XV-Cl E
1
3. Adjustment subjects
VIDEO 1
H-CENT
CONT
BRIGHT
TINT
COLOR
SUB-R
SUB-G
SUB-B
NTSC horizontal position adjustment
Sub-contrast adjustment
Brightness adjustment
Tint adjustment
Colour adjustment
Not used, just to be 0 (zero)
Not used, just to be 0 (zero)
Not used, just to be 0 (zero)
VIDEO 2
SUB-BIAS
R-BIAS
B-BIAS
R-DRIVE
B-DRIVE
Sub-bias adjustment
White balance (red), bias adjustment
White balance (blue), bias adjustment
White balance (red), drive adjustment
White balance (blue), drive adjustment
VIDEO 3
P-H-CENT
P-COLOR
S-COLOR
PAL horizontal position adjustment
PAL colour adjustment
SECAM colour adjustment
TEMPSET
Temperature detection level setting
N.W (Single-colour display)
R
Red
G
Green
B
Blue
N.W:
Not used
12
