Sharp XR-1X Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
133
XR-1X
DUNTKC618WEF0
FORMATTER UNIT
INTEGRATED CIRCUITS
IC9301 RH-iXA384WJN1Q J 2503253-003 BR
DIODES AND LED'S
D9301 VHDSFPB76//2EY J SFPB76 AD
D9302 VHDSFPB76//2EY J SFPB76 AD
COIL AND TRANSFORMERS
L9301 RCiLP0325TAZZY J Coil AD
L9302 RCiLP0325TAZZY J Coil AD
CAPACITORS
C9102 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9301 RC-KZ0046TAZZY J 4.7 35V Ceramic AD
C9302 RC-KZ0046TAZZY J 4.7 35V Ceramic AD
C9303 RC-KZA109WJZZY J 10 16V Ceramic AC
C9304 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9305 RC-KZA109WJZZY J 10 16V Ceramic AC
C9306 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9307 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9308 RC-KZA048WJZZY J 10 25V Ceramic AD
C9309 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C9310 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C9311 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C9312 VCKYCY1HF104ZY J 0.1 50V Ceramic AA
C9313 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9314 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9315 RC-KZ0072TAZZY J 1 25V Ceramic AC
C9316 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9317 RC-KZ0070TAZZY J 4.7 16V Ceramic AD
C9318 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9501 RC-KZA109WJZZY J 10 16V Ceramic AC
C9502 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9503 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9504 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9505 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9506 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9507 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9508 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9509 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9510 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9511 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9512 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9513 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C9514 RC-KZA109WJZZY J 10 16V Ceramic AC
RESISTORS
R9101 VRS-CJ1JF132JY J 1.3k 1/16W Metal Oxide AA
R9301 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9303 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R9304 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9305 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
MISCELLANEOUS PART
FB9301 RBLN-0253TAZZY J Ferrite Bead AA
FB9302 RBLN-0253TAZZY J Ferrite Bead AA
FB9303 RBLN-0253TAZZY J Ferrite Bead AA
S9101 QSW-S0203TAZZY J SLIDE Switch AD
S9102 QSW-S0203TAZZY J SLIDE Switch AD
SC9102 QCNCM0039CEZZY J Socket, 122Pin AM
DUNTKC432WEF5
KEY UNIT (Continued)
DIODES AND LED'S
D2601 RH-PX0196TAZZY J LED (RED), TEMP AC
D2602 RH-PX0210TAZZY J LED (GREEN/RED), LAMP AC
D2603 RH-PXA038WJZZY J LED (GREEN/RED), POWER AC
D2604 RH-PXA072WJZZY J LED (Orange), - AE
D2605 RH-PXA072WJZZY J LED (Orange), UP AE
D2606 RH-PXA072WJZZY J LED (Orange), + AE
D2607 RH-PXA072WJZZY J LED (Orange), DOWN AE
D2608 RH-PXA072WJZZY J LED (Orange), ENTER AE
D2609 RH-PXA072WJZZY J LED (Orange), MENU AE
CAPACITORS
C2601 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2602 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2603 RC-KZA109WJZZY J 10 16V Ceramic AC
RESISTORS
R2601 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2602 VRS-CH1JF102JY J 1k 1/16W Metal Oxide AA
R2603 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R2604 VRS-CH1JF102JY J 1k 1/16W Metal Oxide AA
R2605 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R2608 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2610 VRS-TV1JD681JY J 680 1/16W Metal Oxide AA
R2612 VRS-TV1JD471JY J 470 1/16W Metal Oxide AA
R2613 VRS-TV1JD681JY J 680 1/16W Metal Oxide AA
R2616 VRS-TV1JD221JY J 220 1/16W Metal Oxide AA
R2617 VRS-TV1JD221JY J 220 1/16W Metal Oxide AA
R2620 VRS-TV1JD681JY J 680 1/16W Metal Oxide AA
R2622 VRS-TV1JD681JY J 680 1/16W Metal Oxide AA
R2624 VRS-TV1JD681JY J 680 1/16W Metal Oxide AA
R2626 VRS-TV1JD681JY J 680 1/16W Metal Oxide AA
R2628 VRS-TV1JD681JY J 680 1/16W Metal Oxide AA
R2630 VRS-TV1JD681JY J 680 1/16W Metal Oxide AA
R2631 VRS-CH1JF272JY J 2.7k 1/16W Metal Oxide AA
R2632 VRS-CH1JF272JY J 2.7k 1/16W Metal Oxide AA
R2633 VRS-CJ1JF272JY J 2.7k 1/16W Metal Oxide AA
R2634 VRS-CJ1JF272JY J 2.7k 1/16W Metal Oxide AA
R2637 VRS-CH1JF472JY J 4.7k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
S2601 QSW-PA012WJZZY J Switch, POWER AD
S2602 QSW-PA012WJZZY J Switch, - AD
S2603 QSW-PA012WJZZY J Switch, DOWN AD
S2604 QSW-PA012WJZZY J Switch, UP AD
S2605 QSW-PA012WJZZY J Switch, ENTER AD
S2606 QSW-PA012WJZZY J Switch, + AD
S2607 QSW-PA012WJZZY J Switch, MENU/HELP AD
SC2601 QSOCNA002WJPZY J Lead Wire Relay (KY) AD
DUNTKC435WEF5
PHOTOSENSOR Unit
INTEGRATED CIRCUITS
IC1101 VHiLM393A//-1Y J LM393APSR AL
IC1102 VHPGP2S40//-1S J IC AK
CAPACITORS
C1101 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1102 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
RESISTORS
R1101 VRS-TV1JD680JY J 68 1/16W Metal Oxide AA
R1102 VRS-CY1JF153FY J 15k 1/16W Metal Oxide AA
R1103 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1104 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1105 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1112 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P1101 QPLGN0363TAZZY J Plug, 3Pin (CW) AC
QCNW-C221WJQZ J Lead Relay Wire AF
