Shibaura N843 - Maintenance

5-18 109823_2/09
Maintenance
Item Standard Value or Service Limit
Volts 11
No-load Characteristic Amps 110 Max
R.P.M. 2400 Min.
Commutator Outer Dia. 1.16in.(29.4mm)
Service Limit 1.14in.(28.8mm)
Brush Length 0.69in.(17.5mm)
Service Limit) 0.40in.(10mm)
Brush spring Tension 5.1–7.3 lb
f
(22.5–32.5 N)
Service Limit 2.3 lb
f
(10 N)
Pinion Movement (Pinion Gap) 0.020–0.079 (0.5–2.0mm)
