Section 4 Functions of operating components
29
② Lifting/lowering lever
Used to lift or lower the mower.
<While the cutting button lamp is out:>
By pushing down the lever to the B auto
side, the mower lowers and by pulling it
up to the A lifting side, the mower rises
only while the lever is being operated.
<While the cutting button lamp is ON:>
By pushing down the lever to the B auto
side, the mower lowers and the rotary
blade rotates.
By pulling up the lever to the A lifting
side, the rotary blade stops and lifts only
while the lever is being operated.
③ Lapping button
This button is used to rotate the rotary
blades reversely. By pressing the lapping
button to light the lamp and lowering the
lifting/lowering lever to the B auto side,
the rotary blades reverse. By pushing up
the button to the A rising side, the blade
stops.
Warning
Do not press the mowing button and
lapping button at the same time.
To Next Page
