Sharp XR-1X Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
135
XR-1X
RDENCA075WJZZ
POWER/BALLAST UNIT(Continued)
CP711 98ENZUSYF70200 J Fuse, 1A/AC250V AF
CP712 98ENZUSYF70101 J Fuse, 4A/AC250V AF
CN711 98ENZUSYCN7110 J Connector, 8 Pin AH
CN712 98ENZUSYCN7120 J Connector, 3 Pin AE
CN713 98ENZUSYCN7130 J Connecting Cord AN
(LAMPOUT)
CN1712 98ENZUSYCN1712 J Connector, 4 Pin AK
LB711 98ENZUSYLB7110 J Connecting Cord (INLET) AX
HS-2 98ENZUSYHS0030 J Heat sink (Q711,D711) AN
HS-3-1 98ENZUSYHS0040 J Heat sink (Q712,713) AS
HS-3-1 98ENZUSYHS0050 J Heat sink (Q712,713) AP
98ENZUSYSC0001 J RIVSCREW AE
(Q1—4,D1,2), L=5mm
98ENZUSYSC0002 J RIVSCREW AE
(HIC19), L=4mm
98ENZUSYSC0030 J SCREW, M2.6 x6 AC
98ENZUSYIS0000 J Insulation seat(T1), FR765 AN
RUNTKA079WJZZ
AC Inlet UNIT
DIODES, THERMISTER AND ABZOBER
å DB701 98ENZUSYDB7010 J D10XB60 AT
å RTH701 98ENZUSYRT7010 J Thermister AK
ZNR701 98ENZUSYZR7010 J Abzober, DC470V AE
COILS
å LF701 98ENZUSYLF7010 J Choke coil, 11.5mH AQ
å LF702 98ENZUSYLF7020 J Choke coil, 4mH AP
å L701 98ENZUSYL70100 J Choke coil, 80µH AV
CAPACITORS
å C701 98ENZUSYC70100 J 0.33 AC250V AK
å C702 98ENZUSYC70200 J 0.68 AC250V AL
å C703 98ENZUSYC70300 J 2200p AC250V AE
å C704 98ENZUSYC70300 J 2200p AC250V AE
å C705 98ENZUSYC70500 J 4700p AC250V AF
RESISTORS
R701 98ENZUSYR70100 J 240k 1W AC
MISCELLANEOUS PARTS
å F701 98ENZUSYF70100 J Fuse, 4A/AC250V AR
å CN701 98ENZUSYCN7010 J Connector, 3Pin AM
CN702 98ENZUSYCN7020 J Connector, 2Pin AF
98ENZUSYHS0020 J Heat sink (DB701) AH
98ENZUSYSC0000 J RIVSCREW AE
(DB701), L=6mm
98ENZUSYHS0010 J A ground board for INLET AP
98ENZUSYSC0010 J SCREW (FG), M2.6X5 AE
