Section 6 Operation and works
36
[ Work flow ]
6. Loading on and unloading from
truck
Warning
● When loading or unloading the machine onto
or from the truck, place the truck on a flat
surface not prevented by the traffic, stop the
engine of the truck, apply the side brake and
chock the wheels.
● Select footboards (road boards) with sufficient
width, length and strength and not slipping.
Hitch the hook positively on the bed of the
truck so that the footboards do not come out.
● Load the machine by reversing it.
● Remove mud, etc. from the tires so that the
vehicle does not slip on the footboard.
● Never change the direction of the vehicle on
the footboards. If the direction should be
changed, unload the vehicle once and repeat
the same steps.
① Loading and unloading using
footboards
<Standards of footboard>
● Length:······More than 3.5 times the height of
the truck bed.
● Width:········ More than 40cm
● Strength: ··· Can stand the weight of 1500kg
enough.
● Treated surface to be not slippery
● Install the right and left footboards positively
on a same level, symmetrically about the
center of the bed.
Selection of
operation
Cutting the grass
Lapping
Push the cutting
button
Push the lapping
button
Lower the
lifting/lowering
lever to auto
To Next Page
