55 PSPAT0013CEZZ J Spacer AC
56 LHLDW1226CEZZ J Mini Clamp AC
57 QCNW-C866WJQZ J Connecting Cord AD
58 XEBS926P12000 J Screw
59 HiNDPA814WJSB J Terminal Indication Plate AE
