Sharp XR-1X Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
134
XR-1X
RDENCA075WJZZ
POWER/BALLAST UNIT
INTEGRATED CIRCUITS
IC711 98ENZUSYIC7110 J FA5501AN-TE1 AQ
IC712 98ENZUSYIC7120 J STR-G6452LF1106 AY
IC713 98ENZUSYIC7130 J L78N12CDT AK
HIC19 98ENZUSYSK0000 J CEM3 ELC4970R&S AL
HIC20 98ENZUSYHIC190 J CEM3 ELC4970R&S AU
HIC21 98ENZUSYHIC200 J CEM3 ELC4970R&S BK
TRANSISTORS
Q711 98ENZUSYQ71100 J SPA20N60C3 BA
Q712 98ENZUSYQ71200 J B1197KT146R AE
Q713 98ENZUSYQ71100 J SPA20N60C3 BA
Q714 98ENZUSYQ71200 J B1197KT146R AE
Q715 98ENZUSYQ71500 J FK14KM-10 AV
Q716 98ENZUSYQ71600 J STP20NM60FP BA
DIODES
D711 98ENZUSYD71100 J YG972S6R AR
D712 98ENZUSYD71200 J MA152WA AD
D713 98ENZUSYD71300 J MA152WA AD
D714 98ENZUSYD71100 J YG972S6R AR
D715 98ENZUSYD71200 J MA152WA AD
D716 98ENZUSYD71200 J MA152WA AD
D717 98ENZUSYD71700 J SARS-01W AH
D718 98ENZUSYD71800 J US1J-G11 AF
D719 98ENZUSYD71800 J US1J-G11 AF
D720 98ENZUSYD72000 J 1SS250 AF
D721 98ENZUSYD71200 J MA152WA AD
D722 98ENZUSYD72200 J EA40QC10 AP
D723 98ENZUSYD72400 J SEPB-74V AK
D724 98ENZUSYD72400 J SEPB-74V AK
D725 98ENZUSYD71200 J MA152WA AD
ZD711 98ENZUSYZD7110 J Zener Diode, 30V AD
ZD712 98ENZUSYZD7120 J Zener Diode, 20V AD
ZD713 98ENZUSYZD7130 J Zener Diode. 2.2V AD
CONTROL
VR711 98ENZUSYVR7110 J Volume Resistor, 2k AK
COILS AND TRANSFORMERS
L712 98ENZUSYL71200 J Choke coil, 100µH AH
å L714 98ENZUSYL71400 J Choke coil, 146µH AX
L715 98ENZUSYL71500 J Choke coil, 10µH AH
L716 98ENZUSYL71500 J Choke coil, 10µH AH
PT711 98ENZUSYPT7110 J Transformer AP
T711 98ENZUSYT71100 J Transformer AZ
Note: When exchanging the following parts, it becomes unit replace-
ment correspondence.
å L711 Not Available - Transformer —
å L713 Not Available - Choke coil, 70µH —
CAPACITORS
C711 98ENZUSYC71100 J 0.47 420V AL
C712 98ENZUSYC72400 J 470p 630V AG
C713 98ENZUSYC71300 J 1000p 50V AB
C714 98ENZUSYC71400 J 120 400V Electrolytic AV
C715 98ENZUSYC71500 J 0.01 50V AB
C716 98ENZUSYC71600 J 470p 50V AB
C717 98ENZUSYC71700 J 0.47 25V AC
C718 98ENZUSYC71500 J 0.01 50V AB
C719 98ENZUSYC71900 J 0.22 50V AD
C720 98ENZUSYC71100 J 0.47 420V AL
C721 98ENZUSYC71700 J 0.47 25V AC
C722 98ENZUSYC72200 J 1 250V AK
C723 98ENZUSYC72300 J 1500p 1500V AG
C724 98ENZUSYC72400 J 470p 630V AG
C725 98ENZUSYC72400 J 470p 630V AG
C726 98ENZUSYC72600 J 10 50V Electrolytic AD
C727 98ENZUSYC71900 J 0.22 50V AD
C728 98ENZUSYC71600 J 470p 50V AB
C729 98ENZUSYC71300 J 1000p 50V AB
C730 98ENZUSYC73000 J 33 35V AD
C731 98ENZUSYC73100 J 0.01 630V AG
å C732 98ENZUSYC73200 J 4700p
AC250V AF
å C733 98ENZUSYC73200 J 4700p AC250V AF
C734 98ENZUSYC73500 J 1000 10V Electrolytic AG
C735 98ENZUSYC73500 J 1000 10V Electrolytic AG
C736 98ENZUSYC73600 J 680 16V Electrolytic AG
C737 98ENZUSYC71900 J 0.22 50V AD
C738 98ENZUSYC73800 J 0.0332 630V AG
RESISTORS
R711 98ENZUSYR71100 J 330k 1/4W AB
R712 98ENZUSYR71100 J 330k 1/4W AB
R713 98ENZUSYR71100 J 330k 1/4W AB
R714 98ENZUSYR71400 J 22k 1/10W AA
R715 98ENZUSYR71500 J 0.68 1/4W AE
R716 98ENZUSYR71500 J 0.68 1/4W AE
R717 98ENZUSYR71500 J 0.68 1/4W AE
R718 98ENZUSYR71500 J 0.68 1/4W AE
R719 98ENZUSYR71900 J 0.62 1/4W AE
R720 98ENZUSYR71900 J 0.62 1/4W AE
R721 98ENZUSYR72100 J 180k 1/4W AB
R722 98ENZUSYR72100 J 180k 1/4W AB
R723 98ENZUSYR72100 J 180k 1/4W AB
R724 98ENZUSYR72400 J 22k 1/4W AA
R725 98ENZUSYR72500 J 6.8k 1/10W AA
R726 98ENZUSYR72600 J 100 1/10W AA
R727 98ENZUSYR72700 J 1M 1/10W AA
R728 98ENZUSYR72800 J 2.7k 1/10W AA
R729 98ENZUSYR72900 J 1k 1/4W AA
R730 98ENZUSYR73000 J 330 1/4W AA
R731 98ENZUSYR72100 J 180k 1/4W AB
R732 98ENZUSYR72100 J 180k 1/4W AB
R733 98ENZUSYR72100 J 180k 1/4W AB
R734 98ENZUSYR73400 J 10 1/8W AA
R735 98ENZUSYR71400 J 22k 1/10W AA
R736 98ENZUSYR73600 J 0.82 1W AD
R737 98ENZUSYR73600 J 0.82 1W AD
R738 98ENZUSYR73600 J 0.82 1W AD
R739 98ENZUSYR73900 J 820 1/10W AA
R740 98ENZUSYR74000 J 200k 1/4W AB
R741 98ENZUSYR74000 J 200k 1/4W AB
R742 98ENZUSYR74000 J 200k 1/4W AB
R743 98ENZUSYR74300 J 330k 1/8W AA
R744 98ENZUSYR74300 J 330k 1/8W AA
R745 98ENZUSYR74300 J 330k 1/8W AA
R746 98ENZUSYR74300 J 330k 1/8W AA
R747 98ENZUSYR74300 J 330k 1/8W AA
R748 98ENZUSYR74300 J 330k 1/8W AA
R749 98ENZUSYR74900 J 10k 1/10W AA
R750 98ENZUSYR74900 J 10k 1/10W AA
R751 98ENZUSYR72100 J 180k 1/4W AB
R752 98ENZUSYR72100 J 180k 1/4W AB
R753 98ENZUSYR72100 J 180k 1/4W AB
R754 98ENZUSYR75400 J 22 2W AC
R755 98ENZUSYR75500 J 27k 1W AC
R756 98ENZUSYR75500 J 27k 1W AC
R757 98ENZUSYR75700 J 51 1/4W AA
R758 98ENZUSYR75800 J 4.7 1/4W AA
R759 98ENZUSYR75900 J 22k 1/8W AA
R760 98ENZUSYR76000 J 1.2k 1/10W AA
R761 98ENZUSYR76100 J 1.5k 1/10W AA
R762 98ENZUSYR76200 J 3.3k 1/10W AA
R763 98ENZUSYR76300 J 0.91 1/2W AE
R764 98ENZUSYR76400 J 360 1/10W AA
R765 98ENZUSYR76500 J 10k 1/4W AA
R766 98ENZUSYR76600 J 2k 1/4W AA
R767 98ENZUSYR76700 J 1 1/4W AA
MISCELLANEOUS PARTS
FB713 98ENZUSYFB7130 J Ferrite Beads AD
FB714 98ENZUSYFB7140 J Ferrite Beads AF
FB715 98ENZUSYFB7130 J Ferrite Beads AD
FB716 98ENZUSYFB7140 J Ferrite Beads AF
